Thick Film Nickel Barrier
Wraparound Surface Mount Chip
Resistors
The
ims
RXI series of thick film wraparound surface mount chip resistors is ideal
for most applications requiring an inexpensive, reliable chip resistor. The “X”
designation in the RXI series is a variable that describes the subgroup type (Low
ohm, Trimmable, etc). Please see the ordering information on the back for in-
structions. Thick film technology provides a stable resistor at a very affordable
price. The wraparound terminations include a nickel barrier layer which affords
excellent solderability and mechanical integrity. These chip resistors have the
following features:
• High stability thick film resistor element
• 96% Al
2
O
3
substrate material
• Nickel barrier layer for excellent solderability and mechanical integrity
• Trimmed to EIA standard values
• Tolerances to ± 0.5%
• Glass passivation of resistor element
• Available in bulk or on tape and reel
• 50 ppm available in RPI series only
Terminations
Full wraparound termination
nickel barrier layer
RCI-2010T
1
RCI-2512T
1
RPI-1206
RCI-0805T
3
RCI-1206T
3
RCI-2512S
1
RTI-0805
RTI-1206
Features
RCI-0805
4
RCI-2010
1
Full Wraparound
Nickel Barrier for
excellent solderability
Resistance values from
0.068 ohm to 22 Megohm
Trimmable (RTI series)
Tolerances to 0.5 %
TCR to 50 ppm/
o
C
0.15Ω - 0.82Ω
0.33Ω - 0.68Ω
1.0Ω - 9.76Ω
10%
10%
1%
5%
10Ω - 1MΩ
1%
5%
1.02MΩ - 10MΩ 1%
5%
11MΩ - 22MΩ
5%
Maximum resistance value is 100KΩ
2
Minimum resistance value is 0.1Ω
Ω
±1%
3
Maximum resistance value is 5.6MΩ Jumpers (0
Ω)
available in all
sizes (RCI-0201,0402,0603 rated at 1 amp. All others rated at 2 amps)
4
22MΩ
- 500MΩ available as special part. Contact
ims
for ranges and special P/N.
1
RLI-0805
RLI-1206
50 Schoolhouse Lane
Portsmouth, RI 02871
Tel (401) 683-9700
Fax (401) 683-5571
e-mail: ims@ims-resistors.com
http://www.ims-resistors.com
RLI-1210
0.068Ω - 0.091Ω 5%
0.1Ω - 1.0Ω
2%
5%
10Ω - 1MΩ +0,-30%
10Ω - 3.3MΩ 0.5%
10Ω - 4.7MΩ 0.5%
RPI-0805
RCI-2512
2
RCI-1206
4
Thick film technology
Resistance Ranges
RCI-0201
RCI-0402
RCI-0603
RCI-1210
Dimensions
Part Number
RCI-0201
RCI-0402
RCI-0603
RCI-0805
RLI-0805
RCI-1206
RLI-1206
RLI-1210
RCI-2010
RCI-2512(S)
Length
0.024 ± .002
0.039 ± .002
0.063 ± .006
0.079 ± .008
0.079 ± .006
0.126 ± .008
0.122 ± .008
0.122 ± .002
0.197 ± .008
0.248 ± .008
Width
0.012 ± .002
0.020 ± .004
0.031 ± .006
0.049 ± .004
0.049 ± .004
0.063 ± .006
0.063 ± .006
0.098 ± .006
0.098 ± .006
0.126 ± .010
Height
0.012 max.
0.016 max.
0.022 max.
0.026 max.
0.028 max.
0.028 max.
0.028 max.
0.028 max.
0.028 max.
0.028 max.
Terminal
0.006 ± .002
0.010 ± .004
0.012 ± .004
0.016 ± .008
0.016 ± .008
0.020 ± .010
0.012 ± .008
0.012 ± .008
0.020 ± .012
0.026 ± .010
W
H
L
T
Characteristics
Operating Temperature
Short time overload
Terminal strength
Solder Heat Resistance
Solderability
Temperature Cycle
Load Life
-55
o
C to +150°C
± (1% + 0.05
Ω)
Max.
± (1% + 0.05
Ω)
Max.
± (1% + 0.05
Ω)
Max.
95% minimum coverage
± (1% + 0.05
Ω)
Max.
10
Ω ≤
R
≤
1M
Ω:
± (3% + 0.01
Ω)
R < 10
Ω,
R > 1M
Ω:
± (5% + 0.1
Ω)
TCR
RCI
+ 1000, -300
+ 500, -200
ppm/°C
±250
±200
±100
1
0
0 0.15 0.82 1 9.76 10 1M 10M 11M 22M
Specifications
Maximum Working Voltage
0201
0402, 0603
0805
1206, 2010, 2512, 2512S
Rated power (70°C)
0201
0402
0603
0805 (low ohms)
0805
1206
1210(RCI)
1210(RLI)
2010
2512
2512S
15 VDC
50 VDC
150 VDC
200 VDC
50 mW
63 mW
100 mW
125 mW
175 mW
250 mW
250 mW
500 mW
500 mW
1000 mW
2000 mW
1
Ohms
1% tolerance only
RLI
+500, -100
ppm/°C
± 250
0
0
0.068
0.091
Ohms
0.1
1.0
Ordering Information
Example: 100Ω, 5%, 175 mW, 0805 resistor
Tolerance
F - 1%
J - 5%
K - 10%
U - +0, -30%
Resistance value
The first three digits are significant
values. The fourth is the number
of zeroes following. The R
indicates a decimal point for
resistance values less than 100Ω.
Example: RCI - 0805 - 1000 J
RCI (Standard)
RLI (Low Ohm)
RPI (Precision)
RTI (Untrimmed
U Tol. only)
Form factor
0201
0402
0603
0805(T) 1210
1206(T)
2010(T) 2512(T) 2512S
“T” indicates custom value trim
Engineering Kits Available
Please contact your
nearest rep or contact
IMS directly.
50 Schoolhouse Lane
Portsmouth, RI 02871
Tel (401) 683-9700
Fax (401) 683-5571
e-mail: ims@ims-resistors.com
http://www.ims-resistors.com
RXI ver.5 09/03 Specifications subject to change without notice.
