Lift |
Spacing 5.08 mm
AKZ955/..-5.08-GREEN
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
4.0 mm²
0.2mm²
4.0 mm²
0.25 mm²
2.5 mm²
Order Data (Spacing 5.08 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
10.16
15.24
20.32
25.40
30.48
35.56
40.64
45.72
50.80
55.88
60.96
66.04
71.12
76.20
81.28
86.36
91.44
96.52
101.60
106.68
111.76
116.84
121.92
AKZ955/2-5.08-GREEN
AKZ955/3-5.08-GREEN
AKZ955/4-5.08-GREEN
AKZ955/5-5.08-GREEN
AKZ955/6-5.08-GREEN
AKZ955/7-5.08-GREEN
AKZ955/8-5.08-GREEN
AKZ955/9-5.08-GREEN
AKZ955/10-5.08-GREEN
AKZ955/11-5.08-GREEN
AKZ955/12-5.08-GREEN
AKZ955/13-5.08-GREEN
AKZ955/14-5.08-GREEN
AKZ955/15-5.08-GREEN
AKZ955/16-5.08-GREEN
AKZ955/17-5.08-GREEN
AKZ955/18-5.08-GREEN
AKZ955/19-5.08-GREEN
AKZ955/20-5.08-GREEN
AKZ955/21-5.08-GREEN
AKZ955/22-5.08-GREEN
AKZ955/23-5.08-GREEN
AKZ955/24-5.08-GREEN
Poles
Width (mm)
Article Designation
Article
Number
50955020021 F
50955030021 F
50955040021 F
50955050021 E
50955060021 E
50955070021 E
50955080021 D
50955090021 D
50955100021 D
50955110021 D
50955120021 D
50955130021 D
50955140021 D
50955150021 D
50955160021 D
50955170021 D
50955180021 D
50955190021 D
50955200021 D
50955210021 D
50955220021 D
50955230021 D
50955240021 D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
Stripped Length
7.0 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
8
9
10
11
12
Materials
Clamp
Screw
Contact Spring
Brass
Steel
Bronze
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
13
14
15
16
17
18
Colours
GREEN, RAL 6018
BLACK, RAL 9011
LIGHT GREY, RAL 7035
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
19
20
21
22
23
24
Counterparts (Spacing 5.08 mm)
Pin Strip/Terminal Block
AKZ950
STLZ950
STLZ950-HT
STLZ950-G-HT
STLZ970
STLZ990
Accessoires
Figure
Designation
Bridge, 2-pole, insulated,
BRI/2-5.0/5.08-LIGHT GREY
Article Number
Order Data: 50000000006
In combination of connectors with different admission data, the lower value is valid.
Bridge, 3-pole, insulated,
BRI/3-5.0/5.08-LIGHT GREY
Order Data: 50000000007
Bridge, 2-pole,
BR/2-5.0/5.08-L7.0
Order Data: 50000000008
Coding Star CS1-5.0/5.08-RED
Order Data: 50000000021
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
- solid
- stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
12 A
C
-
-
D
300 V
10 A
250 V
9A
III
min
max
2.5 mm² (9 A)
2.5 mm² (9 A)
0.50 Nm
M3
2.0 kV
3
AWG 28-12
AWG 28-12
0.50 Nm
M3
1.60 kV
-
-
-
-
-
AWG 28-12
AWG 28-12
0.50 Nm
M3
1.60 kV
0.2 mm² (2 A)
0.2 mm² (2 A)
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
