ALUMINUM ELECTROLYTIC CAPACITORS
PJ
Low Impedance, For Switching Power Supplies
series
Low impedance and high reliability withstanding 5000 hours load life
at +105˚C (3000 / 2000 hours for smaller case sizes as specified below).
Capacitance ranges available based on the numerical values in E12 series under JIS.
Ideally suited for use of switching power supplies.
Compliant to the RoHS directive (2002/95/EC).
PJ
PS
Smaller
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Performance Characteristics
– 55 to +105˚C (6.3 to 100V), – 40 to +105˚C (160 to 400V), – 25 to +105˚C (450V)
6.3 to 450V
0.47 to 15000µF
± 20% at 120Hz, 20˚C
Rated Voltage (V)
Leakage current
6.3 to 100
160 to 450
<
After 1 minute's application of rated voltage, leakage current is not more CV = 1000 :
I
= 0.1CV+40 (µA) max. (1 minute's)
than 0.03CV or 4 (µA), whichever is greater.
CV
>
1000 :
I
= 0.04CV+100 (µA) max. (1 minute's)
120Hz, 20˚C
Tangent of loss angle (tan
δ
)
6.3
10
16
25
35
Rated Voltage (V)
tan
δ (
MAX.
)
0.22
0.19
0.16
0.14
0.12
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Rated voltage (V)
Z– 25˚C / Z+20˚C
Impedance
Z– 40˚C / Z+20˚C
ratio
(
MAX.
)
Z– 55˚C / Z+20˚C
50
0.10
63 to 100 160 to 350 400
•
450
0.08
0.20
0.25
250
—
6
—
315
•
350
—
8
—
400
—
10
—
450
15
—
—
120Hz
Stability at Low Temperature
6.3
•
10
—
—
4
16
—
—
3
25
•
35
—
—
3
50 to 100 160
•
200
—
—
4
—
—
2
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20˚C after D.C. bias plus rated ripple
current is applied for 5000 hours (2000 hours for
φ
D=5 and 6.3,
3000 hours for
φ
D=8) at 105˚C, the peak voltage shall not
exceed the rated voltage.
After storing the capacitors under no load at 105˚C for 1000
hours and then performing voltage treatment based on JIS C
5101-4 clause 4.1 at 20°C, they shall meet the specified
values for the endurance characteristics listed above.
Printed with white color letter on dark brown sleeve.
Capacitance change
Within ±20% of the initial capacitance value
tan
δ
200% or less than the initial specified value
Leakage current
Less than or equal to the initial specified value
Shelf Life
Marking
Capacitance change
Within ±20% of the initial capacitance value
tan
δ
150% or less than the initial specified value
Leakage current
Less than or equal to the initial specified value
Radial Lead Type
Sleeve (P.E.T.)
Type numbering system (Example : 25V 470µF)
φ
d
1
2
3
4
5
6
7
8
9 10 11 12
Type
Small Dia
Low Profile
Configuration
P
±
0.5
Code
6
Size code
UP J 1 E 4 7 1 M PD
φD
+
0.5 MAX.
Capacitance tolerance (±20%)
Rated capacitance (470µF)
Rated voltage (25V)
Configuration
φ
D
5
6.3
8
•
10
12.5 to 18
Pb-free leadwire
Pb-free PET sleeve
DD
ED
PD
HD
Pressure
relief vent
(φ6.3up)
Series name
L+
MAX.
15
MIN
4
MIN
Type
Rated voltage
(φD < 10) 1.0
(φD 10) 1.5
(mm)
Frequency coefficient
15000
Frequency coefficient
10000
6800
4700
3300
2200
1500
1000
680
470
Frequency coefficient
of rated ripple current
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
Rated voltage
15000
10000
6800
4700
3300
2200
1500
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
In case L >25 for the
φ12.5
dia. unit, lead dia.
φ
d=0.8mm.
1000
680
470
•
Please refer to page 20 about the end seal configulation.
330
6.3 to 100V
(10kHz to
200kHz = 1)
Cap.(µF)
220
150
100
68
47
33
120Hz
22
15
10
0.68
0.47
0
0.5
0.6
0.7
0.8
Frequency coefficient
0.9
1.0
300Hz
1kHz
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
160 to 450V
50Hz
0.80
120Hz
1.00
300Hz
1.25
1kHz
1.40
10kHz or more
1.60
Dimension table in next pages.
