EMI/RFI Y2-DS
Vishay BCcomponents
Ceramic Disc Capacitors
Safety, Class X1/Y2 440/250V (AC) Series DS
FEATURES
•
Complying with “EN 132 400” and “IEC 60384-14,
2nd edition, including amendment 1.1995”
•
High reliability
•
Kinked (preferred) or straight leads.
•
Lead (Pb)-free available.
tangent
line
SH
D
D
APPLICATIONS
•
Across-the-line
•
Line by-pass
•
Antenna coupling.
DESIGN
The capacitors consist of a ceramic disc both sides of which
are silver-plated. Connection leads are made of tinned
copper having a diameter of 0.6 mm or 0.8 mm.
The capacitors may be supplied with kinked or straight leads
having a lead spacing of 5.0 mm (0.200") or 7.5 mm (0.300")
and a lead length from 4 to 30 mm. The standard tolerance
on capacitance is
±10%
for U2M and Y5P material,
±20%
for
Y5U and
−20/+80%
for Y5V material. Encapsulation is made
of flammable resistant epoxy resin in accordance with
“UL94V-0”.
F
F
Capacitors with 5.0 mm (0.20”) 7.5 mm (0.30”) lead spacing.
TOLERANCE ON CAPACITANCE:
±10%; ±20%; -20/+80%
CAPACITANCE RANGE:
at 1kHz, 1V (RMS); 10 to 10000pF
DISSIPATION FACTOR:
at 1kHz; 1V (RMS); 2.5% max
RATED VOLTAGE U
R
:
(X1): 440V (AC), 50Hz (IEC 60384-14.2)
(Y2): 250V (AC), 50Hz (IEC 60384-14.2)
TEMPERATURE COEFFICIENTS:
U2M; Y5P; Y5U; Y5V
APPROVALS:
DIELECTRIC STRENGTH BETWEEN LEADS:
Component test:
1900V (AC), 50Hz, 2 seconds
As repeated test admissible only once with:
1700V (AC), 50Hz, 2 seconds
Random sampling test (destructive test):
1500V (AC), 50Hz, 60 seconds
ENEC, UL file E95439 and CSA
CLIMATIC CATEGORY:
25/125/56 or 25/85/21
OPERATING TEMPERATURE RANGE:
-30 to +125°C
DIELECTRIC STRENGTH OF BODY INSULATION:
1500V (AC), 50Hz, 60 seconds (destructive test)
MARKING
Marking indicates capacitance value and tolerance in
accordance with
“EIA 198”,
voltage and approval marks.
INSULATION RESISTANCE AT 500V (DC):
≥10000
MΩ
The capacitors meet the essential requirements of “EIA 198”. Unless stated otherwise all electrical values apply at an ambient
temperature of 25 ± 3°C, at normal atmospheric conditions
Document Number: 28519
Revision: 23-Feb-05
For technical questions contact: CDC@vishay.com
www.vishay.com
71
EMI/RFI Y2-DS
Vishay BCcomponents
Ceramic Disc Capacitors
Safety, Class X1/Y2 440/250V (AC)
Series DS
ORDERING INFORMATION, X1 440V (AC); Y1 250V (AC)
CLEAR TEXT CODE
C
(pF)
TOL.
(%)
D
max
(mm)
LEAD
SPACING
F
(mm)
SH
(2)
(mm)
13
th
DIGIT:
T = REEL; U = AMMO;
3 = BULK
(3)
16
th
DIGIT:
R = RoHS COMPLIANT
S100K25U2MY6.K5.
S150K25U2MY6.K5.
S220K25U2MY6.K5.
S330K25U2MY6.K5.
S470K29U2MY6.K5.
S680K33U2MY6.K5.
S101K25Y5PY6.K5.
S151K25Y5PY6.K5.
S221K29Y5PY6.K5.
S331K29Y5PY6.K5.
S471K29Y5PY6.K5.
S681K29Y5PY6.K5.
S102M29Y5UY6.K5.
S152M29Y5UY6.K5.
S222M33Y5UY6.K5.
S332M39Y5UY6.K5.
S472M47Y5UY6.K5.
S222Z33Y5VY6.K5.
S332Z39Y5VY6.K5.
S472Z43Y5VY6.K5.
S103Z59Y5VY6.K7.
