YAGeo CorPorATIoN
INDUCTORS / BEADS
SQV Series
APPLICATIONS
Personal, Cordless Phone
High Freq. Communication Products
GPS (Global Positioning System)
Personal Computers
SMD Wire Wound
Chip Inductors
OUTLINE
PRODUCT IDENTIFICATION
The SQV series provides a wide inductance range, high Q value at high frequencies and low DC
resistance.
SQV
☐☐☐☐☐☐
T
☐☐☐☐
-
☐
Internal No.
Tolerance
Inductance
Packaging Style
Dimensions
Product Symbol
FEATURES
These miniature chip inductors wound on a special ferrite core.
High Q value at high frequencies and low DC resistance.
Wide Inductance range
Excellent solder heat resistance. Both flow and reflow soldering methods can be employed.
■
Packaging: T = Tape and reel
■
Internal No.: N = Lead-Free
SHAPES AND DIMENSIONS
Unit: mm
C
A
B
TYPE
SQV322520
SQV453226
A
3.2 ± 0.3
4.5 ± 0.3
B
2.5 ± 0.2
3.6 ± 0.2
C
2.0 ± 0.2
2.6 ± 0.2
E
1.0
1.5
F
1.3
1.5
G
2.0
3.0
E
Pad
Layout
F
E
G
34
ELECTRICAL CHARACTERISTICS
SQV322520
PART NO.
INDUCTANCE (µH)
NOMINAL
VALUE
SQV322520T-r10□-N
SQV322520T-r18□-N
SQV322520T-r27□-N
SQV322520T-r39□-N
SQV322520T-r56□-N
SQV322520T-r68□-N
SQV322520T-r82□-N
SQV322520T-1r0□-N
SQV322520T-1r2□-N
SQV322520T-1r5□-N
SQV322520T-1r8□-N
SQV322520T-2r2□-N
SQV322520T-2r7□-N
SQV322520T-3r3□-N
SQV322520T-3r9□-N
SQV322520T-4r7□-N
SQV322520T-5r6□-N
SQV322520T-6r8□-N
SQV322520T-8r2□-N
SQV322520T-100□-N
SQV322520T-120□-N
SQV322520T-150□-N
SQV322520T-180□-N
SQV322520T-220□-N
SQV322520T-270□-N
SQV322520T-330□-N
SQV322520T-390□-N
SQV322520T-470□-N
SQV322520T-560□-N
SQV322520T-680□-N
SQV322520T-820□-N
SQV322520T-101□-N
SQV322520T-121□-N
SQV322520T-151□-N
SQV322520T-181□-N
SQV322520T-221□-N
SQV322520T-271□-N
SQV322520T-331□-N
SQV322520T-391□-N
SQV322520T-471□-N
SQV322520T-561□-N
0.10
0.18
0.27
0.39
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
TOLERANCE TEST
(±%)
20
20
20
20
20
20
20
20
20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 KHz
1 KHz
QUALITY FACTOR
SPEC.
20
20
25
25
30
30
30
20
20
20
20
20
20
20
20
20
20
20
20
35
35
35
35
35
35
40
40
40
40
40
40
40
40
40
40
40
40
40
50
50
50
TEST
FREQUENCY
25.2 MHz
25.2 MHz
25.2 MHz
25.2 MHz
25.2 MHz
25.2 MHz
25.2 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
200
200
200
200
160
160
120
100
100
75
60
50
43
38
35
31
28
25
23
20
18
16
15
14
13
12
11
11
10
9.0
8.5
8.0
7.5
7.0
6.0
5.5
5.0
5.0
5.0
5.0
5.0
FREQUENCY Min.
SRF
(MHz) Min.
DC
(Ω) Max.
0.025
0.25
0.25
0.25
0.25
0.25
0.25
0.50
0.60
0.60
0.70
0.80
0.90
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
2.20
2.50
2.80
3.10
3.50
3.90
4.30
4.90
5.50
6.20
7.00
8.00
9.30
10.2
11.8
12.5
13.0
22.0
25.0
28.0
RATED
(mA) Max.
700
650
600
530
530
470
450
445
425
400
390
370
320
300
290
270
250
240
225
190
180
170
165
150
125
115
110
100
85
80
70
80
75
70
65
65
65
65
50
45
40
RESISTANCE CURRENT
Note:
Tolerance: J = ± 5%, K = ± 10%, M = ± 20%
Test Instruments: L/Q- HP4192A LF Impedance Analyzer
SrF- HP4291A rF Impedance Analyzer
rDC- CH502BC/HP4338B
IDC- Self temperature rise shall be limited to 35 °C Max. Inductance drop 10% typ.
