NISSEI
NISSEI / ARCOTRONICS
CLASS X2 (EN132400)
Type
R46
METALLIZED POLYPROPYLENE FILM CAPACITOR
Features
For interference suppression and.
Light and small in size.
Pitch 10mm available now for 0.010microF to 0.047 microF.
Specifications
Temp range
Rated Voltage
Capacitance
Cap. Tolerance
Tangent of loss angle
-40 to +110C
275 V.a.c
0.010 to 4.7microF (E-6)
+/-10%(K) +/-20%(M)
0.001 less at 25C +/-5C 1kHz
Between terminals
Withstand voltage
Between terminal and case
Insulation resistance
Impulse voltage
Between terminals
1500 V.a.c 1 min
1810 V.d.c 1 min
2500 V.a.c 2 sec
Approvals
UL
UL 1414 (up to 1 microF)
UL 1283
CSA C22.2 No.1 (up to 1 microF)
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
CB
EN 132400
GB/T14472
File No.E97797
File No.E85238
File No.LR 83890
File No.119624
File No.9839064
File No.99-01226
File No.P99100831
File No.F11586
File No.99, 7 70207,01
File No.V4413
File No.IT-1524
File No.1275-005
File No.CH0045034
Across-the-line
Electromagnetic
Interference Filters
Across- the- line
Class X2
Class X2
Class X2
Class X2
Class X2
Class X2
Class X2
Class X2
Class X2
Class X2
CSA
VDE
SEMKO
DEMKO
NEMKO
FIMKO
SEV
IMQ
OVE
CCEE
C =< 0.33microF 100,000M-Ohm more
C > 0.33microF 30,000S(M-Ohm)
IEC 60384-14 amendment A1: 1995
2nd Ed.’93 (EN 132400) PV =< 2.5kV
Dimensions (mm)
Cap
Parts number
*1
*2
275 V.a.c
Max dv/dt at
390V.d.c(V/micro s)
Bulk
(microF) W+/-0.5 H+0.2/-0.3 T+/-0.2 P+/-0.4 d+/-
0.05
13.0
13.0
13.0
13.0
13.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
26.5
26.5
26.5
26.5
26.5
26.5
32.0
32.0
32.0
32.0
32.0
32.0
32.0
11.0
11.0
11.0
11.0
12.0
11.0
11.0
11.0
11.0
11.0
11.0
12.0
13.5
16.0
19.0
15.0
15.0
16.0
17.0
18.5
22.0
17.0
17.0
20.0
22.0
28.0
33.0
37.0
5.0
5.0
5.0
5.0
6.0
5.0
5.0
5.0
5.0
5.0
5.0
6.0
7.5
10.0
11.0
6.0
6.0
7.0
8.5
10.0
13.0
9.0
9.0
11.0
13.0
14.0
18.0
22.0
13.0
16.0
19.0
10.0
10.0
10.0
10.0
10.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
22.5
22.5
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
27.5
27.5
27.5
37.5
37.5
37.5
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1.0
1.0
1.0
R46 KF 2100 -- M1 - 103 0.010
R46 KF 2150 -- M1 - 153 0.015
R41 KF 2220 -- M1 - 223 0.022
R46 KF 2330 -- M1 - 333 0.033
R46 KF 2470 -- M1 - 473 0.047
R46 K I 2100 -- 01 - 103 0.010
R46 K I 2150 -- 01 - 153 0.015
R46 K I 2220 -- 01 - 223 0.022
R46 K I 2470 -- 01 - 473 0.047
R46 K I 2680 -- 01 - 683 0.068
R46 K I 3100 -- M1 M 104 0.10
R46 K I 3150 -- M2 M 154 0.15
R46 K I 3220 -- M2 M 224 0.22
R46 K I 3330 -- M1 - 334 0.33
R46 K I 3470 -- M1 - 474 0.47
R46 KN 3150 -- 01 - 154 0.15
R46 KN 3220 -- M1 - 224 0.22
R46 KN 3330 -- M1 - 334 0.33
R46 KN 3470 -- M1 - 474 0.47
R46 KN 3680 -- M2 - 684 0.68
R46 KN 4100 -- M1 - 105 1.0
R46 KR 3470 -- 01 - 474 0.47
R46 KR 3680 -- 01 - 684 0.68
R46 KR 4100 -- M1 - 105 1.0
R46 KR 4150 -- 01 - 155 1.5
R46 KR 4220 -- M1 - 225 2.2
R46 KR 4330 -- M2 - 335 3.3
R46 KR 4470 -- M1 - 475 4.7
500
500
500
500
500
400
400
400
400
400
400
400
400
400
400
200
200
200
200
200
200
150
150
150
150
150
150
150
100
100
100
±2
±5
±2
+5
±
Taped
Insulated Rigid Leads
Insulated Flexible Leads 0.5mm
2
R46 KW
-- M1 - 225 2.2
41.5
24.0
4220
R46 KW
-- M1 - 335 3.3
41.5
28.5
4330
R46 KW
-- M1 - 475 4.7
41.5
32.0
4470
*1 Lead/Taping configuration code
*2 Capacitance tolerance：K(+/-10%) M(+/-20%)
Lead/Taping configuration
Lead length
(mm)
Taping style
P2 (mm)
12.70
19.05
12.70
19.05
Fig. (No.)
1
2
1
2
Pitch (mm)
10.0/15.0
22.5
10.0/15.0
22.5/27.5
Lead/Taping
configuration code
*1
Ammo-pack
Ammo-pack
Reel 355mm
Reel 500mm
Bulk, short leads
Bulk, long leads
Bulk, insulated rigid leads
Bulk, insulated flexible leads
*Ammo-pack is the preferred packaging for taped version.
4+2
30+5
30+5
150+/-5
DQ
DQ
CK
CK
00
50
51
52
When using our capacitors, please consider the application notes on pages 8-15 and contact Nissei for any additional technical specifications relating to the limits of our performance
