DATA SHEET
SEMICONDUCTOR
KBL005 THRU KBL10
TECHNICAL SPECIFICATIONS OF SINGLE-PHASE
SILICON BRIDGE RECTIFIER
VOLTAGE RANGE-50 to 1000 Volts CURRENT-4.0 Amperes
FEATURES
•Ideal
for printed circuit board
•Surge
overload rating: 200 Amperes peak
•Molded
structure
•This
seeries is UL recognized under component index, file number E315292
KBL Unit:inch(mm)
•High
temperature soldering : 260
O
C / 10 seconds at terminals
•Pb
free product at available : 99% Sn above meet RoHS
environment substance directive request
.591(15.0)
.567(14.4)
MECHANICAL DATA
•Case:Molded
plastic
•Epoxy:
UL 94V-0 rate flame retardant
•Lead:
MIL-STD-202E,Method 208 guaranteed
•Polarity:
Symbols molded or marked on body
•Mounting
position: Any
•Weight:
4.8 grams
max
91
3
1.0
25.4
1.1
27.9
TRCEKPI
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
•Ratings
at 25
℃
ambient temperature unless otherwise specified.
•Single
phase, half wave, 60 Hz, resistive or inductive load.
•For
capacitive load, derate current by 20%.
PARAMETER
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Output TA = 50℃
Peak Forward Surge Current 8.3 ms single half
sine-wave
superimposed on rated load (JEDEC method)
Maximum Forward Voltage Drop per element at 4.0A
DC
Maximum DC Reverse Current at
Rated DC Blocking Voltage per
element
I2t Rating for Fusing(t<8.3ms)
Typical Junction Capacitance(Note1)
Typical Junction Resistance(Note2)
Operating Temperature Range
Storage Temperature Range
@TA = 100℃
@TA = 25℃
IR
500
I2t
CJ
RθJA
TJ
TSTG
93
40
19
-55 to + 150
-55 to + 150
A2Sec
pF
℃/W
℃
℃
VF
1.0
5
µAmp
Volts
SYMBOL
KBL005
VRRM
VRMS
VDC
IO
IFSM
50
35
50
KBL01
100
70
100
KBL02
200
140
200
KBL04
400
280
400
4.0
KBL06
600
420
600
KBL08
800
560
800
KBL10
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
150
A
NOTES: 1.Measured at 1 MHz and applied reverse voltage of 4.0 volts
2.Thermal Resistance from Junction to Ambient with units mounted on 3.0x3.0xx0.11”(7.5x7.5x0.3cm)AL plate.
http://www.yeashin.com
1
REV.02 20120305
