Ultra-Small, Low-Power Single Comparators in 4-Bump UCSP and 5 SOT23

Preview

Download Datasheet

View All

19-4105; Rev 4; 3/11

KIT

ATION

EVALU

BLE

AVAILA

Ultra-Small, Low-Power Single

Comparators in 4-Bump UCSP and 5 SOT23

General Description

Features

Tiny 1mm x 1mm x 0.6mm 4-Bump UCSP

Footprint = Two 0402 Resistors

Also Available in a 5-Pin SOT23 Package

Ultra-Low Operating Current (100nA max)

Input Voltage Range = -0.3V to +5.5V

External REF Range = 0.9V to 5.5V

(MAX9060/MAX9061)

Internal REF Voltage = 0.2V

(MAX9062/MAX9063/MAX9064)

15µs Propagation Delay

-40°C to +85°C Extended Temperature Range

MAX9060–MAX9064

The MAX9060–MAX9064 are small single comparators,

ideal for a wide variety of portable electronics applica-

tions such as cell phones, media players, and notebooks

that have extremely tight board space and power con-

straints. These comparators are offered in both, a minia-

ture 4-bump UCSP™ package with a 1mm x 1mm

footprint (as small as two 0402 resistors), and a 5-pin

SOT23 package.

The MAX9060–MAX9064 feature an input voltage range

of -0.3V to +5.5V independent of supply voltage. These

devices maintain high impedance at the inputs even

when powered down (V

or V

REF

= 0V). They also

feature internal filtering to provide high RF immunity.

The MAX9060 and MAX9061 have open-drain outputs

and draw quiescent supply current from a user-supplied

reference voltage, V

REF

, between 0.9V and 5.5V. These

devices consume only 100nA (max) supply current and

operate over the extended -40°C to +85°C temperature

range.

The MAX9062, MAX9063 and MAX9064 are single com-

parators with an internal 0.2V reference. These devices

feature either a push-pull or an open-drain output. They

consume only 700nA (max) supply current. The MAX9062,

MAX9063, and MAX9064 operate down to V

= 1V

over the extended -40°C to +85°C temperature range.

Ordering Information

PART

MAX9060EBS+G45

MAX9060EUK+

MAX9061EBS+G45

MAX9061EUK+

MAX9062EBS+G45

MAX9062EUK+

MAX9063EBS+G45

MAX9063EUK+

MAX9064EBS+G45

MAX9064EUK+

PIN-PACKAGE

4 UCSP

5 SOT23

4 UCSP

5 SOT23

4 UCSP

5 SOT23

4 UCSP

5 SOT23

4 UCSP

5 SOT23

TOP MARK

AFX

AFFG

AFY

AFFH

AFZ

AFFI

AGA

AFFJ

AGB

AFFK

Applications

Cell Phones

Portable Media Players

Electronic Toys

Notebook Computers

Portable Medical Devices

UCSP is a trademark of Maxim Integrated Products, Inc.

Note:

All devices are specified over the extended -40°C to

+85°C operating temperature range.

+Denotes

a lead(Pb)-free/RoHS-compliant package.

G45 = Protective die coating.

Selector Guide and Typical Operating Circuits appear at

end of data sheet.

Pin Configuration

TOP VIEW (BUMPS ON BOTTOM)

OUT

REF

)

OUT

MAX9060–MAX9064

REF

)

GND

MAX9060–

MAX9064

GND

UCSP

REF = MAX9060/MAX9061

) = MAX9062–MAX9064

SOT23

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,

or visit Maxim’s website at www.maxim-ic.com.
