LM2902N/D
QUAD OPERATIONAL AMPLIFIER
DESCRIPTION
The
LM2902
consist of four independent,
high gain, internally frequency compensated
operational amplifiers which were designed
specifically to operate from a single power
supply over a wide voltage range. Operation
from split power supplies is also possible and
the low power supply current drain is
independent of the magnitude of the power
supply voltage. Application areas include transducer
amplifier, DC gain
blocks and all the
DIP14
Outline Drawing
LM2902
LM2902N
conventional OP amp circuits which now can
be easily implemented in single power
supply systems.
LM2902D
FEATURE
Larg e DC voltage gain: 100dB
Wide power supply range:
Vcc=3V~32V(or Vcc=±1.5V~±1 6 V)
Input common-mode voltage range includes ground.
Large output voltage swing :0V~Vcc-1.5V
Power drain suitable for battery operation
Internally frequency compensated for unity gain
Wide bandwidth(unity gain) 1MHz
Very low supply current drain(700µA)—essentially independent of supply voltage
Low input biasing current
Low input offset voltage
45nA
2mV and offset current
5nA
SOP1 4
Differential input voltage range equal to the power supply voltage
Compatible with all forms of logic
1/5
LM2902N/D
SCHEMATIC DIAGRAM
INTERNAL BLOCK DIAGRAM AND PIN CONNECTION
OUT1
1
IN1( - )
2
IN1( + )
3
Vcc
4
IN2( + )
5
IN2( - )
6
OUT2
7
- +
14
OUT4
1
- +
4
+ -
13
IN4( - )
12
IN4( + )
11
GND
10
IN3( + )
ABSOLUTE MAXIMUM RATINGS
(Ta=25
°C)
Characteristic
Power Supply Voltage
Differential Input Voltage
Input Voltage
Output Short Circuit to GND
DIP14
SOP14
Operating Temperature Range
Storage Temp erature
Power Dissipation
Symbol
Vcc
V
ID
V
IN
P
D
Topr
Tstg
Value
±16
or 32
32
-0.3~32
Continuous
1130
80 0
-20~+85
-65~150
Unit
V
V
V
mW
°C
°C
2/5
+ -
2
3
9
IN3( - )
8
OUT3
LM2902N/D
ELECTRICAL CHARACTERISTICS
(unless otherwise specified: Ta=25°C, Vcc=5V)
Characteristics
Input offset voltage
Input bias current
Input offset current
Input common-mose voltage range
Supply current
Larg e signal voltage gain
Common-mode rejection ratio
Test Conditions
I
I N ( + )
or I
I N -
,V
C M
=0V
I
I N ( + )
or I
I N -
,V
C M
=0V
Vcc=30V
Over full temperature range
RL=
∞
on all OP amps
Vcc=30V
Vcc=5V
Min. Typ.
2
20
5
0
Max.
7
250
50
Vcc-1.5
Unit
mV
nA
nA
V
mA
V/mV
dB
dB
mA
mA
µA
Vcc=15V,R
L
≥2
kΩ
DC,V
C M
=0V to Vcc-1.5V
Vcc=5V to 30V
V
I N +
=1V, V
I N -
=0V
Vcc=15V,Vo=2V
V
I N +
=0V, V
I N -
=1V
Vcc=15V,Vo=2V
V
I N +
=0V, V
I N -
=1V
Vcc=15V,Vo=200mV
Vcc=15V
Vcc=30V, R
L
=2kΩ
Vcc=30V, R
L
=10kΩ
Vcc=5V, R
L
=10kΩ
25
65
65
20
8
12
1.5
0.7
100
85
100
40
20
50
40
3
1.2
Power supply rejection ratio
Source
Output current
Sink
Short circuit to ground
Output voltage swing
V
OH
V
OL
60
mA
V
V
26
27
28
5
20
mV
3/5
