SMP1210S-102MLF datasheet, PDF

Datasheet> All Categories > Passive components> inductor> SMP1210S-102MLF

SMP1210S-102MLF: DescriptionGeneral Purpose Inductor,; CategoryPassive components inductor; File Size440KB，2 Pages; ManufacturerGowanda Electronics; Environmental Compliance

Download Datasheet Parametric View All

SMP1210S-102MLF Overview

General Purpose Inductor,

SMP1210S-102MLF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Gowanda Electronics
Reach Compliance Code	compli
ECCN code	EAR99
Inductor type	GENERAL PURPOSE INDUCTOR

Preview

Download Datasheet

View All

POWER SURFACE MOUNT

SMP1210S

SMP1210SLF

Wirewound, Shielded, Molded

RECOMMENDED FOOT PRINT

0.118/0.134

(2.98/3.40)

0.086/0.102

(2.18/2.59)

OVER TRMINAL

PART

NUMBER

SMP1210S-101K

SMP1210S-121K

SMP1210S-151K

SMP1210S-181K

SMP1210S-221K

SMP1210S-271K

SMP1210S-331K

SMP1210S-391K

SMP1210S-471K

SMP1210S-561K

SMP1210S-681K

SMP1210S-821K

SMP1210S-102K

SMP1210S-122K

SMP1210S-152K

SMP1210S-182K

SMP1210S-222K

SMP1210S-272K

SMP1210S-332K

SMP1210S-392K

SMP1210S-472K

SMP1210S-562K

SMP1210S-682K

SMP1210S-822K

SMP1210S-103K

L µH

100

kHz

1.0

1.2

1.5

1.8

2.2

2.7

3.3

3.9

4.7

5.6

6.8

8.2

100

DCR

MAX

FERRITE CORE

0.11

0.13

0.14

0.20

0.22

0.24

0.27

0.30

0.32

0.34

0.39

0.44

0.60

0.75

0.85

1.0

1.4

1.5

2.2

2.4

2.7

3.2

3.7

4.5

5.0

I SAT

mA DC

2060

1860

1690

1550

1430

1240

1160

1030

970

880

800

740

600

580

520

460

420

380

340

320

290

260

240

220

200

CURRENT

RATING

mA DC

1384

1273

1227

1027

979

937

884

838

812

787

735

692

590

530

498

459

388

375

310

292

279

257

239

216

205

0.070

(1.78)

0.130

(3.30)

0.120

(3.50)

0.055

(1.40)

REF

0.090/0.106

(2.29/2.70)

0.066/0.074 (1.68/1.88) WIDE

0.016/0.024 (0.41/0.61) DEEP

in. (mm)

NOTES:

Operating Temperature Range:

-55°C to +125°C

Current Rating

is based on a 40°C temperature

rise at an ambient temperature of 85°C

Weight Max:

0.05 grams

Marking:

PSXXX (dash number)

010

Coupling less than 4% with 1mm of spacing between

components

Epoxy-encapsulated for environmental protection

and superior strength to withstand all types of

reflow soldering

When ordering, specify

tolerance

termination:

Tolerance:

SMP1210S-101KLF

= 20%,

= 10%

Termination: LF

= RoHS compliant tin-silver copper

over copper

Custom designs are available to meet your specific

requirements; please contact factory

TAPE AND REEL SPECS:

Pcs./Reel maximum:

Pitch between parts:

Tape width:

Reel diameter:

Gowanda Electronics is an Affiliate of

(Table shows lowest standard tolerance option)

*Optional tolerances are available; contact factory

2000

8 mm

7 in.

One Magnetics Pkwy, Gowanda, NY 14070

(f ) 716-532-2702

sales@gowanda.com

REV:

ISSUE

05142019

(t) 716-532-2234

www.GowandaComponentsGroup.com

www.gowanda.com
