D-Sub Shells
DCP
DCM
DCG
E
D
C
B
A
Ordering example:
Shell
Size
09
15
25
DCP - 15
DCP Dimensions
Shell
Size
09
15
25
37
DCM Dimensions
A
31.4
40.2
53.8
69.2
67.1
B
48.3
48.3
48.3
48.5
48.5
C
9.5
9.0
9.0
11.0
14.0
E
19.4
28.0
42.0
57.8
55.0
A
31.0
39.5
55.0
B
36.0
32.3
38.5
C
6.80
9.70
10.70
D
20.1
18.5
27.5
E
20.1
27.8
40.8
Consult factory for DCG
50
Specifications
Dual Port Right Angle Stacked D-Sub Connector Series:
DP
Ratings:
Current
Dielectric strength
Contact resistance
Insulator resistance
5A
AC 1000V for 1 minute
30mΩ max. at DC 100mA
1000MΩ min. at DC 500V
Material:
Plastic
Color
Contact
Shell
Temperature
PBT Glass-filled, UL94V-0
Black
Brass or Phosphor Bronze
Tin
-55°C / +105°C, 260°C for 5 sec. (solder bath resistant)
ORDERING PROCEDURE
1
-
2
3
4
5
-
6
1) Series
2) Number of Positions (see chart for available positions)
Gender:
P = Male
S = Female
3) Number of Positions (see chart for available positions)
Gender:
P = Male
S = Female
4) Plating:
1 = Full Flash Gold
6 = Selective Flash Gold
7 = Selective 10µ Gold*
8 = Selective 30µ Gold*
* May Require Minimums
5) Spacing:
A = 15.88
B = 19.05
C = 22.86
6) Options:
A = 4-40 Jack screws assembled on connector
B = Board locks
G = Grounding straps
J = 4-40 Jack screws (bulk packed)
T = Threaded inserts
Please refer to following page for ordering example.
