JZC-36F
SUBMINIATURE
INTERMEDIATE
POWER RELAY
Features
•
10A
switching capabilities
and SPDT configurations
File No.:E133481
•
SPST-NO
•
Sealed
and Unsealed type available
File No.:CH0039695-99
CONTACT DATA
Contact Arrangement
Initial Contact Resistance Max.
Contact Material
1A, 1C
100m (at 1A 6VDC)
Silver alloy
10A 250VAC
Contact Rating (Res. Load)
10A 30VDC
TV-5 125VAC
Max. switching voltage
Max. switching current
Max. switching power
250VAC/30VDC
10A
2500VA/300W
10A 250VAC
UL/CUR rating
10A 30VDC
TV-5 125VAC
Mechanical life
Electrical life
1 x 10
7
OPS
1 x 10
5
OPS
COIL
Coil power
Sensitive:0.25W
Standard:0.53W
COIL DATA
Standard Type
Nominal
Voltage
VDC
5
6
9
12
18
Pick-up
Voltage
VDC
3.75
4.50
6.75
9.00
13.5
18.0
36.0
Drop-out
Voltage
VDC
0.25
0.30
0.45
0.60
0.90
1.20
2.40
Sensitive Type
Nominal Pick-up
Voltage Voltage
VDC
VDC
5
6
9
12
18
24
48
3.75
4.50
6.75
9.00
13.5
18.0
36.0
Drop-out
Voltage
VDC
0.25
0.30
0.45
0.60
0.90
1.20
2.40
Max.
allowable
Voltage
VDC(at 20 )
6.5
7.8
11.7
15.6
23.4
31.2
62.4
Coil
Resistance
100
145
325
575
1300
2310
10%
10%
10%
10%
10%
10%
Max.
Coil
allowable
Resistance
Voltage
VDC(at 20 )
6.5
7.8
11.7
15.6
23.4
31.2
62.4
47
68
155
270
620
1080
4400
10%
10%
10%
10%
10%
10%
10%
General Purpose Power Relays
JZC-36F
24
CHARACTERISTICS
Initial Insulation Resistance
Between coil and
Dielectric Contacts
Strength Between open
contacts
Operate time (at nomi. Volt.)
Release time (at nomi. Volt.)
Temperature rise
Humidity
Ambient temperature
Shock
Resistance
Functional
Destructive
1000M (500VDC)
NO: 4000VAC 1min
NC: 3000VAC 1min
15ms
5ms
Max. 55
(at nomi. volt.)
35 to 85%RH
-40
to 70
200 m/s
2
1000 m/s
2
10 to 55 Hz(Amplitvde
of 1.5mm)
PCB
Approx.12g
Sealed & Unsealed
48
Vibration Resistance
Termination
Unit weight
Construction
HONGFA RELAY
ISO9001/QS9000/ISO14000
CERTIFIED
64
ORDERING INFORMATION
JZC-36F / 012
Type
Coil voltage
5, 6, 9, 12, 18, 24, 48VDC
Contact arrangement
H:1A(SPST-NO) Z:1C(SPST-NC)
Structure
Nil: Unsealed
Coil Power
NIL: Standard
S : Sealed
L: Sensitive
T:AgSnO
H
S
L
T
Contact Material
Nil:AgCdO
OUTLINE DIMENSIONS, WIRING DIAGRAM AND PC BOARD LAYOUT
Outline Dimensions
H
23.8
9.5
24.5
HS
10.5
24.5
ZS
10.5
General Purpose Power Relays
24.
5
4
24.
5
4
0.8
0.4 0.3
0.8
4
0.4
0.3
0.8
24.
5
0.4
0.3
23.8
Z
9.5
H(S)
Wiring Diagram
Z(S)
JZC-36F
24.
5
16.5
3.5
16.5
3.5
4
PCB layout
7.5
4 Ø1.3
-
7.5
0.8
0.4 0.3
5 Ø1.3
-
3.5
CHARACTERISTICS CURVE
LIFE CURVE
Operations (X10000 OPS)
100
50
250VAC/30VDC(Resistive)
COIL TEMPERATURE RISE
60
50
)
Temperature(
40
30
Standard
10
5
Sensitive
20
10
0
5
10
15
0
70
80
90
100
110
120
Contact Current (A)
Percentage Of Nominal Coil Voltage
65
