Single Channel Integrated Tap
Monitors
ITMS Series
Product Description
Oplink’s Single Channel Integrated Tap Monitor (ITMS) is a hybrid component that integrates
a flat spectral response of a thin-film tap with a high sensitivity PIN photodiode for power
monitoring applications.The ITMS minimizes component assembly costs and module footprint
while increasing module design efficiency by facilitating fiber management.
The ITMS integrates the functionality of an optical coupler and a photodiode while delivering
low insertion loss and low dark current with high temperature stability over a wide wavelength
range. It is compact and easy to mount on a PCB board for module and network system use.
Applications include DWDM channel power monitoring, optical network switching/protection
monitoring, re-configurable optical add/drop multiplexers, and gain/attenuation monitoring in
amplifier systems.
Oplink can provide customized designs to meet specialized feature applications. Also, Oplink
offers modular assemblies that integrate other components to form a full function module or
subsystem.
Performance Specification
ns
Parameters
Specification
Unit
Features
Operating Wavelength Range
Insertion Loss (@ λ
Op
, T
Op
, All SOP, exclude
connector)
Polarization Dependent Loss
Return loss (exclude connector)
Responsivity (relative to nominal power at
input port)
or 1550nm)
1260~1360
2%
5%
10%
1510~1610
mm
dB
dB
dB
2-/3-pin Package Easily Mounted
on a PCB
Flat and Broad Operating
Wavelength Range
Low Insertion Loss and PDL
Low Dark Current
Various Tap Ratios Available
High Temperature Stability with
Hermetically Sealed Photodiode
Through
≤ 0.4
≤ 0.6
≤ 0.9
≤ 0.05
≥ 45
Tapped
Monitoring
2%
5%
10%
10~23
26~59
52~110
≤ 0.3
≤ 0.1
≤ 10
≤ 2.5
≤ 20
≤ 10
14~25
35~65
70~120
mA/W
dB
dB
nA
nA
V
mA
dBm
°C
°C
Responsivity Temperature Dependence
(@1310nm
Responsivity Polarization Dependence
PD Dark Current (@ 70°C, -5V bias)
PD
Reverse Voltage
Forward Current
Input Optical Power
Conditions
2%
5%
10%
0.5G Bandwidth
2.0G Bandwidth
Applications
DWDM channel monitoring
Optical network switch/protection
monitoring
Re-configurable optical add/drop
multiplexers
Gain/attenuation monitoring in
amplifier systems
EDFAs and Raman amplifiers
≤ 21
≤ 16
≤ 12
-5 to +70
-40 to +85
SMF-28
Operating Temperature Range
(<85%RH, Non-condensing)
Storage Temperature Range
(<85%RH, Non-condensing)
Fiber Type
R06.20080813
Single Channel Integrated Tap Monitors
ITMS Series
Mechanical Drawing / Package Dimensions (dimension in mm)
Standard Package (P1, Bare Fiber or Loose Tube)
Miniature Package (P4, Bare Fiber only)
Input(Black)
Note:
Anode is connected to the metal housing.
Standard Package Pin Assignment
Pin 1:
Pin 2:
Pin 3:
Anode
Cathode
Case Ground
Miniature Package (P5, Loose Tube only)
Input(Blue)
Output(White)
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Note:
Anode is connected to the metal housing.
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
ITMS
0
0
Tap Ratio
2/98 = 02
5/95 = 05
10/90 = 10
Bandwidth
0.5G= 05
2.0G= 20
Fiber Length
0.5meter= H
1.0meter= 1
1.5meter= 5
2.0meter= 2
Connector
Type
None = 1
FC/PC=2
FC/SPC=3
FC/APC=4
SC/PC=5
SC/SPC=6
SC/APC=7
ST=8
LC=9
MU=A
Wavelength
1310/1550nm= D
1310nm= 3
C+L band= E
Package & Fiber Type
P1+250µm bare fiber =11
P1+900µm loose tube =12
P4+250µm bare fiber = 41
P5+900µm loose tube = 52
RoHS:
1. Add “G” to the end of the above PN for RoHS 6 Requirement.
