MDM (Military M83401)
Vishay Dale
Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified,
Type RZ Dual-In-Line Package, 01, 03, 05 Schematics
FEATURES
•
•
•
•
•
MIL-PRF-83401 qualified
Epoxy molded construction
All device leads are hot-solder dipped
Available in tube pack
TCR available in “K” (± 100 ppm/°C) or “M” (± 300 ppm/°C)
depending on style
•
100 % screen tested per Group A, Subgroup 1 of
MIL-PRF-83401
•
All devices are capable of passing the MIL-STD-202,
Method 210, Condition D, “Resistance to Soldering Heat”
test
STANDARD ELECTRICAL SPECIFICATIONS
VISHAY DALE
MODEL/
PINS NO
RESISTOR
POWER RATING
SCHEMATIC
MAX. at 70 °C
W
01
0.10
03
0.20
05
0.05
01
0.10
03
0.20
05
0.05
PACKAGE
POWER RATING
MAX. at 70 °C
W
1.30
1.40
1.20
1.50
1.60
1.40
RESISTANCE
RANGE
Ω
10 - 1M
10 - 1M
Consult factory
10 - 1M
10 - 1M
Consult factory
STANDARD
TOLERANCE
±%
± 2 (± 1, ± 5)
(2)
± 2 (± 1, ± 5)
(2)
± 2 (± 1, ± 5)
(2)
± 2 (± 1, ± 5)
(2)
± 2 (± 1, ± 5)
(2)
± 2 (± 1, ± 5)
(2)
TEMPERATURE
WEIGHT
COEFFICIENT
g
(- 55 °C to + 125 °C)
K, M
(1)
K, M
(1)
K, M
(1)
K, M
(1)
K, M
(1)
K, M
(1)
1.3
1.3
1.3
1.5
1.5
1.5
MDM 14
MDM 14
MDM 14
MDM 16
MDM 16
MDM 16
Notes
(1)
K = ± 100 ppm/°C; M = ± 300 ppm/°C
(2)
± 1 % and ± 5 % tolerances available on request
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: M8340101M2201GBD04 (preferred part numbering format)
M
MIL STYLE
8
3
4
0
1
0
1
M
2
2
0
1
G
B
D
0
4
CHARACTERISTIC
RESISTANCE
TOLERANCE
V
ALUE
01
= 14 Pin
K
= 100 ppm
3 digit significant
F
=±1
%
M83401
figure, followed
02
= 16 Pin
M
= 300 ppm
G
=±2
%
by
a multiplier
J
=±5
%
10R0
= 10
Ω
3302
= 33 kΩ
1004
= 1 MΩ
Historical Part Number example: M8340101M2201GB (will continue to be accepted)
2201
01
M83401
M
SPEC SHEET
MIL STYLE
SPEC SHEET
CHARACTERISTIC
RESISTANCE
VALUE
SCHEMATIC
A
= Isolated
B
= Bussed
PACKAGING
D04
= Tin/Lead, Tube
DSL
= Tin/Lead, Tube,
Single Lot Date Code
G
B
D04
TOLERANCE
SCHEMATIC
PACKAGING
New Global Part Numbering: M8340102KA001GJD04 (preferred part numbering format)
M
MIL STYLE
8
3
4
0
1
0
2
K
A
0
0
1
G
J
D
0
4
RESISTANCE
TOLERANCE
V
ALUE
Per std. Mil. Spec
F
=±1
%
M83401
01
= 14 Pin
K
= 100 ppm
(see Impedence
G
=±2
%
02
= 16 Pin
M
= 300 ppm
codes table)
J
=±5
%
Historical Part Number example: M8340102KA001GJ (will continue to be accepted)
M83401
02
K
A001
SPEC SHEET CHARACTERISTIC
MIL STYLE
SPEC SHEET
CHARACTERISTIC
RESISTANCE
VALUE
SCHEMATIC
J
= Dual
Terminator
PACKAGING
D04
= Tin/Lead, Tube
DSL
= Tin/Lead, Tube,
Single Lot Date Code
J
D04
G
TOLERANCE
SCHEMATIC
PACKAGING
www.vishay.com
1
For technical questions, contact: ff2aresistors@vishay.com
Document Number: 31516
Revision: 08-Jul-08
MDM (Military M83401)
Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified,
Type RZ Dual-In-Line Package, 01, 03, 05 Schematics
DIMENSIONS
in inches [millimeters]
0.310
±
0.010
[7.87
±
0.254]
A
±
0.010 [0.254]
TYP 0.030
[0.762]
0.250
±
0.005
[6.35
±
0.127]
Vishay Dale
0.120
±
0.005
[3.05
±
0.127]
Pin #1
Identification
0.130 + 0.015
- 0.005
[3.30 + 0.381
- 0.127]
0.075
±
0.015
[1.91
±
0.381]
0.100
±
0.010
[2.54
±
0.254]
Non-Accumulative Tol.
