IM831D-37UAO-119.342001MHZ datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> IM831D-37UAO-119.342001MHZ

IM831D-37UAO-119.342001MHZ: Description119.342001MHz Nom,; CategoryPassive components oscillator; File Size639KB，9 Pages; ManufacturerILSI; Websitehttp://www.ilsiamerica.com; Environmental Compliance

Download Datasheet Parametric View All

IM831D-37UAO-119.342001MHZ Overview

119.342001MHz Nom,

IM831D-37UAO-119.342001MHZ Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ILSI
package instruction	DILCC4,.08,75
Reach Compliance Code	compli
maximum descent time	2 ns
Frequency Adjustment - Mechanical	NO
frequency stability	25%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Number of terminals	4
Nominal operating frequency	119.342001 MHz
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Oscillator type	LVCMOS/HCMOS
Output load	15 pF
Encapsulate equivalent code	DILCC4,.08,75
physical size	2.5mm x 2mm x 0.8mm
longest rise time	2 ns
Maximum supply voltage	3.63 V
Minimum supply voltage	2.97 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	45/55 %
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)

Preview

Download Datasheet

View All

MEMS Oscillator, -55°C to +125°C, LVCMOS/HCMOS Compatible, 119.342001 MHz to 137.000MHz

IM831 Series

Features:



MEMS Technology

Direct pin to pin drop-in replacement for industry-standard packages

Ultra-low phase jitter: 0.5 pSec (12 kHz to 20 MHz)

LVCMOS/HCMOS Compatible Output

Industry-standard package 2.0 x1.6, 2.5 x 2.0, 3.2 x 2.5, and 5.0 x 3.2 mm x mm

Pb-free, RoHS and REACH compliant

Fast delivery times

Typical Applications:



Fibre Channel

Server and Storage

GPON, EPON

100M / 1G /10G Ethernet

Ruggedized equipment in

harsh operating environment

Electronic Specifications:

Frequency Range

Frequency Stability

Operating Temperature

Supply Voltage (Vdd) ±10%

Current Consumption

119.342001 MHz to 137.000MHz

See Part Number Guide

-55°C of +125°C

See Part Number Guide

6.2 mA typ./ 8.0 mA max

5.4 mA typ./ 7.0 mA max

4.9 mA typ./ 6.0 mA max

4.7 mA max

4.5 mA max

2.6 µA typ./ 8.5 µA max

1.4 µA typ./ 5.5 µA max

0.6 µA typ./ 4.0 µA max

LVCMOS/HCMOS

45%/55%

1.0 nSec typ./ 2.0 nSec max

1.3 nSec typ./ 2.5 nSec max

90% of Vdd min

10% of Vdd max

70% of Vdd min

30% of Vdd max

50 kΩ min/ 87 kΩ typ./150 kΩ max,

2.0 MΩ min

5 mSec max

130 nSec max

5 mSec max

1.6 pSec typ./ 2.5 pSec max

1.8 pSec typ./ 3.0 pSec max

12 pSec typ./ 20 psec max

14 pSec typ./ 25 pSec max

0.5 pSec typ./ 0.8 pSec max

1.3 pSec typ./ 2.0 pSec max,

Inclusive of Operating Temperature Range, Load, Voltage, and Aging

OE Disable Current

Standby Current

No load condition, f = 125 MHz, Vdd = +2.8 V, +3.0 V or +3.3 V

No load condition, f = 125 MHz, Vdd = +2.5 V

No load condition, f = 125 MHz, Vdd = +1.8 V

Vdd = +2.5 V, or +3.3 V, OE = Low, output is high Z state

Vdd = +1.8 V, OE = Low, output is high Z state

Vdd = +2.8 V to 3.3 V,

= low

Vdd = +2.5 V,

= Low

Vdd = +1.8 V,

= Low

50% of waveform

Vdd = +2.5 V, +2.8 V, 3.0 V or 3.3 V from 20% to 80% of waveform

Vdd = +1.8 V, from 20% to 80% of waveform

Waveform Output

Symmetry

Rise / Fall Time

Logic “1”

Logic “0”

Input Voltage High

Input Voltage Low

Input Pull-up Impedance

Startup Time

Enable/Disable Time

Resume Time

RMS Period Time

Peak-to-Peak Period Jitter

RMS Period Time (random)

Pin 1, OE or

Pin 1, OE logic high or logic low, or

logic high

Pin 1,

logic low

Measured from the time Vdd reaches its rated minimum values

F = 119.342001 MHz. For other frequencies, T_oe = 100 ns + 3 *

clock periods

Measured from the time

pin crosses 50% threshold.

F = 125 MHz, Vdd = +2.5 V, +2.8 V, +3.0 V or +3.3 V

F = 125 MHz, Vdd = +1.8 V

F = 125 MHz, Vdd = +2.5 V, +2.8 V, +3.0 V or +3.3 V

F = 125 MHz, Vdd = +1.8 V

F = 125 MHz, Integration bandwidth = 900 kHz to 7.5 MHz

F = 125 MHz, Integration bandwidth = 12.0 kHz to 20.0 MHz

Notes:



All min and max limits are specified over temperature and rated operating voltage with 15pF output unless otherwise stated.



Typical values are at +25ºC and nominal supply voltage.

ILSI America Phone 775-851-8880

●

Fax 775-851-8882

●email:

e-mail@ilsiamerica.com

●

www.ilsiamerica.com

Specifications subject to change without notice

Rev 01/30/16_A

Page 1 of 9
