8700 E. Thomas Road
Scottsdale, AZ 85251
Tel: (480) 941-6300
Fax (480) 947-1503
HSMBJ5913B
thru
HSMBJ5956B
SILICON
3.0 W
ZENER DIODE
FEATURES:
•
•
•
•
Surface mount equivalent to 1N5913B thru 1N5956B
Popular HSMBJ Package outline-Small and Rugged
Zener voltage 3.3V to 200V
Constructed with an Oxide Passivated All Diffused Die
MAXIMUM RATINGS:
•
•
•
•
Junction and Storage Temperature: -55°C to +150°C
DC Power Dissipation 3 W at Lead Temp. T
L
≤75°C
Derate above +75°C: 40 mW/°C
Forward voltage @ 200mA: 1.2Volts and T
L
= 30°C
Electrical Characteristics @ TL = 30°C
PART
NUMBER
ZENNER
VOLTAGE
V
T
(NOTE 1)
Volts
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
TEST
CURRENT
I
ZT
mA
113.6
104.2
96.1
87.2
79.8
73.5
66.9
60.5
55.1
50.0
45.7
41.2
37.5
34.1
31.2
28.9
25.0
23.4
20.8
18.7
17.0
15.6
13.9
12.5
11.4
10.4
9.6
8.7
8.0
7.3
6.7
6.0
5.5
5.0
4.6
4.1
3.7
3.4
3.1
2.9
2.5
2.3
2.1
1.9
DYNAMIC
IMPEDANCE
Z
ZT
(NOTE 2)
Ohms
10.0
9.0
7.5
6.0
5.0
4.0
2.0
2.0
2.5
3.0
3.5
4.0
4.5
5.5
6.5
7.0
9.0
10.0
12.0
14.0
17.5
19.0
23.0
28.0
33.0
38.0
45.0
53.0
67.0
70.0
86.0
100
120
140
160
200
250
300
280
450
600
700
900
1200
KNEE
CURRENT
I
ZK
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
KNEE
IMPEDANCE
Z
ZK
(NOTE 2)
OHMS
500
500
500
500
500
350
250
200
200
400
400
500
500
550
550
550
600
600
650
650
650
700
700
750
800
850
900
950
1000
1100
1300
1500
1700
2000
2500
3000
3100
4000
4500
5000
6000
6500
7000
8000
REVERSE
CURRENT
I
R
µ Adc
100.0
75.0
25.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
REVERSE
VOLTAGE
V
R
Volts
1.0
1.0
1.0
1.0
1.5
2.0
3.0
4.0
5.2
6.0
6.5
7.0
8.0
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.2
56.0
62.2
69.2
76.0
83.6
91.2
98.8
114.0
121.6
136.8
152.0
MAX.DC
CURRENT
I
ZM
(NOTE 3)
MA
749
686
633
574
526
485
440
397
363
330
300
270
247
206
206
189
165
153
137
124
112
102
91
83
74
68
63
56
51
48
43
40
36
33
30
26
25
22
20
18
17
15
13
12
HSMBJ5913B
HSMBJ5914B
HSMBJ5915B
HSMBJ5916B
HSMBJ5917B
HSMBJ5918B
HSMBJ5919B
HSMBJ5920B
HSMBJ5921B
HSMBJ5922B
HSMBJ5923B
HSMBJ5924B
HSMBJ5925B
HSMBJ5926B
HSMBJ5927B
HSMBJ5928B
HSMBJ5929B
HSMBJ5930B
HSMBJ5931B
HSMBJ5932B
HSMBJ5933B
HSMBJ5934B
HSMBJ5935B
HSMBJ5936B
HSMBJ5937B
HSMBJ5938B
HSMBJ5939B
HSMBJ5940B
HSMBJ5941B
HSMBJ5942B
HSMBJ5943B
HSMBJ5944B
HSMBJ5945B
HSMBJ5946B
HSMBJ5947B
HSMBJ5948B
HSMBJ5949B
HSMBJ5950B
HSMBJ5951B
HSMBJ5952B
HSMBJ5953B
HSMBJ5954B
HSMBJ5955B
HSMBJ5956B
DIM
A
B
C
D
E
F
G
DIMENSIONS
INCHES
MILLIMETERS
MIN
MAX
MIN
MAX
.073
.087
1.85
2.21
.160
.180
4.06
4.57
.130
.155
3.30
3.94
.205
.220
5.21
5.59
.075
.130
1.91
3.30
.030
.060
.76
1.52
.006
.016
.15
.41
Mechanical
Characteristics
•
•
•
•
•
Case: Similar to DO-214AA
Terminals: Leads tin plated
Thermal resistance: 25°C/W
(maximum) junction to lead
at mounting plane
Polarity: Cathode indicated
by a band
Packaging: Standard 12 mm
tape 2500 per 13 inch reel
see (EIA Standard RS-481)
MSC1299.PDF
ISO 9001 CERTIFIED
REV E 10/19/99
HSMBJ5913B thru HSMBJ5956B
NOTE 1:
No suffix indicates a ±20% tolerance on nominal VZ. Suffix A denotes a ±10% tolerance, B
denotes a ±5% tolerance, C denotes ±2% tolerance, and D denotes a ±1% tolerance. V
Z
is
measured with diode T
L
at 30°C and thermal equilibrium.
NOTE 2:
Zener impedance is derived from the 1 kHz ac voltage which results when an ac current having an
rms value equal to 10% of dc zener current (I
ZT
or I
ZK
) superimposed on I
ZT
or I
ZK
.
NOTE 3:
Based upon 3 W maximum power dissipation. Allowance has been made for the higher voltage
associated with higher currents and temperature. For determination of voltage change with
current deviations from I
ZT
see Micro Note 202.
P
d
Maximum Power Dissipation (mW)
T
L
Lead Temperature at Mounting Plane
MSC1299.PDF
ISO 9001 CERTIFIED
REV E 10/19/99
