REVISION D
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. ALL DIMENSIONS TO BE ABOUT CL WITHIN ±.005[0.13].
3. MINIMUM PUSHOUT FORCE: 3 lbs.
4. MAXIMUM CUT FLASH: .020[0.50].
5. MEASURE FROM THE TIPS OF THE TERMINALS.
6. MEASURE AT BOTH ENDS OF PART.
7. PARTS TO BE PACKAGED IN TUBES FOR 4-50 POSITIONS (.100 [2.54]
PITCH) OR 2-25 POSITIONS (.200 [5.08] PITCH), OTHERWISE BULK PACKAGED.
BTSW-XXX-XX-X-S-XX-XX
TERMINAL SPACE
-1: .100[2.54 (FILL EVERY POSITION)
-2: .200[5.08] (FILL EVERY OTHER POS
STARTING AT -01 AND ENDING
IN LAST POS)
NO OF POSITIONS
-1: -01 THRU -50
-2: -02 THRU -25 (SEE FIG. 3, SHEET 2)
TERMINAL SPECIFICATION
-01: .050[1.27] PROFILE
*-02: .060[1.52] PROFILE
(SEE TABLE 1)
01
.100 2.54
REF
POLARIZATION
XX INDICATES POSITION
TO BE OMITTED; LEAVE
BLANK FOR NO OPTION
OPTIONS
-LL: LOCKING LEAD
(SEE FIG. 2, SHEET 2)
ROW SPECIFICATION
-S: SINGLE
PLATING SPECIFICATION
(VALUES GIVEN ARE IN MICRO-INCHES)
-T: MATTE TIN CONTACT AND TAIL
-F: FLASH GOLD, 3 Au / 50 Ni MIN
(USE T-1S6-XX-GF-2)
* = NOT RELEASED
DO NOT
SCALE FROM
THIS PRINT
.025 0.64 SQ
REF (TYP)
.100 2.54 REF (TYP)
(No. OF POSITIONS x .100[2.54])
- .010
[
- 0.25
]
C
+.015 +0.38
2 MAX SWAY
(TYP)
T-1S6-XX-XXX-2
2 MAX SWAY
(TYP)
TSM-50-SV
"B"±.005
(SEE NOTE 5 & 6)
C
"C"
.100 2.54
REF
90° (TYP)
"A"±.005
(SEE NOTE 5 & 6)
C
BTSW-1XX-XX-X-S SHOWN
FIG 1
TUBE VIEW
* = NOT RELEASED
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01[.3]
.XXX: .005[.13]
.XXXX: .0020[.051]
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
PT-1-24-01-60 (USE TP-03)
(SEE NOTE 7)
MATERIAL:
BODIES:
LCP UL94VO, COLOR: BLACK
TERMINALS:
PHOSPHOR BRONZE
F:\DWG\MISC\MKTG\BTSW-XXX-XX-X-S-XX-XX-MKT.SLDDRW
.025 [.64] SQ. SINGLE ROW, DOUBLE -RA POST ASM
BTSW-XXX-XX-X-S-XX-XX
BY:
J. BROWNING 04/27/2010
SHEET
1
OF
2
REVISION D
C
L
01
.008 0.20
(TYP)
ODD POSITION PART
C
L
.017 0.43 MIN
(TYP)
.040 1.02
01
BTSW-1XX-XX-X-S-LL SHOWN
(SAME AS FIG. 1 EXCEPT AS SHOWN)
FIG. 2
EVEN POSITION PART
■ = CRIMP LOCATION
IF CRIMP POSITION IS POLARIZED, MOVE ONE POSITION TOWARD PIN 1
LOCKING LEAD OPTION
+.015
(No. OF POSITIONS x .200 [5.08] - .100 [2.54]-.010 )
.200 5.08
BTSW-210-XX-X-S SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
FIG 3
"E"
"D"
REF
C
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
IN-PROCESS 1
* = NOT RELEASED
F:\DWG\MISC\MKTG\BTSW-XXX-XX-X-S-XX-XX-MKT.SLDDRW
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
.025 [.64] SQ. SINGLE ROW, DOUBLE -RA POST ASM
BTSW-XXX-XX-X-S-XX-XX
BY:
J. BROWNING 04/27/2010
SHEET
2
OF
2
