MCL103A/B/C
•
•
•
•
•
•
•
Features
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Saving space
High Reliability
Low reverse current and low forward voltage
Micro Melf package,fits onto SOD 323/SOT 23 Footprints
Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates
Compliant. See ordering information)
350 mA Schottky
Barrier Rectifier
20 to 40 Volts
MICROMELF
Cathode Mark
Maximum Ratings
Parameter
Symbol
Value
40V
30V
20V
1A
350mA
400 mW
-65~+175
250K/W
A
C
Test Conditions
Repetitive peak reverse
voltage
MCL103A
V
RRM
MCL103B
MCL103C
Repetitive peak forward
current
Forward current
Power dissipation
Storage temperature range
I
FRM
I
FM
P
D
T
stg
R
thJA
Junction to ambient
B
Electrical Characteristics @ 25
o
C Unless Otherwise Specified
Parameter
Forward voltage
Reverse current
MCL103A
MCL103B
MCL103C
Diode capacitance
Reverse recovery time
Symbol
V
F
Value
0.37 V
0.6 V
5
A
Test Conditions
I
F
=20mA
I
F
=200mA
DIMENSIONS
I
R
C
D
t
rr
V
R
=30V
V
R
=20V
V
R
=10V
V
R
=V
F
=0, f=1MHz
I
F
= I
R
=200mA to
0.1mA
DIM
A
B
C
INCHES
MIN
.071
.004
.047
MAX
.079
.008
.051
MM
MIN
1.8
.10
1.20
MAX
2.0
.20
1.30
NOTE
∅
50 pF
10ns
SUGGESTED SOLDER
PAD LAYOUT
0.039
Note: 1. Lead in Glass Exemption Applied, see EU Directive Annex 5.
0.055”
0.030”
www.mccsemi.com
Revision:
A
1 of 4
2011/01/01
MCL103A/B/C
Characteristics
(T
j
=25
unless otherwise specified)
MCC
Micro Commercial Components
TM
Forward current: I
F
(mA)
Forward current: I
F
(mA)
Forward voltage: V
F
(V)
Forward voltage: V
F
(V)
Figure 1. Typical variation of forward current vs.
forward voltage for primary conduction
through the schottky barrier
Figure 2. Typical high current forward conduction
curve t
p
=300ms, duty cycle=2%
Reverse leakage current: I
R
(uA)
Forward current: I
F
(mA)
t
p
Reverse voltage: V
R
Figure 3. Typical non repetitive forward surge
current vs. pulse width
Figure 4. Typical variation of reverse current
at various temperatures
Revision:
A
www.mccsemi.com
2 of 4
2011/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Packing
Tape&Reel:
2.5Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
A
4 of 4
2011/01/01
