Silicon Bridge Rectifiers
KBU10A-KBU10M
FEATURES
Rating to 1000V PRV
Surge overload rating to
220
Amperes peak
Ideal for printed circuit board
Reliable low cost construction utilizing molded
plastic technique results in inexpensive product
Lead solderable per MIL-STD-202 method 208
KBU
Dim
A
A1
B
B1
C
C1
E
F
F1
K
4.70
All Dimensions in mm
Min
22.80
3.70
18.90
17.60
6.55
4.50
Ø1.20
25min
4min
5.30
Max
23.20
4.10
19.30
18.00
6.85
4.80
Ø1.40
Maximum Ratings
(@TA = 25°C unless otherwise specified)
Characteristic
Maximum recurrent peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward Output current
@T
A
=25℃
Peak forward surge current
8.3ms single half-sine-wave
superimposed on rated load
I
FSM
220
A
Symbol
V
RRM
V
RMS
V
DC
KBU10A KBU10B KBU10D KBU10G
50
35
50
100
70
100
200
140
200
400
280
400
KBU10J
600
420
600
KBU10K KBU10M
800
560
800
1000
700
1000
UNITS
V
V
V
I
F(AV)
10.0
A
I²t Rating for fusing @Tj=25℃
I²t
200
A²S
Thermal Characteristics
Characteristic
Symbol
KBU10A KBU10B KBU10D KBU10G
KBU10J
KBU10K KBU10M
UNITS
Typical thermal resistance
Operating junction temperature range
Storage temperature range
R
θJ
A
R
θJC
T
J
T
STG
18
4.0
- 55 ---- + 150
- 55 ---- + 150
℃/W
℃
℃
Electrical Characteristics
(@TA = 25°C unless otherwise specified)
Characteristic
Maximum instantaneous forward voltage
@5.0A
@10.0A
Maximum reverse current @T
A
=25℃
at rated DC blocking voltage @T
A
=100℃
I
R
5.0
0.5
μ
A
mA
Symbol
V
F
KBU10A KBU10B KBU10D KBU10G
1.0
1.1
KBU10J
KBU10K KBU10M
UNITS
V
ht
t
p
:
//
Revision:20170701-P1
