isc
Silicon NPN Power Transistor
DESCRIPTION
·Excellent
Safe Operating Area
·Collector-Emitter
Saturation Voltage-
: V
CE(sat
)= 1.0 V(Max)@ I
C
= 5A
·Collector-Emitter
Sustaining Voltage-
: V
CEO(SUS)
= 120V(Min)
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for general-purpose switching and amplifier
applications
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current
Collector Power Dissipation@T
C
=25℃
Junction Temperature
Storage Temperature
VALUE
200
120
6
10
15
4
62
150
-65~150
UNIT
V
V
V
A
A
A
W
℃
℃
BU127
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBO
L
V
CEO(SUS)
V
CE
(sat)
V
BE
(sat)
I
CBO
I
EBO
h
FE
f
T
t
off
PARAMETER
Collector-Emitter Sustaining Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Base Cutoff Current
Emitter Cutoff Current
DC Current Gain
Current Gain-Bandwidth Product
Turn-Off Time
CONDITIONS
I
C
= 50mA ; I
B
= 0
I
C
= 5A; I
B
= 0.5A
I
C
= 5A; I
B
= 0.5A
V
CB
=200V; I
E
= 0
V
EB
= 6V; I
C
= 0
I
C
= 5A ; V
CE
= 1V
I
C
= 0.5A ; V
CE
= 10V
I
C
= 5A; I
B
= 0.5A
40
60
0.4
MIN
120
TYP
BU127
MAX
UNIT
V
1.0
1.2
0.1
0.1
V
V
mA
mA
MHz
μs
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
