ILSB-0603
Vishay Dale
Monolithic Chip Inductors
FEATURES
•
High reliability.
•
Surface mountable.
•
Magnetically self shielded.
•
Nickel barrier plating virtually eliminates silver migration.
MECHANICAL SPECIFICATIONS
Solderability:
90% coverage after 5 second dip in 235°C
solder following 60 second preheat at 120°C to 150°C and
type R flux dip.
Resistance To Solder Heat:
10 seconds in 260°C solder
after preheat and flux per above.
Termination:
90/10 Sn/Pb.
Terminal Strength:
0.5kg for 30 seconds.
Beam Strength:
0.3kg.
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature:
- 55°C to + 125°C.
Thermal Shock:
- 40°C to + 85°C.
Humidity:
90% RH at 40°C, 1000 hours at full rated
current.
Load Life:
85°C for 1000 hours full rated current.
STANDARD ELECTRICAL SPECIFICATIONS
in inches [millimeters]
INDUCTANCE
(
µ
H)
±
10%
0.047
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
THICKNESS “D”
(Inches)
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2
0.031
±
0.008 [0.80
±
0.2]
0.031
±
0.008 [0.80
±
0.2]
Q
(Min.)
10
10
10
15
15
15
15
15
15
15
15
15
15
15
15
35
35
35
35
35
35
35
35
35
30
30
30
30
MIN.
TEST FREQUENCY SELF- RESONANT MAX.
RATED
L&Q
FREQUENCY
DCR
DC CURRENT
(MHz)
(MHz)
(Ohms)
(mA)
50
260
50
0.15
50
250
50
0.25
50
245
50
0.25
25
276
50
0.50
25
236
50
0.50
25
207
50
0.60
25
190
50
0.60
25
173
50
0.80
25
157
50
0.80
25
144
35
0.85
25
127
35
1.00
25
121
35
1.35
25
110
35
1.55
25
104
35
1.70
25
98
35
2.10
10
87
25
0.60
10
74
25
0.80
10
69
25
0.80
10
64
25
0.95
10
58
15
1.15
10
52
15
1.35
10
46
15
1.55
10
41
15
1.70
10
38
15
2.10
4.0
22
15
1.55
4.0
20
15
1.70
4.0
18
15
2.10
2.0
17
15
2.55
TOLERANCE
±
20%
±
20%
±
20%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
±
10%
DESCRIPTION
ILSB-0603
MODEL
3.3
µ
H
INDUCTANCE
VALUE
±
10%
INDUCTANCE TOLERANCE
SAP PART NUMBERING GUIDELINES (INTERNAL)
I
L
S
B
0
6
SIZE
0
3
R
K
3
R
3
K
TOL.
PRODUCT FAMILY
See the end of this data book for conversion tables
PACKAGE
CODE
INDUCTANCE
VALUE
www.vishay.com
68
For technical questions, contact Magnetics@vishay.com
Document Number 34027
Revision 28-Aug-02
ILSB-0603
Monolithic Chip Inductors
DIMENSIONS
in inches [millimeters]
90/10 Sn/Pb Termination
Vishay Dale
B
G
A
Ferrite Body
F
H
D
E
C
Dimensional Outline
Suggested Pad Layout
A
0.063
±
0.006
[1.6
±
0.15]
B
0.031
±
0.006
[0.8
±
0.15]
C
0.012
±
0.006
[0.3
±
0.15]
D
0.031
±
0.008
[0.8
±
0.2]
E
0.105
[2.7]
F
0.035
[0.9]
G
0.025
[0.64]
H
0.040
[1.0]
TAPE AND REEL SPECIFICATIONS 0603 SIZE PER EIA-481-1
in inches [millimeters]
4000 Piece/Reel
P
2
P
0
ØD
0
E
1
T
A
0
0.045
±
.004 [1.14
±
0.1]
B
0
0.068
±
.004 [1.75
±
0.1]
D
0
0.059
±
.005/-0.000 [1.5
±
0.127]
F
W
B
0
ØD
1
A
0
K
0
T
1
ØC
ØN
P
1
D
1
0.039 Min. [1.0 Min.]
E
1
0.069
±
.004 [1.75
±
0.1]
F
0.138
±
.002 [3.50
±
0.05]
K
0
0.045
±
.002 [1.15
±
0.05]
P
0
0.157
±
.004 [4.00
±
0.1]
P
1
0.157
±
.004 [4.00
±
0.1]
P
2
0.079
±
.002 [2.00
±
0.05]
ØA
W
W
1
0.327 Max. [8.3 Max.]
0.008
±
.002 [0.2
±
0.05]
7.000
±
.079 [178
±
2.0]
2.500 [63.5]
0.512
±
.020 [13.00
±
0.05]
T
Empty Trailer
Components
Empty Tape
Cover Tape Leader
Unreel
Direction
160mm Minimum
160mm Minimum
390mm Minimum
A
N
C
W
1
0.315 + 0.059/-0.00 [8.00
±
1.5]
T
1
0.079
±
.002 [2.00
±
0.05]
Document Number 34027
Revision 28-Aug-02
For technical questions, contact Magnetics@vishay.com
www.vishay.com
