XC6132 Series
ETR02032-001
Delay capacitor adjustable voltage detectors with sense pin isolation,
surge voltage protection and HYS external adjustment
■GENERAL
DESCRIPTION
The XC6132 series are ultra-small delay capacitor adjustable type voltage detectors that have high accuracy and sense pin
isolation. High accuracy and a low supply current are achieved by means of a CMOS process, a highly accurate reference
power supply, and laser trimming technology.
The sense pin is isolated from the power input pin to enable monitoring of the voltage of another power supply. Output can
be maintained in the detection state even if the voltage of the power supply that is monitored drops to 0V. The sense pin is
also suitable for detecting high voltages, and the detection and release voltage can be set as desired using external
resistors. An internal surge voltage protection circuit and an internal delay circuit are also provided.
By connecting a capacitor to the Cd/MRB pin, any release delay time and detect delay time can be set and the pin can also
be used as a manual reset pin.
The HYS external adjustment pin can be used to establish a sufficient hysteresis width.
■APPLICATIONS
●Microcontroller
reset and malfunction monitoring
●Battery
voltage monitoring
●System
power-on reset
●Power
failure detection
■FEATURES
Operating Ambient Temperature
Operating voltage range
Detect voltage range
Detect voltage accuracy
(Ta=25℃)
Detect voltage accuracy
(Ta=-40½125℃)
Temperature Characteristics
Hysteresis width
Adjustable Pin for Hysteresis Width
Low supply current
: -40℃½+125℃
: 1.6V½6.0V
: 0.8V½2.0V
: ±18mV(V
DF
＜1.5V)
: ±1.2%(1.5V≦V
DF
≦2.0V)
: ±36mV(V
DF
＜1.5V)
: ±2.7%(1.5V≦V
DF
≦2.0V)
: ±50ppm/℃(TYP.)
: V
DF
×0.1％(TYP.)
: Yes
: 1.28μA(TYP.)
V
IN
=1.6V(At detection)
: 1.65μA(TYP.)
V
IN
=6.0V(At release)
: Yes (For details, refer to
FUNCTION CHART)
: CMOS or Nch open drain
: H level or L level at detection
: Release delay / detection delay
can be set in 5 time ratio options
(For details, refer to Selection Guide).
: Includes a surge voltage protection
function
: USP-6C,SOT-26
: EU RoHS compliant, Pb free
Manual reset function
Output type
Output logic
Delay capacitance pin
Sense pin
Packages
Environment friendly
■TYPICAL
APPLICATION CIRCUIT
■TYPICAL
PERFORMANCE
CHARACTERISTICS
+B
R3
HYS
V
SEN
Output Voltage : V
RESET
(V)
V
DD
XC6132C10E
VIN=3.3V
VSEN=0V→10V→0V
R2=100kΩ、R3=330kΩ
R1
V
IN
4.0
Rpull
(*1)
RESET
RESETB
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0
1
2
3
4
5
6
7
8
9
10
Voltage Sense : V
SEN
(V)
OPEN
R1=330kΩ
R1=560kΩ
R2
RESET
SW
Cd
Cd/MRB
V
SS
GND
Battery (+B) voltage monitoring: Detects high voltage
via R1/R2 resistance division.
A hysteresis width can be added as desired by
connecting R3 between the V
SEN
and HYS pins
(For details, refer to OPERATIONAL DESCRIPTION).
1/30
XC6132
Series
■PIN
CONFIGURATION
●A/B/C/D/L
type
Cd/MRB
6
V
SS
5
V
SEN
4
V
SEN
6
V
SS
5
1 HYS
2 RESET
3 V
IN
1
V
IN
2
3
Cd/MRB 4
RESET HYS
SOT-26
(TOP VIEW)
USP-6C
(BOTTOM VIEW)
●E/F/H/K/M
type
Cd/MRB
6
V
SS
5
V
SEN
4
1 HYS
2 RESETB
3 V
IN
V
SEN
6
V
SS
5
1
V
IN
2
3
Cd/MRB 4
RESETB HYS
SOT-26
(TOP VIEW)
USP-6C
(BOTTOM VIEW)
*The dissipation pad for the USP-6C package should be solder-plated in reference mount pattern and metal masking so as to
enhance mounting strength and heat release. If the pad needs to be connected to other pins, it should be connected to V
SS
(No.
5) pin.
■PIN
ASSIGNMENT
PIN NUMBER
SOT-26
1
2
3
4
5
6
(*1)
USP-6C
3
2
1
6
5
4
PIN NAME
V
IN
RESETB
RESET
HYS
V
SEN
V
SS
Cd/MRB
FUNCTION
Power Input
Reset Output (Active Low)
(*1)
Reset Output (Active High)
(*1)
Adjustable Pin for Hysteresis Width
Voltage Sense
Ground
Adjustable Pin for Delay Time/
Manual Reset
Refer to the
④
in Ordering Information table.
