BAV100/101/102/103
500mW.Hermetically Sealed Glass High Voltage Switching Dides
MINI MELF
Features
High Voltage Switching Device
Mini Melf package
Surface device type mounting
Hermetically sealed glass
Compression bonded construction
All external surface are corrosion resistant
and leads are readily solderable
RoHS compliant
Matte Tin (Sn) lead finish
Color band indicates Negative Polarity
Dimension in millimeters
Maximum Ratings and Electrical Characteristics
Rating at 25
o
Cambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Maximum Ratings
Type Number
Repetitive Peak Reverse Voltage
Symbol
V
RRM
Value
250
Units
V
mA
A
mW
O
C
Units
V
V
nA
Average Rectified Forward Current
I
F(AV)
200
Non- Repetitive Peak Forward Surge Current
1.0
I
FSM
Pulse Width =1.0 Second
4.0
Pulse Width = 1.0 usecond
Power Dissipation
Pd
500
Operating and Storage Temperature Range
T
J
, T
STG
-65 to + 200
Electrical Characteristics
Type Number
Symbol
Min
Max
60
Breakdown Voltage
BAV100 IR=100uA
120
BAV101 IR=100uA
B
V
200
BAV102 IR=100uA
250
BAV103 IR=100uA
Forward Voltage
IF= 100mA
V
F
1.0
Peak Reverse Current BAV100 VR=50V
100
IR
BAV101 VR=100V
100
-
BAV102 VR=150V
100
BAV103 VR=200V
100
R
ӨJA
Thermal Resistance, Junction to Ambient
350
-
Junction Capacitance VR=0, f=1.0MHz
Cj
5.0
-
Reverse Recovery Time (Note)
trr
50
Notes: Reverse Recovery Test Conditions: IF=IR=30mA, Irr=3mA, R
L
=100Ω.
o
C/W
pF
nS
ht
t
p
:
//
Revision:20170701-P1
www.lgesemi
.c
o
m
mail:lge@lgesemi.com
BAV100/101/102/103
500mW.Hermetically Sealed Glass High Voltage Switching Dides
RATINGS AND CHARACTERISTIC CURVES
(BAV100/101/102/103)
1000
I
F
- Forward Current ( mA )
1000
I
R
- Reverse Current (
µ
A )
100
T
j
= 25° C
100
Scattering Limit
10
1
0.1
0.01
0
Scattering Limit
10
V
R
= V
RRM
1
0.1
40
80
120
160
200
0
0.4
0.8
1.2
1.6
2.0
T
j
- Junction Temperature (
°
C )
V
F
- Forward Voltage ( V )
Fig. 1 Reverse Current vs. Junction Temperature
Fig. 2 Forward Current vs. Forward Voltage
r
f
- Differential Forward Resistance (
Ω
)
1000
100
T
j
= 25° C
10
1
0.1
1
10
100
I
F
- Forward Current ( mA )
Fig. 3 Differential Forward Resistance vs. Forward Current
