SKBPC1504 THRU SKBPC1516
Three Phase Bridge Rectifiers
~
+
Features
●
UL recognition, file #E230084
●
Glass passivated chip
●
High surge current capability
●
Low thermal resistance
●
Solder dip 275 °C max. 7 s, per JESD 22-B106
Typical Applications
‐
~
~
General purpose use in AC/DC bridge full wave
rectification for power supply, home appliances, office
equipment, industrial automation applications.
Mechanical Data
●
Package:
SKBPC
Molding compound meets UL 94 V-0
flammability rating, RoHS-compliant
●
Terminals:
Tin plated leads,
solderable per
J-STD-002 and JESD22-B10
■
Maximum Ratings
(Ta=25℃ Unless otherwise specified
）
PARAMETER
Device marking code
Repetitive Peak Reverse Voltage
Average Rectified Output Current
@60Hz sine wave, R-load, With
heatsink Tc=55℃
Surge(Non-repetitive)Forward
Current @60HZ Half- sine Wave, 1
cycle,
T
a
=25℃
Current Squared Time
@1ms≤t<8.3ms Tj=25℃, Rating of
per diode
Storage Temperature
Junction Temperature
Dielectric Strength, Terminals to
case，AC 1 minute
Mounting Torque
VRRM
IO
V
A
SYMBOL UNIT
SKBPC1504
SKBPC1504
SKBPC1506 SKBPC1508 SKBPC1510 SKBPC1512 SKBPC1514 SKBPC1516
SKBPC1506 SKBPC1508 SKBPC1510 SKBPC1512 SKBPC1514 SKBPC1516
400
600
800
1000
1200
1400
1600
15
IFSM
I
2
t
Tstg
Tj
A
2
180
134.5
-55 ~+150
-55~+150
2.5
10
AS
℃
℃
KV
kg·cm
V
dis
TOR
■Electrical
Characteristics
（T
a
=25℃ Unless otherwise specified）
PARAMETER
Maximum instantaneous forward
voltage drop per diode
Maximum DC reverse current at
rated DC blocking voltage per diode
SYMBOL UNIT
VFM
IRRM
V
TEST
CONDITIONS
IFM=
7.5A
SKBPC15 SKBPC15 SKBPC15 SKBPC15 SKBPC15 SKBPC15 SKBPC15
06
08
08
10
12
14
16
1.2
10
μA
VRM=VRRM
■
Thermal Characteristics
（T
a
=25℃ Unless otherwise specified）
PARAMETER
Thermal
Resistance
SYMBOL
R
θ
J-C
UNIT
SKBPC1506 SKBPC1508 SKBPC1508 SKBPC1510 SKBPC1512 SKBPC1514 SKBPC1516
℃/W
3.0
Between junction
and case, With
heatsink
Revision:20170701-P1
ht
t
p
:
//
www.lgesem i
.c
o
m
mail:lge@lgesemi.com
SKBPC1504 THRU SKBPC1516
■
Ordering Information (Example)
PREFERED
P/N
SKBPC1504~SKBPC1516
PACKAGE
CODE
A1
UNIT WEIGHT(g)
Approximate 19
MINIMUM
PACKAGE(pcs)
50
INNER BOX
QUANTITY(pcs)
50
OUTER CARTON
QUANTITY(pcs)
500
DELIVERY MODE
Paper Box
■
Characteristics (Typical)
FIG1:Io-Tc Curve
180
15
Average Rectified Output Current (A)
FIG2:Surge Forward Current Capability
Half-sine Wave
Peak Forward Surge Current
（
A)
0
100
10
non-repetitive
Ta=25℃
5
50
0
0
50
100
150
0
1
2
5
10
20
50
100
Case Temperature(°C)
Number of Cycles
FIG4:Typical Reverse Characteristics
1000
Tj=125
℃
FIG3:Instantaneous Forward Voltage
60
Instantaneous Forward Current (A)
20
10
5.0
Ta=25
℃
Instantaneous Reverse Current (uA)
100
10
1.0
0.5
Tj=25
℃
1
0.2
0.1
0.4
0.1
0.6
0.8
1.0
1.2
1.4
0
20
40
60
80
100
Instantaneous Forward Voltage (V)
Percent Rated Peak Reverse Voltage(%)
Revision:20170701-P1
ht
t
p
:
//
www.lgesem i
.c
o
m
mail:lge@lgesemi.com
