Silicon NPN Power Transistor
2SD110
DESCRIPTIONV
·High
Power Dissipation-
: P
C
= 100W@T
C
= 25
℃
·High
Current Capability-
: I
C
= 10A
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for power amplifier , power switching ,DC-DC
converter and regulator applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
E
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Emitter Current-Continuous
Base Current-Continuous
Collector Power Dissipation @T
C
=25℃
Junction Temperature
Storage Temperature
VALUE
130
110
10
10
10
3
100
150
-65~150
UNIT
V
V
V
A
A
A
W
℃
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
(BR)EBO
V
CE
(sat)
V
BE
(sat)
I
CBO
I
EBO
h
FE-1
h
FE-2
f
T
C
OB
PARAMETER
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
Output Capacitance
CONDITIONS
I
C
= 10mA ; R
BE
=
∞
I
E
= 1mA ; I
C
= 0
I
C
= 5A; I
B
= 1A
I
C
= 5A; I
B
= 1A
V
CB
= 50V; I
E
= 0
V
EB
= 10V; I
C
=0
I
C
= 1A ; V
CE
= 5V
I
C
= 5A ; V
CE
= 5V
I
C
= 1A ; V
CE
= 10V
I
E
= 0 ; V
CB
= 50V; f= 1MHz
30
10
1
200
MIN
110
10
TYP.
2SD110
MAX
UNIT
V
V
1.5
2.5
0.5
10
300
V
V
mA
mA
MHz
pF
h
FE-2
Classifications
R
30-90
O
50-150
Y
100-300
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not
designed for use in equipment which require specialized quality and/or reliability, or in equipment
which could have applications in hazardous environments, aerospace industry, or medical
field. Please contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
isc website
：
www.iscsemi.com
2
isc & iscsemi
is registered trademark
