Ultra Precision Wire-Wound Resistors
Type UPW Series
Key Features
I
Custom weld tabs and
copper weld leads ensure a
good mechanical and
electrical connection
between the element and
the lead wires.
Protection is given to the
windings by means of a
layer of silicone RTV
rubber. This allows
movement of the windings
during temperature
cycling due to loads and
to varying ambient
temperatures. Outer
protection is given by
means of a hot transfer
moulded epoxy compound
which ensures an airtight
coating with no trapped air
Superior quality wire-
wound resistors with very
low selection tolerances
and temperature
coefficients down to 1 ppm.
3 case sizes are available.
T/C, ratio and pair
matching is available
and customer specifications
are welcome. These
components exhibit high
stability under load and
severe environmental
conditions
I
The resistive element is wire wound onto a moulded high temperature plastic bobbin with
a central former. The direction of winding is reversed part way through the winding,
giving very low values of inductance. These Neohm resistors use bobbin assemblies with
flattened lead ends, providing high resistance to pull, vibration and torsional forces
during handling, assembly and life.
Characteristics - Electrical
UPW15
Rated Power @ 125°C (W)
Derate to zero at 145°C
Resistance Range (Ohms) Min
Max
Tolerance (%)
Code Letter
Limiting Element Voltage (V)
Temp. Coefficient (ppm/°C) Typ.
Max.
Operating Temperature Range (°C)
Long Term Stability (Load)
Thermal EMF
150
0.125
R10
300K
E
UPW25
0.25
R10
1M0
L
300
P
W
B
UPW30
0.3
R10
1M0
A
150
D
F
400
UPW50
0.5
R10
2M0
0.005 0.01 0.02 0.05 0.1 0.2 0.5 1
± 3 (0°C to +85°C)
± 5 (-55°C to +125°C) ± 1 available on request
-55 to +145
< 50 ppm @ 10,000 hrs
< 100ppm @ 26,000 hrs
< 0.2 μ V /°C
Dimensions - Style A
Style B
Type
UPW15
UPW25
UPW30
UPW50
Style
A
A
B
A
L ± 0.4
6.35
9.53
7.62
12.7
D ± 0.4
3.18
4.75
7.62
6.35
W ± 0.5
-
-
3.18
-
s ± 0.2
-
-
3.81
-
d nom
0.64
0.64
0.64
0.81
1773299 CIS BI 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Ultra Precision Wire-Wound Resistors
Type UPW Series
Derating Curve
100
Percent Rated Power
80
0.05%
1%, 0.5%, 0.2%, 0.1%
60
40
20
0
0.02%
0.01%
0.005%
40
60
80
100
120
140
160
Ambient Temperature (°C)
UPW Series resistors must be derated for tolerances below 0.1%. Use the graph to select tolerance versus
operating temperature to determine the percentage rated power for operation.
No derating is required for operation below 20 °C.
Mounting
The resistors are suitable for processing on automatic insertion equipment and cutting and bending machines.
Marking
The resistors are marked with the following information:- Manufacturer's name, type number, value and tolerance,
four figure date code.
Packaging
UPW Series resistors are packed loose in boxes.
Performance Characteristics
The evaluation of the performance characteristics is carried out with reference to
IEC specifications QC 400 000 and QC 400 100.
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.16
4.18
4.19
4.22
Long Term Tests ±(0.25% + 0.05 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70 °C
Endurance at 145 °C
Short Term Tests ±(0.1% + 0.01 ohm)
Overload
Robustness of terminations
Resistance to soldering heat
Rapid change of temperature
Vibration
All resistance values are measured at a distance of 9.53mm (0.375 inch) from
the end cap.
How to Order
Orders for these components should include the following information:-
Type, tolerance code letter and value e.g.
UPW30 L 1K15
