C U I Stack, Inc.,
1997
0.63
(16)
Ø0.787
(Ø20)
Ø0.079
(Ø2)
Ø0.157
(Ø4)
0.531
(13.5)
0.492
(12.5)
OUTPUT WAVEFORM
T
2-M2x3
T
±
T
8
4
SPECIFICATIONS
OUTPUT CIRCUIT
270Ω
STANDARD RESOLUTIONS
+5V
Collector
RED
BROWN
A=WHITE
B=GREEN
BLACK
Bore Diameter:
1=Ø1mm
15=Ø1.5mm
2=Ø2mm
Channels:
A = Single Channel
AB = Dual Channel
ELECTRICAL
1. Input Voltage: 5VDC ±10%
2. Current Draw: 30mA max
3. Response Frequency: 20kHz
4. Output Waveform: Near sine, A/B
MECHANICAL
1. Max Shaft Load, radial: 0.2 kgf
axial: 0.2 kgf
2. Moment of Inertia: 2gf•cm
2
3. Angular Acceleration: 1x10
4
rad/S
2
4. Max Slewing Speed: 6000 RPM
5. Starting Torque: 3 gf•cm max.
6. Rotational Life: 1 x 10
7
rpm•hrs
ENVIRONMENTAL
1. Operating Temp: 0° to +50° C
2. Storage Temp: -20° to +80° C
3. Humidity:
≤
90% RH, no condensation
4. Vibration: 55 Hz, 1.5 mm, 2 hrs
5. Shock: 50G, 11ms, 3 axes, 3 reps
100
200
300
100PPR
200PPR
300PPR
SEH(_)17-XXX
200Ω
~3kΩ
A/B out
0V
ORDERING INFORMATION
SEH(_)17-_ _ _-_ _
Resolution(PPR)
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
JAS
PART NO.
06/08/00
06/08/00
REV.
SEH(X)17-XXX-XX
≤1Vpp
