3180-070002 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 3180-070002

3180-070002: DescriptionD Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, Plug; CategoryThe connector The connector; File Size162KB，1 Pages; ManufacturerWieson Technologies Co., Ltd.

Download Datasheet Parametric Compare View All

3180-070002 Overview

D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, Plug

3180-070002 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Wieson Technologies Co., Ltd.
Reach Compliance Code	unknown
ECCN code	EAR99
body width	0.492 inch
subject depth	1.34 inch
body length	1.213 inch
Body/casing type	PLUG
Contact to complete cooperation	AU ON NI
Contact completed and terminated	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	COPPER ALLOY
contact mode	STAGGERED
Contact style	RND PIN-SKT
Insulator color	BLUE
insulator material	THERMOPLASTIC
JESD-609 code	e0
Manufacturer's serial number	3180
Plug contact pitch	0.09 inch
Match contact row spacing	0.078 inch
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	3
Number of rows loaded	3
PCB contact pattern	STAGGERED
PCB contact row spacing	2.54 mm
Plating thickness	1u inch
Guideline	UL
reliability	COMMERCIAL
Shell surface	NICKEL
Terminal length	0.102 inch
Terminal pitch	2.286 mm
Termination type	SOLDER
Total number of contacts	15

Preview

Download Datasheet

View All

3180-070002 Related Products

	3180-070002	3180-070201	3180-070301	3180-070401	3180-070402	3180-070502
Description	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, Plug	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, #4-40, Plug	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, Plug	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, #4-40, Plug	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, #4-40, Plug	D Type Connector, 15 Contact(s), Female, 0.09 inch Pitch, Solder Terminal, #4-40, Plug
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	Wieson Technologies Co., Ltd.	Wieson Technologies Co., Ltd.	Wieson Technologies Co., Ltd.	Wieson Technologies Co., Ltd.	Wieson Technologies Co., Ltd.	Wieson Technologies Co., Ltd.
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
body width	0.492 inch	0.492 inch	0.492 inch	0.492 inch	0.492 inch	0.492 inch
subject depth	1.34 inch	1.34 inch	1.34 inch	1.34 inch	1.34 inch	1.34 inch
body length	1.213 inch	1.213 inch	1.213 inch	1.213 inch	1.213 inch	1.213 inch
Body/casing type	PLUG	PLUG	PLUG	PLUG	PLUG	PLUG
Contact to complete cooperation	AU ON NI	AU ON NI	AU ON NI	AU ON NI	AU ON NI	AU ON NI
Contact completed and terminated	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Contact material	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY	COPPER ALLOY
contact mode	STAGGERED	STAGGERED	STAGGERED	STAGGERED	STAGGERED	STAGGERED
Contact style	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT
Insulator color	BLUE	BLACK	BLACK	BLACK	BLUE	BLUE
insulator material	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC
JESD-609 code	e0	e0	e0	e0	e0	e0
Manufacturer's serial number	3180	3180	3180	3180	3180	3180
Plug contact pitch	0.09 inch	0.09 inch	0.09 inch	0.09 inch	0.09 inch	0.09 inch
Match contact row spacing	0.078 inch	0.078 inch	0.078 inch	0.078 inch	0.078 inch	0.078 inch
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
PCB row number	3	3	3	3	3	3
Number of rows loaded	3	3	3	3	3	3
PCB contact pattern	STAGGERED	STAGGERED	STAGGERED	STAGGERED	STAGGERED	STAGGERED
PCB contact row spacing	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Plating thickness	1u inch	1u inch	1u inch	1u inch	1u inch	1u inch
Guideline	UL	UL	UL	UL	UL	UL
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Shell surface	NICKEL	NICKEL	NICKEL	NICKEL	NICKEL	NICKEL
Terminal length	0.102 inch	0.102 inch	0.102 inch	0.102 inch	0.102 inch	0.102 inch
Terminal pitch	2.286 mm	2.286 mm	2.286 mm	2.286 mm	2.286 mm	2.286 mm
Termination type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER
Total number of contacts	15	15	15	15	15	15
Installation option 1	-	#4-40	-	#4-40	#4-40	#4-40
Installation option 2	-	SCREW	-	SCREW	SCREW	SCREW
