MPM-10
Series
Compact, 10W PC Mount
Single, Dual & Dual ISO Out
AC/DC Power Supplies
Electrical Specifications
Key Features:
•
10W Output Power
•
Universal 85-264 VAC Input
•
EN 60950 Approved (UL)
Specifications typical @ +25°C, 230 VAC input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Input Voltage Range
Input Frequency
Conditions
Min.
Typ.
85
120
47
See Model Selection Guide
115 VAC
10.0
230 VAC
20.0
Meets CISPR Pub. 22/FCC Class B
115 VAC
230 VAC
Max.
264
370
63
Units
VAC
VDC
Hz
A Pk
0.1
0.3
Max.
•
Single, Dual & Dual Iso Outputs
Input Current
•
Meets EN 55022 B
Inrush Current
•
>200 kHour MTBF
•
Compact PC Mount Case
EMI
Safety Ground Leakage Current
mA
Units
Output
Parameter
Output Voltage
Output Current
Output Voltage Accuracy
Line Regulation
Load Regulation, See Note 1
Ripple & Noise (20 MHz)
Hold-Up Time
Temperature Coefficient
Short Circuit Protection
Overload Protection
Conditions
Min.
Typ.
See Model Selection Guide
See Model Selection Guide
±2.0
±0.5
See Model Selection Guide
50
115 VAC
20
230 VAC
80
±0.02
Continuous (Autorecovery)
Typ. 110% of Output Power
Conditions
Input to Output
Input to Ground
Output to Ground
Conducted
Electrostatic Discharge (ESD)
RF Field Susceptibility
Electrical Fast Transients/Bursts On Mains
Surge
Min.
3,000
1,500
500
Typ.
%
mV Pk - Pk
mSec
%/°C
General
Parameter
Isolation Voltage
EMI/RFI
EMC Compliance
Switching Frequency
Max.
Units
VAC
EN 55022 Level B
EN 61000-4-2 Level 3 6kV/8kV
EN61000-4-3
EN 61000-4-4 Level 3 2 kV
EN 61000-4-5 Level 3 1kV/2 kV
150
kHz
Min.
-25
Typ.
+25
Units
°C
°C
°C
%
Environmental
Parameter
Conditions
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Case Material
Weight
Max.
Ambient
+70
Case
+90
-25
+105
Free Air Convection (See Derating Curve)
RH, Non-condensing
85
2.16 x 1.77 x 0.81 Inches (55.0 x 45.0 x 20.5 mm)
Non-Conductive Black Plastic (UL94-V0)
4.23 Oz (120g)
Conditions
Min.
Typ.
MIL HDBK 217F, 25°C, Gnd Benign
200
UL 60950, EN 60950
UL, cUL; File No. E245422
Max.
Units
kHours
Reliability Specifications
Parameter
MTBF
Safety Standards
Safety Approvals
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
MPM-10S-03
MPM-10S-05
MPM-10S-09
MPM-10S-12
MPM-10S-15
MPM-10S-24
MPM-10D-05
MPM-10D-12
MPM-10D-15
MPM-10D-24
MPM-10ID-0505
MPM-10ID-0512
MPM-10ID-0515
MPM-10ID-0524
Current
(A)
115
VAC
230
VAC
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
Voltage
(VDC)
www.micropowerdirect.com
Output 1
(Vout 1)
Current
(A)
Rated
2.00
2.00
1.10
0.90
0.70
0.45
+1.00
+0.45
+0.35
+0.20
1.80
1.50
1.40
1.00
Load
Reg.
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±1.0%
±2.0%
±2.0%
±2.0%
±2.0%
±3.0%
±3.0%
±3.0%
±3.0%
Over Volt.
Protection Voltage
(VDC)
(VDC)
Output 2
(Vout 2)
Current
(A)
Rated
Load
Reg.
Output 3
(Vout 3)
Current
(A)
Rated Load
Reg.
Efficiency
(%, Typ)
Over Volt.
Protection Voltage
(VDC)
(VDC)
3.3
5.0
9.0
12.0
15.0
24.0
+5.0
+12.0
+15.0
+24.0
5.0
5.0
5.0
5.0
6.5
6.5
12.0
20.0
20.0
30.0
6.5
20.0
20.0
30.0
6.5
6.5
6.5
6.5
-5.0
-12.0
-15.0
-24.0
5.0
12.0
15.0
24.0
-1.00
-0.45
-0.35
-0.20
0.20
0.20
0.20
0.20
±2.0%
±2.0%
±2.0%
±2.0%
±5.0%
±5.0%
±5.0%
±5.0%
6.5
20.0
20.0
30.0
6.5
20.0
20.0
30.0
70
76
78
80
81
82
76
80
81
84
75
79
79
81
Notes:
1. Load regulation is measured for an output change of 10% to 90% at
nominal input line. For multiple output models, the loads are balanced.
2. The
MPM-10
series is specified for operation over the wide oper-
ating temperature range of -25°C to +55°C without derating. For
operation over +55°C, derate the power linearly by 3.75%/°C from
+55°C to +70°C.
3. Model numbers
MPM-10ID-05xx
are dual isolated units (Dual
ISO). The outputs on these models are isolated from each other.
4. It is recommended that a fuse be used on the input of a power supply
for protection. For the
MPM-10
series, a 2A/250 VAC slow blow
should be used.
Typical Connection
Mechanical Dimensions
Typical Component Values
Vout
C1, C3
C2, C4
Fuse
TVS
3.3
330 ~ 1,000
µF/16V
P6KE6.8A
5.0
330 ~ 1,000
µF/16V
P6KE6.8A
2A/
0.1
µF/50V
250 VAC
12.0
220
µF/25V
P6KE16A
Ceramic
Slow Blow
15.0
220
µF/25V
P6KE20A
24.0
120
µF/35V
P6KE33A
Notes:
1. C1 and C3 are high frequency, low resistance electrolytic capacitors. Refer to the suppliers
specifications for capacitance/current ratings.
2. Voltage derating on all capacitors should be 80% or higher.
3. C2 and C4 eliminate high frequency noise.
4. The TVS is recommended to protect load circuitry in the event of a module failure.
Pin Connections
Pin
1
2
3
4
5
6
7
8
Single
Dual
Dual ISO
AC-Ground AC-Ground AC-Ground
AC-Neutral AC-Neutral AC-Neutral
AC-Line
AC-Line
AC-Line
-Vo 1
-Vo 2
-Vo 1
No Pin
No Pin
+Vo 1
No Pin
Common
No Pin
No Pin
No Pin
-Vo 2
+Vo 1
+Vo 1
+Vo 2
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.01 (
±
0.25)
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