Soldering Heat: 260 °C 10 sec. after 150 °C Preheat Cycle for 4 Min.
operating Temperature range: -25 °C to +85 °C
35
ELECTRICAL CHARACTERISTICS
SQV453226
PART NO.
INDUCTANCE (µH)
NOMINAL
VALUE
SQV453226T-1r0□-N
SQV453226T-1r2□-N
SQV453226T-1r5□-N
SQV453226T-1r8□-N
SQV453226T-2r2□-N
SQV453226T-2r7□-N
SQV453226T-3r3□-N
SQV453226T-3r9□-N
SQV453226T-4r7□-N
SQV453226T-5r6□-N
SQV453226T-6r8□-N
SQV453226T-8r2□-N
SQV453226T-100□-N
SQV453226T-120□-N
SQV453226T-150□-N
SQV453226T-180□-N
SQV453226T-220□-N
SQV453226T-270□-N
SQV453226T-330□-N
SQV453226T-390□-N
SQV453226T-470□-N
SQV453226T-560□-N
SQV453226T-680□-N
SQV453226T-820□-N
SQV453226T-101□-N
SQV453226T-121□-N
SQV453226T-151□-N
SQV453226T-181□-N
SQV453226T-221□-N
SQV453226T-271□-N
SQV453226T-331□-N
SQV453226T-391□-N
SQV453226T-471□-N
SQV453226T-561□-N
SQV453226T-681□-N
SQV453226T-821□-N
SQV453226T-102□-N
SQV453226T-122□-N
SQV453226T-152□-N
SQV453226T-182□-N
SQV453226T-222□-N
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1,000
1,200
1,500
1,800
2,200
TOLERANCE TEST
(±%)
20
20
20
20
20
20
20
20
10 / 20
10 / 20
10 / 20
10 / 20
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
QUALITY FACTOR
SPEC.
20
20
20
20
20
20
20
20
30
30
30
30
35
35
35
35
35
35
35
35
35
35
35
35
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
TEST
FREQUENCY
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
1 MHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
252 KHz
252 KHz
252 KHz
252 KHz
252 KHz
120
100
85
75
62
53
47
41
38
33
31
27
23
21
19
17
15
14
12
11
10
9.3
8.4
7.5
6.8
6.2
5.5
5.0
4.5
4.0
3.6
3.3
3.0
2.7
2.5
2.2
2.0
1.8
1.6
1.5
1.3
FREQUENCY Min.
SRF
(MHz) Min.
DC
(Ω) Max.
0.20
0.20
0.30
0.30
0.30
0.32
0.35
0.38
0.40
0.47
0.50
0.56
0.56
0.62
0.73
0.82
0.94
1.10
1.20
1.40
1.50
1.70
1.90
2.20
2.50
3.00
3.70
4.50
5.40
6.80
8.20
9.70
11.8
14.5
17.5
20.5
25.0
30.0
37.0
45.0
50.0
RATED
(mA) Max.
500
500
500
500
500
500
500
500
500
500
450
450
400
380
360
340
320
300
270
240
220
200
180
170
160
150
130
120
110
100
95
90
80
70
65
60
50
45
40
35
30
RESISTANCE CURRENT
Note:
Tolerance: J = ± 5%, K = ± 10%, M = ± 20%
Test Instruments: L/Q- HP4192A LF Impedance Analyzer
SrF- HP4291A rF Impedance Analyzer
rDC- CH502BC/HP4338B
IDC- Self temperature rise shall be limited to 35 °C Max. Inductance drop 10% typ.
Soldering Heat: 260 °C 10 sec. after 150 °C Preheat Cycle for 4 Min.
operating Temperature range: -25 °C to +85 °C
36
TAPE DIMENSIONS
TAPE MATERIAL
Carrier Tape: Polystyrene
Cover Tape: Polyethylene
P0
E
W
P2
P
D
B
160mm Min.
Blank Part
Cover Tape
Chip Mounting
Part
Blank
330mm Min.
Leader
A
K
REEL DIMENSIONS
D
B
A
C
Dimensions: mm
TYPE
TAPE
DIMENSIONS
A
SQV322520
SQV453226
2.90
3.60
B
3.60
4.90
K
2.25
3.00
D
1.50
1.50
E
1.75
1.75
W
8
12
P
4
8
P0
4
4
P2
2
2
REEL
DIMENSIONS
A
178
178
B
60
60
C
9.0
13.2
D
1.5
1.5
2,000
500
QUANTITY/
REEL
