2 Watts
IL Series
•
•
•
•
•
•
•
Single Output
SIP Package
1000 VDC Isolation
Optional 3000 VDC Isolation
MTBF >1.2 MHrs
40 °C to +85 °C Operation
3 Year Warranty
DC DC
xppower.com
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Reverse
Voltage Protection
Input Filter
• Nominal ±10%
• 20 mA pk-pk through 12 µH inductor,
5 Hz to 20 MHz
• None
• Capacitor
Input
Voltage
No Load
Input Current
35 mA
35 mA
35 mA
35 mA
35 mA
35 mA
20 mA
20 mA
20 mA
20 mA
20 mA
25 mA
10 mA
10 mA
10 mA
10 mA
10 mA
10 mA
7 mA
7 mA
7 mA
7 mA
7 mA
7 mA
Output
Voltage
3.3 V
5.0 V
9.0 V
12.0 V
15.0 V
24.0 V
3.3 V
5.0 V
9.0 V
12.0 V
15.0 V
24.0 V
3.3 V
5.0 V
9.0 V
12.0 V
15.0 V
24.0 V
3.3 V
5.0 V
9.0 V
12.0 V
15.0 V
24.0 V
Output
Current
400 mA
400 mA
222 mA
168 mA
132 mA
84 mA
400 mA
400 mA
222 mA
168 mA
132 mA
84 mA
400 mA
400 mA
222 mA
168 mA
132 mA
84 mA
400 mA
400 mA
222 mA
168 mA
132 mA
84 mA
Efficiency
71%
77%
80%
82%
82%
82%
72%
78%
82%
84%
84%
82%
74%
80%
84%
84%
84%
84%
72%
78%
82%
80%
82%
82%
Model
Number
(1)
IL0503S
IL0505S
IL0509S
IL0512S
IL0515S
IL0524S
IL1203S
IL1205S
IL1209S
IL1212S
IL1215S
IL1224S
IL2403S
IL2405S
IL2409S
IL2412S
IL2415S
IL2424S
IL4803S
IL4805S
IL4809S
IL4812S
IL4815S
IL4824S
5 VDC
Output
Output Voltage Range
Minimum Load
Line Regulation
Load Regulation
•
•
•
•
See table
None
(2)
1.2%/1%
∆
Vin
±10%, 20-100% load change
(3.3 V models: ±20%)
±3%
150 mV pk-pk max, 20 MHz bandwidth
0.02%/°C
470 µF
12 VDC
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Maximum Capacitive
•
Load
24 VDC
48 VDC
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
• See table
• 1000 VDC minimum
(3000 VDC -H option)
• 10
9
Ω
• 60 pF typical
• Variable, 70 KHz typical
• >1.21 MHrs to MIL-HDBK-217F
at 25 °C, GB
Mechanical Details
0.46
(11.68) max
0.01
(0.25) max
0.30
(7.62)
-Vin +Vin -Vout +Vout
BOTTOM VIEW
0.08
(2.03)
0.29
(7.50)
Environmental
Operating Temperature
Storage Temperature
Case Temperature
Cooling
Notes
1.
2.
3.
4.
5.
Add suffix ‘H’ to model for 3000 VDC isolation.
Operation at no load will not damage unit but it may not meet all specifications.
All dimensions in inches (mm).
Pin pitch tolerance: ±0.014 (±0.35), Case tolerance: ±0.02 (±0.5)
Weight: 0.004 lbs (1.8 g)
0.12
0.10
(3.05) min (2.54)
•
•
•
•
-40 °C to +85 °C
-40 °C to +125 °C
100 °C max
Convection-cooled
0.40
(10.16) max
0.02
(0.51)
0.02
(0.51)
26-Oct-12
