Push-In |
Spacing 3.5 mm
AK4291/..KDVP/1-3.5-PEBBLE GREY
- 2- to n-poles
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.08 mm²
1.5 mm²
0.14mm²
1.0 mm²
0.14 mm²
0.5 mm²
Order Data (Spacing 3.5 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
8.50
12.00
15.50
19.00
22.50
26.00
29.50
33.00
36.50
40.00
43.50
Poles
Width (mm)
Article Designation
AK4291/2KDVP/1-3.5-PEBBLE
GREY
AK4291/3KDVP/1-3.5-PEBBLE
GREY
AK4291/4KDVP/1-3.5-PEBBLE
GREY
AK4291/5KDVP/1-3.5-PEBBLE
GREY
AK4291/6KDVP/1-3.5-PEBBLE
GREY
AK4291/7KDVP/1-3.5-PEBBLE
GREY
AK4291/8KDVP/1-3.5-PEBBLE
GREY
AK4291/9KDVP/1-3.5-PEBBLE
GREY
AK4291/10KDVP/1-3.5-PEBBLE
GREY
AK4291/11KDVP/1-3.5-PEBBLE
GREY
AK4291/12KDVP/1-3.5-PEBBLE
GREY
Article
Number
54291020061 F
54291030061 F
54291040061 F
54291050061 E
54291060061 E
54291070061 E
54291080061 D
54291090061 D
54291100061 D
54291110061 D
54291120061 D
PU
200
200
200
100
100
100
50
50
50
50
50
UL 94 V-0
3
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
4
5
6
7
8
9
10
11
Dimensions
Stripped Length
PCB Hole Diameter
9.0 mm
1.0 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
Materials
Contact Tag
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
Colours
PEBBLE GREY, RAL 7032
ORANGE, RAL 2011
BLUE, RAL 5015
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
12
Accessoires
Figure
Designation
Bridge, 2-pole, insulated,
BRI/2-7.0/7.62-L7.5-LIGHT GREY
Article Number
Order Data:
50000000018
Bridge, 2-pole, angled,
BR/2-3.5/3.81-H-L7.5
Order Data:
50000000029
Bridge, 2-pole, BR/2-3.5/3.81-L7.5
Order Data:
50000000015
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
Order Data:
50000000016
Spacer SPC-AK4291-PEBBLE GREY
Order Data:
54291000000
Ratings
UseGroup
Rated Voltage
Rated Current
Rated Wire Size
- solid
- stranded
Test Voltage
B
300 V
6A
C
-
-
D
300 V
6A
min
250 V
3A
max
0.75 mm²
-
2.0 kV
AWG 22-16
-
1.60 kV
-
-
-
AWG 22-16
-
1.60 kV
0.2 mm²
-
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
