Leaded Oscillator, OCXO
Metal Package, 20.5 mm X 20.5 mm
Frequency
Output Level
Level
Duty Cycle
Rise / Fall Time
Output Load
Supply Voltage
Current (Warm Up)
Current @ +25 C
Control Voltage (“V” option)
Slope
Temperature
Operating
Storage
Environmental
Package Information
1.000 MHz to 150.000 MHz
HC-MOS
‘0’ = 10% Vcc Max., ‘1’= 90% Vcc Min.
Specify 50%
10% or
5% See Table
10 nS Max. @ Fo < 16 MHz, 5 nS Max. @ Fo > 16 MHz
See Table
5.0 VDC
5%
600 mA Max. @ 5.0 VDC
250 mA @ 5 VDC
2.5 VDC
2.0 VDC,
8
ppm Min.
Positive
See Operating Temperature Table
-40 C to +85 C
See Appendix B for information
MSL = N.A., Termination = e1
I411 Series
Sine
+4 dBm,
3 dBm
N.A.
N.A.
50 Ohms
Part Number Guide
Package
Input
Voltage
3 = 3.3 V
5 = 5.0 V
I411 -
9 = 12 V
Sample Part Number:
Operating
Temperature
7 = 0 C to +50 C
1 = 0 C to +70 C
6 = -10 C to +70 C
3 = -20 C to +70 C
Symmetry
(Duty Cycle)
5 = 45 / 55 Max.
6 = 40 / 60 Max.
I411 - 5151YV - 20.000 MHz
Output
1 = 10TTL / 15 pF HC-MOS
3 = 15 pF HC-MOS
6 = 30 pF
A = Sine
Stability
(in ppm)
Y =
0.5
1 =
0.25
2 =
0.1
3 =
0.05
*
Voltage
Control
V = Controled
F = Fixed
- 20.000 MHz
Frequency
NOTE: A 0.01 µF bypass capacitor is recommended between Vcc (pin 4) and Gnd (pin 2) to minimize power supply noise.
* - Not available for all temperature ranges.
12/10_A
ILSI America
Phone: 775-851-8880 • Fax: 775-851-8882• e-mail: e-mail@ilsiamerica.com • www.ilsiamerica.com
Specifications subject to change without notice