"C" Spaces
B
±
0.010 [0.254]
0.050
±
0.005
[1.27
±
0.127]
0.018
±
0.003
[0.457
±
0.076]
0.290 Min.
0.320 Nom.
0.360 Max.
[7.37 Min.
8.13
Nom.
9.14 Max.]
Pin #1
0.010 + 0.005
- 0.002
[0.254 + 0.127
- 0.051]
VISHAY DALE MODEL
MDM14
MDM16
A
0.750 [19.05]
0.850 [21.59]
B
0.600 [15.24]
0.700 [17.78]
C
6
7
IMPEDANCE CODES
CODE
A001
A002
A003
A004
A005
A006
A007
A008
A009
R
1
(Ω)
82
120
130
160
180
180
220
220
330
R
2
(Ω)
130
200
210
260
240
390
270
330
390
CODE
A010
A011
A012
A013
A014
A015
A016
A017
A018
R
1
(Ω)
330
330
1.5K
3K
180
270
560
560
620
R
2
(Ω)
470
680
3.3K
6.2K
270
270
560
1.2K
2.7K
TECHNICAL SPECIFICATIONS
PARAMETER
Maximum Operating Voltage
Voltage Coefficient of Resistance
Dielectric Strength
Insulation Resistance
Operating Temperature Range
Storage Temperature Range
UNIT
V
DC
V
eff
V
AC
Ω
°C
°C
MDM SERIES
100
< 50 ppm
200 per min.
10 000 M
- 55 to + 125
- 55 to + 150
MECHANICAL SPECIFICATIONS
Marking Resistance to Solvents
Solderability
Body
Terminals
Permanency testing per MIL-PRF-83401
Per MIL-PRF-83401
Molded epoxy
Copper alloy, hot-solder dipped
Document Number: 31516
Revision: 08-Jul-08
For technical questions, contact: ff2aresistors@vishay.com
www.vishay.com
2
MDM (Military M83401)
Vishay Dale
Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified,
Type RZ Dual-In-Line Package, 01, 03, 05 Schematics
CIRCUIT APPLICATIONS
01 SCHEMATIC
MDM1401 (M8340101xxxxxxB)
MDM1601 (M8340102xxxxxxB)
13 or 15 resistors with one pin common
• • • • • • • •
The MDMxx01 provides the user with a choice of 13 or 15 nominally
equal resistors, each connected to a common pin. Commonly used in
the following applications:
• MOS/ROM Pull-up/Pull-down
• Open Collector Pull-up
• “Wired OR” Pull-up
• Power Driven Pull-up
• TTL Input Pull-down
• Digital Pulse Squaring
• TTL Unused Gate Pull-up
• High Speed Parallel Pull-up
MDM1401
Pin #1
MDM1601
03 SCHEMATIC
MDM1403 (M8340101xxxxxxA)
MDM1603 (M8340102xxxxxxA)
7 or 8 isolated resistors
The MDMxx03 provides the user with a choice of 7 or 8 nominally
equal resistors, with each resistor isolated from all others. Commonly
used in the following applications:
• “Wired OR” Pull-up
• Long-line Impedance Balancing
• Power Driven Pull-up
• LED Current Limiting
• Power Gate Pull-up
• ECL Output Pull-down
• Line Termination
• TTL Input Pull-down
MDM1403
Pin #1
MDM1603
05 SCHEMATIC
MDM1405 (M8340101xxxxxxJ)
MDM1605 (M8340102xxxxxxJ)
12 or 14 resistor pairs
The MDMxx05 provides the user with a choice of 12 or 14 pairs of
R1/R2 resistor values for pulse squaring and TTL dual-line
terminating requirements.
