ALUMINUM ELECTROLYTIC CAPACITORS
HXA type
(Warranty of 20,000 hours at 85°C)
Product Specifications
Features
• High-reliability series with the warranty of 20,000 hours realized
through improvement of the FXA type into a longer-life type
Items
Specifications
Temperature range
−40℃∼＋85℃
Capacitance tolerance
±20％（20℃,120Hz）
Rated voltage
350∼450V.DC
0.01 CV (μA) or 5 mA, whichever is smaller or less
Leakage current
[C = nominal capacitance (μF), V = rated voltage (V)]
Dissipation factor
0.15 or less（20℃,120Hz）
Permissible ripple current
As per the following "Standard value and case size".（85℃,120Hz）
After the rated voltage (specified ripple current convolution) is applied at 85℃ for 20000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
Others
JIS C 5101-4.
Ripple current correction coefficient
40
60
85
Ambient temperature（℃）
Correction coefficient
2.44
2.16
1.00
Frequency (Hz)
50/60
120
300
1K
≧10K
Correction coefficient
0.7
1.0
1.1
1.3
1.4
Ripple current should be under 60 Arms at M5 terminal in accordance with from
the permissible current.
Product code : (Example) HXA type 400V 10,000μF±20％
HX
A
2G 103
Y
( )
Case code (*)
Type of bracket
Capacitance code
Rated voltage code
Terminal symbol code A (screw)
Type name
* ( ), case code: Put the first letter of case code into ( ) in case there are
two case sizes in the same CV value.
Standard value and case size
Capacitance
μF
Code
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
C8R
C8R
C10R
C10R
C13R
D10R
-
D12R
-
D13R
-
D16R
E12R
D20R
E13R
E16R
F16R
F16R
F20R
12.2
11.5
14.6
13.1
15.5
18.1
19.9
23.8
28.8
Case code
10.3
D16R
E12R
D20R
E13R
D20R
E16R
F16R
F16R
F20R
F24R
-
9.0
D13R
-
11.1
10.4
13.4
12.0
14.6
14.4
16.5
18.1
21.7
25.8
Permissible ripple current (A)
85℃,120Hz
E20R
F16R
F20R
F20R
F24R
E16R
-
15.4
14.9
18.0
19.8
23.5
Rated voltage V. DC (code)
350
（2V）
3.8
4.2
5.2
5.6
7.1
7.6
C8R
C10R
C12R
C13R
D10R
D12R
-
9.5
400
（2G）
3.8
4.6
5.5
6.4
6.9
8.2
C10R
C12R
C13R
D10R
D12R
D13R
E12R
D16R
E13R
D20R
-
12.9
450
（2W）
4.2
5.0
5.8
6.2
7.4
8.6
8.7
10.2
10.0
12.2
F24R
Ripple current should be under 60 Arms
