Noise Suppression Products/EMI Suppression Filters > For Automotive > Common Mode Choke Coil for Automotive
Data Sheet
1
For Automotive
Common Mode Choke Coil for Automotive
DLW43S Series (1812 Size)
c
Dimensions
DLW43S_XK Series
c
Dimensions
DLW43S_XP Series
2.6±0.2
(0.30)
2.7±0.2
4.5±0.2
(0.8)
3.2±0.2
4.5±0.2
(0.8)
3.2±0.2
(1)
(2)
(1)
(2)
(4)
(3)
(0.6): 100μH
(0.7): 11, 22, 51μH
(in mm)
(4)
(3)
(0.6)
(in mm)
c
Impedance-Frequency Characteristics (Main Items)
DLW43S_XK Series
100000
DLW43SH510XK2
10000
Common mode
Impedance (Ω)
DLW43SH101XK2
c
Impedance-Frequency Characteristics (Main Items)
DLW43S_XP Series
10000
Common mode
1000
DLW43SH101XP2
Impedance (Ω)
1000
DLW43SH220XK2
DLW43SH110XK2
100
DLW43SH10XK2
10
DLW43SH510XK2
DLW43SH220XK2
DLW43SH110XK2
1
1
10
Frequency (MHz)
100
Differential mode
100
10
DLW43SH101XP2
1
Differential mode
0.1
0.1
1
Frequency (MHz)
10
(0.30)
100
c
Equivalent Circuit
c
Packaging
Code
L
K
B
Packaging
180mm Embossed Tape
330mm Embossed Tape
Bulk(Bag)
Minimum Quantity
500
2500
100
(1)
(2)
(4)
(3)
No polarity.
Continued on the following page.
oThis
data sheet is applied for CHIP COMMON MODE CHOKE COIL used for Automotive Electronics equipment for your design.
!Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our products in it
may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2014.9.8
Murata Manufacturing Co., Ltd.
http://www.murata.com/
Downloaded from
Arrow.com.
Noise Suppression Products/EMI Suppression Filters > For Automotive > Common Mode Choke Coil for Automotive
Data Sheet
Continued from the preceding page.
2
c
Rated Value (p: packaging code)
Part Number
DLW43SH110XK2p
DLW43SH220XK2p
DLW43SH510XK2p
DLW43SH101XK2p
DLW43SH101XP2p
Number of Circuit: 1
Common Mode Inductance
11µH -30%/+50% (at 0.1MHz)
22µH -30%/+50% (at 0.1MHz)
51µH -30%/+50% (at 1MHz)
100µH -30%/+50% (at 1MHz)
100µH -30%/+80% (at 0.1MHz)
Rated Current Rated Voltage Insulation Resistance (min.) Withstand Voltage DC Resistance
360mA
310mA
230mA
200mA
170mA
50Vdc
50Vdc
50Vdc
50Vdc
50Vdc
10M ohm
10M ohm
10M ohm
10M ohm
10M ohm
125Vdc
125Vdc
125Vdc
125Vdc
125Vdc
0.5ohm max.
0.6ohm max.
1.0ohm max.
2.0ohm max.
2.0ohm max.
Operating
Temperature Range
-40 to +125°C
-40 to +125°C
-40 to +125°C
-40 to +125°C
-40 to +125°C
c !Caution/Notice
!Caution
(Rating)
1. Do not use products beyond the rated current and rated
voltage as this may create excessive heat and
deteriorate the insulation resistance.
2. Be sure to provide an appropriate fail-safe
function on your product to prevent a second damage
that may be caused by the abnormal function or
the failure our product.
Notice
Solderability of Tin plating termination chip might be
deteriorated when low temperature soldering profile
where peak solder temperature is below the Tin melting
point is used. Please confirm the solderability of Tin
plating termination chip before use.
oThis
data sheet is applied for CHIP COMMON MODE CHOKE COIL used for Automotive Electronics equipment for your design.
!Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our products in it
may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2014.9.8
Murata Manufacturing Co., Ltd.
http://www.murata.com/
Downloaded from
Arrow.com.