R1
R2
R1
R2
R2
R1
R2
R1
R2
R1
R2
R1
R2
R1
R1
R2 R2
R1
R2
R1
R2
R2
R1
R2
R1
R1
R2
R1
Pin #1
MDM1405, MDM1605
CAGE CODE: 91637
01 Schematic
03 Schematic
05 Schematic
Power Rating (W)
Power Rating (W)
1.50
1.30
MDM 16
MDM 14
1.60
1.40
MDM 16
MDM 14
Power Rating (W)
1.40
1.20
1.00
MDM 16
MDM 14
1.00
1.00
Single Resistor
0.10
0.20
Single Resistor
Single Resistor
0.05
- 55
+ 25
+ 70
+ 125 + 150
- 55
+ 25
+ 70
+ 125 + 150
- 55
+ 25
+ 70
+ 125 + 150
Derating
Ambient Temperature °C
Ambient Temperature °C
Ambient Temperature °C
www.vishay.com
3
For technical questions, contact: ff2aresistors@vishay.com
Document Number: 31516
Revision: 08-Jul-08
MDM (Military M83401)
Thick Film Resistor Networks Military, MIL-PRF-83401 Qualified,
Type RZ Dual-In-Line Package, 01, 03, 05 Schematics
Vishay Dale
PERFORMANCE
TEST
Power Conditioning
CONDITIONS
1.5 x rated power, applied 1.5 h “ON” and 0.5 h “OFF”
for 100 h ± 4 h at + 25 °C ambient temperature
5 cycles between - 65 °C and + 125 °C
MAX.
ΔR
(Typical Test Lots)
± 0.50 %
ΔR
± 0.50 %
ΔR
± 0.25 %
ΔR
(Char. K)
± 0.50 %
ΔR
(Char. M)
± 0.25 %
ΔR
(Char. K)
± 0.50 %
ΔR
(Char. M)
± 0.50 %
ΔR
± 0.25 %
ΔR
± 0.25 %
ΔR
± 0.25 %
ΔR
± 0.50 %
ΔR
(Char. K)
± 2.00 %
ΔR
(Char. M)
± 0.25 %
ΔR
Thermal Shock
Short Time Overload
2.5 x rated working voltage for 5 s
Low Temperature Operation
45 min at full rated working voltage at - 65 °C
Moisture Resistance
240 h with humidity ranging from 80 % RH to 98 % RH
Resistance to Soldering Heat
Leads immersed in + 260 °C solder to within 1/16" of body for 10 s
Shock
Total of 18 shocks at 100 G's
Vibration
12 h at maximum of 20 G's between 10 and 2000 Hz
1000 h at + 70 °C, rated power applied 1.5 h “ON”,
0.5 h “OFF” for full 1000 h period
4.5 pound pull for 30 s
Load Life
Terminal Strength
Insulation Resistance
10 000 MΩ (minimum)
-
Dielectric Withstanding Voltage
No evidence of arcing or damage (200 V
RMS
for 1 min)
-
Document Number: 31516
Revision: 08-Jul-08
For technical questions, contact: ff2aresistors@vishay.com
www.vishay.com
4
Legal Disclaimer Notice
Vishay
Disclaimer
All product specifications and data are subject to change without notice.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf
(collectively, “Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained herein
or in any other disclosure relating to any product.
Vishay disclaims any and all liability arising out of the use or application of any product described herein or of any
information provided herein to the maximum extent permitted by law. The product specifications do not expand or
otherwise modify Vishay’s terms and conditions of purchase, including but not limited to the warranty expressed
therein, which apply to these products.
No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any conduct of Vishay.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications unless
otherwise expressly indicated. Customers using or selling Vishay products not expressly indicated for use in such
applications do so entirely at their own risk and agree to fully indemnify Vishay for any damages arising or resulting
from such use or sale. Please contact authorized Vishay personnel to obtain written terms and conditions regarding
products designed for such applications.
Product names and markings noted herein may be trademarks of their respective owners.
