BCM5701
PRODUCT
®
Brief
O F
B E N E F I T S
10/100/1000BASE-T CONTROLLER WITH INTEGRATED TRANSCEIVER
B C M 5 7 0 1
F E AT U R E S
S U M M A R Y
LAN on Motherboard
•
Single-chip solution forcard (NIC) applications (LOM)
and network interface
• Integrated 10BASE-T/100BASE-TX/1000BASE-T transceivers
• 10/100/1000 tri-speed MAC
• Host interfaces
- PCI v2.2, 32/64-bit, 33/66-MHz
- PCI-X v1.0, 64-bit, 133-MHz
• MII/GMII/TBI interfaces for external transceivers
• Ultra-deep, 96-KB on-chip packet buffer
• Dual high-speed RISC cores with 16-KB caches
- Programmable, in-line packet classification
• SMBus controller
• On-chip power circuit controller and Wake on LAN power
switching circuit
Industry’s
•
(power andfirst 10/100/1000 MAC/PHY solution
space optimized for LOM and low profile
•
• To existing 10/100 network infrastructure
•
Futureproof
• PCI-X interface, on-chip programmable CPUs, ASF support
Performance focused
•
CPU utilization) (optimized for throughput and
• Adaptive interrupts
• PCI-X eliminates PCI bottlenecks
• Ultra-deep, 96-KB packet buffer lowers CPU utilization and
averts PCI congestion
• CPU task offloads
• To existing PCI-based desktop and server platforms
NIC applications)
Completely backward compatible:
features
•
Performance
checksum
• TCP, IP, UDP
•
Robust manageability
• PXE 2.0 remote boot
• TCP segmentation
• CPU task offload
• Adaptive interrupts
• Ultra-deep, 96-KB packet buffer
manageable
•
•
Robust and highly
Wake-on LAN, ASF 1.0
PXE 2.0, ACPI 1.1,
•
Advanced features
jumbo frames
• VLAN, priority queuing,
• Integrated cable testing (link quality, length, pair skew, pair
polarity, pair swap
)
•
Advanced network features
2 priority encoding; support for
• Priority queuing (802.1p Layer
four priority queues)
• Virtual LANs (802.1q VLAN tagging; support for up to 64
VLANs)
• Jumbo frames (9 KB)
• 802.3x flow control
• Alert specification forum (ASF 1.0 support)
• Wake-on LAN
• Statistics gathering (SNMP MIB II, Ethernet-like MIB,
Ethernet MIB (802.3x, clause 30))
• Comprehensive diagnostic and configuration software suite
• ACPI 1.1a compliant (multiple power modes)
• Wake on LAN
Server-class
•
features reliability, availability and performance
• Link aggregation and load balancing
- Switch dependent
• 802.3ad (LACP), generic trunking (GEC/FEC)
- Switch and NIC independent
• Smart Load Balancing™ (unique technology that supports
heterogeneous teams, and can operate with any switch)
• Failover
- Smart Load Balancing™ allows heterogeneous failover
• Hot Plug PCI support
• RISC processors for advanced packet classification
features
•
•
Advanced server
(802.3ad, GEC/FEC, Smart Load
Link aggregation
Balancing™ (supports heterogeneous teams))
• Heterogeneous, mixed-speed failover
• Hot-Plug PCI support
•
•
Low power for zero airflow implementations
0.18 µm CMOS design
•
•
Space savings for LOM
300-pin HBGA package
• No external memory
• Integrated power circuitry
• Advanced Power Management
•
Low-power, 0.18 µm CMOS design
•
300-pin HBGA package
•
3.3V I/Os (5V tolerant)
•
JTAG
B C M 5 7 0 1
O V E R V I E W
RX
10/100/1000
PHY
TX
10/100/1000
MAC
Buffer
Memory
Memory
Controller
Dual Processor
PCI/PCI-X
PLL
32-KB
Memory
EEPROM
Control
PCI/PCI-X
Bus
LED Control
SMBus
PLL
PCI
CLK
LED Signals
SMB Interface EEPROM Interface
The
BCM5701
is a fully-integrated 10/100/1000BASE-T
Gigabit Ethernet Media Access Control and physical layer
transceiver solution for high-performance network
applications. The
BCM5701
is a highly integrated solution
combining triple-speed, IEEE 802.3 compliant media access
controller (MAC), PCI and PCI-X bus interfaces, on-chip
buffer memory, and integrated physical layer transceiver in a
single device. The
BCM5701
is fabricated in a low-voltage,
0.18 µm CMOS process, providing a low-power system solution.
By itself the
BCM5701
provides a complete, single-chip Gigabit
Ethernet NIC or LOM solution.
The
BCM5701
includes a 10/100/1000-Mbps Ethernet MAC
with full/half-duplex capability at all speeds, and a 10/100/1000
copper PHY. Support for the following 802.3 functions is
featured in the MAC: VLAN tagging, layer 2 priority encoding,
link aggregation, and full-duplex flow control.
The device provides both PCI v2.2 and PCI-X v1.0 bus
interfaces. The
BCM5701
provides a large on-chip buffer
memory for stand-alone operation. Dual on-chip, high-
performance processors enable custom frame processing
features, including TCP segmentation.
The transceiver is fully compatible with the IEEE 802.3 standard
for auto-negotiation of speed. Additionally, several Plug and Play
enhancements have been added to make the device even more
user friendly. A link quality indicator LED gives installers an
Broadcom
®
, the pulse logo and
Connecting everything
®
are trademarks of
Broadcom Corporation and/or its subsidiaries in the United States and certain other countries.
All other trademarks are the property of their respective owners.
instant visual indication if there are any issues with the wiring
plant supporting operation at the desired speed. This includes
physical wiring defects or channel conditions, such as excessive
cable length, return loss, crosstalk, echo, and noise. Broadcom’s
remote cable management and diagnostics software can be used
with the device to provide remote management of the cable and
a first level of diagnostics and fault isolation. The
BCM5701
continually monitors various channel conditions. The optional
wire speed capability allows the
BCM5701
to force auto-
negotiation to be automatically limited by the speed that the
channel can reliably support, rather than the performance of the
end equipment.
Target Applications of the BCM5701
Network Interface Card (NIC) designs
Single Port
10/100/1000
BASE_T
1000
BASE_SX
1000
BASE_LX
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
LAN on Motherboard (LOM) designs
Single Port
10/100/1000
BASE_T
10/100/1000
BASE_T
PCI 2.2 LOM
PCI-X v1.0 LOM
PCI 2.2 LOM
PCI-X v1.0 LOM
Dual Port
Dual Port
10/100/1000
BASE_T
®
BROADCOM CORPORATION
16215 Alton Parkway, P.O. Box 57013
Irvine, California 92619-7013
© 2003 by BROADCOM CORPORATION. All rights reserved.
5701-PB08-R-06.25.03
Phone: 949-450-8700
FAX: 949-450-8710
Email: info@broadcom.com
Web: www.broadcom.com
