364073: DescriptionBoard Connector, 48 Contact(s), 3 Row(s), Female, Straight, 0.2 inch Pitch, Press Fit Terminal, Locking, Plug,; CategoryThe connector The connector; File Size74KB，1 Pages; ManufacturerERNI; Websitehttp://www.erni.com

Download Datasheet Parametric View All

364073 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	364073	-	-	View	Buy Now

364073 Overview

Board Connector, 48 Contact(s), 3 Row(s), Female, Straight, 0.2 inch Pitch, Press Fit Terminal, Locking, Plug,

364073 Parametric

Parameter Name	Attribute value
Maker	ERNI
Reach Compliance Code	compli
ECCN code	EAR99
Other features	COMPLIANT FIT
body width	0.618 inch
subject depth	0.457 inch
body length	3.74 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	COPPER ALLOY
Contact resistance	15 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	1550VAC V
Durability	400 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	1.251 N
Insulation resistance	10000000000 Ω
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
MIL compliance	NO
Plug contact pitch	0.2 inch
Match contact row spacing	0.2 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Loaded row name	A,C,E
PCB row number	3
Number of rows loaded	3
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	5.08 mm
polarization key	POLARIZED HOUSING
Rated current (signal)	5.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	1.024 inch
Terminal pitch	5.08 mm
Termination type	PRESS FIT
Total number of contacts	48

Preview

Download Datasheet

View All

Datum

date

class

ERNI

RC 2

Anforderungsstufe

11,6 max

XXXX

a

c

e

1

26

±0,2

2,9

-0,3

mating transfer zone

5

Übergabesteckzone

5,08

15 x 5,08 = 76,2

95 max

a32

a2

a

15,7

-0,3

6

0,3

3

c

e

2,8

e32

+0,1

0,6

2 x 5,08 = 10,16

13,6

-0,1

+0,2

Elastische Einpresszone mit Übergabesteckzone /

1

85

-0,2

90

±0,10

+0,1

e2

compliant pressfit zone with mating tranfer zone

Isolierwerkstoff /

housing material:

PBT GF30

Bauart 7 /

type 7

Anforderungsstufe 2 = 400 Steckzyklen /

performance class 2 = 400 mating cycles

Fehlende Masse und Angaben nach IEC 60 603-2 / DIN EN 60 603-2

Missing information and dimensions per IEC 60 603-2 / DIN EN 60 603-2

bestückt /

assembled

Schichtaufbau im metallisierten Loch siehe Zeichnung 164062 / Nr. 10

4

2

a

c

Bedruckung siehe Zeichnung 294875

0,09

1)

ø

1,6

+ 0,06

Durchmesser des metallisierten Loches

-

Bestückungsplan /

contact layout

32

30

28

26

24

22

20

18

16

14

12

diameter of drilled hole see drawing 164062 / No. 10

0,09

ø

1,6

+ 0,06

Diameter of finished plated-through hole

-

10

8

6

Marking see drawing 294875

2 x 5,08 = 10,16

e

Leiterplatten-Lochbild /

PCB drillhole pattern

2,8

+0,1

1)

0,05

alle Löcher /

all holes

a

0,3

c

e

32

30

28

5,08

26

24

22

20

18

16

14

12

10

8

6

4

2

8,17

Copyright by ERNI GmbH

Proprietary notice pursuant to ISO 16016 to be observed.

Information:

Tolerances

All Dimensions

in mm

Scale

2:1

15 x 5,08 = 76,2

90

Only for Information.

To ensure that this is the latest

version of this drawing, please

contact one of the ERNI companies

before using.

-

Index

19.06.2008

Date

Designation

Subject to modification without

prior notice.

Drawing will not be updated.

Federleiste E 48 EE

Fem. Connector E 48 Pressfit

www.ERNI.com

Class

364073

STVE

I

A3
