ULTRA MINIATURE SMD HCMOS/TTL OSCILLATORS

F3400/F3410

FEATURES

Fox introduces the F3400 series, our newest ultra miniature surface

mount oscillator. This AT-strip design is housed in a 6.0 x 3.5 x

1.5mm ceramic package, providing one of the smallest footprints

in the industry.

MODEL NUMBER SELECTION

Frequency Stability

Model Number

±100PPM

±50PPM

±25PPM

F3400

F3405

F3406

F3410

F3415

F3416

TTL / HCMOS

Ultra Miniature Package

Tri-state Enable/ Disable

Tape & Reel

(2,000 pcs. STD)

Note: -40ºC ~ +85ºC "R" version available

in 100 & 50 PPM

(ex: F3400R)

ELECTRICAL CHARACTERISTICS (V

DD

= 5.0V, C

L

= Max Load)

OSCILLATORS

PARAMETERS

Frequency Range

Frequency Stability

Temperature Range

Operating

Storage

Supply Voltage

Input Current

Output Symmetry

Rise Time

Fall Time

Output Voltage

Output Current

Output Load

(Fo)

(T

OPR

)

(T

STG

)

(V

DD

)

(I

DD

)

(T

R

)

(T

F

)

(V

OL

)

(V

OH

)

(I

OL

)

(I

OH

)

FREQUENCY

RANGE

1.544 ~ 50.000

CONDITIONS

All Conditions*

F3400

MIN

MAX

1.544

-100

-10

-30

+4.5

50.000

+100

+70

+85

+5.5

25

40

60

5

0.5

16

-16

10

50

10

100

F3410

MIN

MAX

1.544

-100

-10

-30

+4.5

40

50.000

+100

+70

+85

+5.5

13

24

60

10

0.5

4

-4

10LS

15

10

100

UNITS

MHz

PPM

ºC

V

mA

%

nS

V

mA

TTL

pF

mS

nS

1.544 ~

25.000+ ~

1.544 ~

25.000

50.000

1.544 ~ 50.000

Start-up Time

(T

S

)

Enable/Disable Time

2.5V

0.5V to 4.5V

4.5V to 0.5V

I

OL

= 16mA / I

OL

= 4mA

I

OH

= -16mA / I

OH

= -4mA

V

OL

= 0.5V

V

OH

= 4.5V

TTL

HCMOS

40

4.5

* Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging, shock, and vibration.

***An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF bypass capacitor should be placed between V

DD

(Pin 4) and GND (Pin 2) to minimize power supply line noise.

See page 44 for mechanical specifications, test circuits, and output waveform.

All specifications subject to change without notice. Rev. 03/02/00

ENABLE / DISABLE FUNCTION**

INH (Pin 1)

OPEN ***

'1' Level V

IH

³

2.2 V

'0' Level V

IL

£

0.8 V

OUTPUT (Pin 3)

ACTIVE

High Z

All dimensions are in millimeters.

See page 74 for tape and reel specifications.

56

FOXElectronics

5570 Enterprise Parkway

Fort Myers, Florida 33905

941-693-0099

FAX 941-693-1554

http://www.foxonline.com
