MAL215135478E3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> MAL215135478E3

MAL215135478E3: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 250 V, 4.7 uF, THROUGH HOLE MOUNT; CategoryPassive components capacitor; File Size96KB，6 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

MAL215135478E3 Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 250 V, 4.7 uF, THROUGH HOLE MOUNT

MAL215135478E3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
capacitance	4.7 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	10 mm
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
leakage current	0.119 mA
length	16 mm
Manufacturer's serial number	151RLH
Installation features	THROUGH HOLE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Radial
method of packing	AMMO PACK
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	350 V
ripple current	65 mA
series	151 RLH
surface mount	NO
Delta tangent	0.15
Terminal surface	Matte Tin (Sn)
Terminal pitch	5 mm
Terminal shape	WIRE

Preview

Download Datasheet

View All

151 RLH

Vishay BCcomponents

Aluminum Capacitors

Radial Long-Life, High Voltage

FEATURES

•

Polarized

aluminum

electrolytic

capacitors, non-solid electrolyte

•

Radial leads, cylindrical aluminum case,

insulated with a blue vinyl sleeve

•

Pressure relief

•

Charge and discharge proof

Fig.1 Component outline

RoHS

COMPLIANT

044 RSH

°C

151 RLH

105 °C

low

voltage

miniaturized

152 RMH

•

High rated voltage, up to 450 V

148 RUS

miniaturized

048 RML

•

High-reliability and professional applications

QUICK REFERENCE DATA

DESCRIPTION

Nominal case sizes

(Ø D x L in mm)

Rated capacitance range, C

Tolerance on C

Rated voltage range, U

Category temperature range

Endurance test at 105 °C

Useful life at 105 °C:

Case Ø D = 10 and 12.5 mm

Case Ø D = 16 and 18 mm

Useful life at 40

°C,

1.6 x I

applied:

Case Ø D = 10 and 12.5 mm

Case Ø D = 16 and 18 mm

Shelf life at 0 V, 105 °C

Based on sectional

specification

VALUE

10 x 12

to 18 x 35

1 to 220 µF

± 20 %

160 to 450 V

- 40 to +105 °C

2000 hours

3000 hours

4000 hours

•

Filtering of high voltages in power supplies

200 000 hours

260 000 hours

500 hours

IEC 60384-4/EN 130300

40/105/56

Climatic category IEC 60068

SELECTION CHART FOR C

, U

AND RELEVANT NOMINAL CASE SIZES

(Ø D x L in mm)

(µF)

1.0

2.2

3.3

4.7

100

220

www.vishay.com

(V)

200

10 x 12

10 x 16

10 x 20

12.5 x 20

12.5 x 25

16 x 20

16 x 31

18 x 25

250

10 x 12

10 x 20

12.5 x 25

16 x 20

12.5 x 25

16 x 20

16 x 25

18 x 20

16 x 31

18 x 25

350

10 x 12

10 x 16

12.5 x 20

12.5 x 25

16 x 20

16 x 25

16 x 35

18 x 31

400

10 x 12

10 x 16

10 x 20

12.5 x 20

16 x 25

18 x 20

16 x 31

18 x 25

18 x 31

450

10 x 12

10 x 16

10 x 20

12.5 x 20

16 x 20

16 x 31

18 x 25

18 x 35

Document Number: 28319

Revision: 27-May-08

160

10 x 16

10 x 20

12.5 x 20

12.5 x 25

16 x 20

16 x 25

18 x 20

18 x 35

For technical questions, contact: aluminumcaps1@vishay.com

MARKING

The capacitors are marked (where possible) with the

following information:

•

Rated capacitance value (in µF)

•

Tolerance on rated capacitance, code letter in accordance

with IEC 60062 (M for ± 20 %)

•

Rated voltage (in V)

•

Date code, in accordance with IEC 60062

•

Code indicating factory of origin

•

Name of manufacturer

•

Upper category temperature (105 °C)

•

Negative terminal identification

•

Series number (151)

•

Lighting,

industrial

APPLICATIONS

monitors,

•

Lead (Pb)-free versions are RoHS compliant

consumer

•

Long useful life: 3000 to 4000 hours at 105 °C, high

reliability

electronics,

general