PACKAGING CODE
8
th
AND 9
th
DIGIT
REEL
AMMO
BULK
CATALOG
NUMBER
(4)
3
rd
DIGIT:
5 = STANDARD,
8 = RoHS
COMPLIANT
KINKED
U2M
10
15
22
33
47
68
Y5P
100
150
220
330
470
680
Y5U
1000
1500
2200
3300
4700
Y5V
2200
3300
4700
10000
Notes
6.5
±10
7.5
8.5
5.0
4.0
13
14
15
22.2 815 ..006
22.2 815 ..106
22.2 815 ..206
22.2 815 ..306
22.2 815 ..406
22.2 815 ..606
22.2 815 ..016
22.2 815 ..116
22.2 815 ..216
22.2 815 ..316
22.2 815 ..416
22.2 815 ..616
22.2 815 ..027
22.2 815 ..127
22.2 815 ..227
22.2 815 ..327
22.2 815 ..427
22.2 815 ..228
22.2 815 ..328
22.2 815 ..428
22.2 815 ..038
6.5
±10
7.5
5.0
4.0
13
14
15
7.5
±20
8.5
10.0
12.0
8.5
10.0
11.0
15.0
5.0
4.0
13
14
15
−20/+80%
5.0
7.5
4.0
4.8
13
35
14
36
15
37
1. Maximum thickness 4.5 mm.
2. SH = seated height.
3. Straight leads are available on request.
4. 3
rd
digit to complete RoHS catalog number. 8
th
and 9
th
digit of the catalog number to be completed with the packaging code.
PACKAGING
D
max
(mm)
8.5 (0.33")
10.0 (0.39")
11.0 (0.43")
12.0 (0.47")
13.5 (0.53")
15.0 (0.59")
Note
1. The capacitors are supplied in bulk packaging (cardboard boxes), in tape on reel or in ammopack.
SIZE CODE
33
39
43
47
53
59
500
−
−
1000
1000
1500
PACKAGING QUANTITIES
BULK
REEL
AMMO
www.vishay.com
72
For technical questions contact: CDC@vishay.com
Document Number: 28519
Revision: 23-Feb-05
EMI/RFI Y2-DS
Ceramic Disc Capacitors
Sarfety, Class X1/Y2 440/250V (AC)
Series DS
D
P
2
P
∆s
∆P
∆s
∆P
∆h
∆h
Vishay BCcomponents
H
1
W
2
H
0
L
W
1
W
0
W
A
e
direction of unreeling
∅d
P
1
F
P
0
t
1
detail A
t
D
0
Kinked capacitors on tape, lead spacing 5 mm (0.20”) or 7.5 mm (0.30”).
DIMENSIONS OF TAPE
SYMBOL
PARAMETER
DIMENSIONS
(mm)
FEED-HOLE PITCH
P
0
= 12.7
11.0 max.
0.6
±0.05
12.7
±1.0
12.7
±0.3;
note 1
1.0 max.
3.85
±0.7;
note 2
6.35
±1.3;
note 2
5.0 +0.6/−0.4
0
±1.0
0
±1.0
18.0 +1.0/−0.5
5.0 min.
9.0 +0.75/−0.5
3.0 max.
16.0
±0.5
32.0
1.0 max.
11.0
4.0
±0.2
0.9 max.
1.5 max.
FEED-HOLE PITCH
P
0
= 15.0
14.0 max.
0.6
±0.05
15.0
±1.0
15.0
±0.3;
note 1
1.0 max.
3.75
±1.0;
note 2
7.5
±1.5;
note 2
7.5
±1.0
0
±1.0
0
±1.0
18.0 +1.0/−0.5
5.0 min.
9.0 +0.75/−0.5
3.0 max.
16.0
±0.5
40.0
1.0 max.
11.0
4.0
±0.2
0.9 max.
1.5 max.
D
d
P
P
0
∆P
P
1
P
2
F
∆h
∆s
W
W
0
W
1
W
2
H
0
H
1
e
L
D
0
t
t
1
Notes
body diameter
lead diameter
pitch between capacitors
feed-hole pitch
plane deviation
feed-hole centre to lead centre
feed-hole centre to component centre
lead spacing
component alignment
deviation along tape, left or right
tape width
hold-down tape width
hole position
hold-down tape margin
height to seating plane
maximum component height
lead end protrusion
maximum length of snipped lead
feed-hole diameter
total tape thickness
maximum thickness of tape and wires
1. Cumulative pitch error:
±≤1
mm/20 pitches.
2. Obliquity maximum 3°.
Document Number: 28519
Revision: 23-Feb-05
For technical questions contact: CDC@vishay.com
www.vishay.com
73
