AUK CORP.
Infrared Emitting Diode
KEL-0315CK
Description
The KEL-0315CK is a ultra bright light & surface mount type
infrared emitting diode. It’s ideal for various kinds of
optical emittersr such as touch panels for C/D, ATM,
Car navigation system and even AV Instrument and
various types of disk driver.
Features
Compact and thin package
SMD type
Reflow soldering
RoHS & High reliability package
Pin Connection
1. Anode
2. Cathode
Applications
Touch screen for ATM
Touch screen for Car navigation system
Touch screen for FA equipment
AV instrument
Various types of disk driver
Absolute Maximum Ratings
Parameter
Symbol
Min.
-
-
-
-
-20
-30
-
Max.
[T
A
= 25
Max.
]
Reverse Voltage
Forward Current
Power Dissipation
Pulse Forward Current*1
Operating Temperature
Storage Temperature
Soldering Temperature*2
*2 : MAX 10s
V
R
I
F
P
D
I
FP
Topr
Tstg
Tsol
5
50
75
0.5
85
85
260
V
㎃
½
A
*1 : Pulse Width : Tw
≤
100㎲, Periode : T = 10㎳
The contents of this data sheet are subject to change without advance notice for the purpose of improvement.
When using this product, would you please refer to the latest specifications.
KEL-0315CK
Electrical Characteristics
Parameter
Forward Voltage
Reverse Current
Radiant Intensity
Peak Emission Wavelength
Spectral Bandwidth 50%
Half Angle
Symbol
V
F
I
R
P
O
λ
P
∆λ
∆θ
Conditions
I
F
=20mA
V
R
=5V
I
F
=20mA
I
F
=20mA
I
F
=20mA
-
Min.
-
-
2.2
-
-
-
Typ.
1.2
-
3.0
940
45
±15
Max.
1.5
10
-
-
-
[T
A
= 25
Unit
V
㎂
½/sr
㎚
㎚
deg
]
Ordering Information
Part Number
KEL-0315CK
Packaging Type
Tape and Reel
Quantity
3,000
Package Outline Dimensions
(Unit : mm)
Anode
Cathode
The contents of this data sheet are subject to change without advance notice for the purpose of improvement.
When using this product, would you please refer to the latest specifications.
