Polymeric PTC
MPRV Series
Feature and Applications
•
•
•
•
•
•
•
ROHS Compliant (Lead Free) Product
Wide variety of electronic applications
Radial leaded type
Operation Current: 100mA to 3.75A
Maximum Operating Voltage: 120V
Maximum Interrupt Voltage: 135V
Temperature Range: -40ºC to 85ºC
UL E223037
P
ART
N
UMBERING
S
YSTEM
MPRV
Meritek Series
Voltage rating
Current rating
120V
015
Rev.7
Polymeric PTC
MPRV Series
Electrical Characteristics (23ºC)
Part
Number
MPRV120V010
MPRV120V017
MPRV120V020
MPRV120V025
MPRV120V030
MPRV120V040
MPRV120V050
MPRV120V065
MPRV120V070
MPRV120V075
MPRV120V090
MPRV120V100
MPRV120V110
MPRV120V125
MPRV120V130
MPRV120V135
MPRV120V160
MPRV120V185
MPRV120V200
MPRV120V250
MPRV120V300
MPRV120V375
Hold
Current
IH, A
0.10
0.17
0.20
0.25
0.30
0.40
0.50
0.65
0.75
0.75
0.90
1.00
1.10
1.25
1.35
1.35
1.60
1.85
2.00
2.50
3.00
3.75
Trip
Current
IT, A
0.20
0.34
0.40
0.50
0.60
0.80
1.00
1.30
1.50
1.50
1.80
2.00
2.20
2.50
2.70
2.70
3.20
3.70
4.20
5.00
6.00
7.50
Max.Time
to Trip
at 5XIH, Sec
10.0
10.0
9.0
7.5
8.5
6.5
6.0
5.7
6.3
15.0
7.2
15.0
8.2
20.0
9.6
20.0
11.4
12.6
36.0
15.6
19.8
24.0
Maximum
Current
Imax, A
2.0
2.0
2.0
3.0
3.0
3.0
3.0
5.0
5.0
7.5
5.0
10.0
8.0
12.5
10.0
13.5
12.0
12.0
20.0
15.0
17.0
20.0
Rated
Voltage
Vmax, V
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
Typical
Power
Pd, W
0.84
0.84
1.08
1.08
1.44
1.44
1.56
1.68
1.80
2.64
1.80
2.64
2.28
2.88
2.64
3.12
3.12
3.36
4.32
4.44
4.56
4.80
Resistance Tolerance
Rmin
R1max.
ohms
ohms
3.00
7.50
2.00
1.83
1.25
0.88
0.55
0.50
0.31
0.25
0.25
0.20
0.18
0.15
0.11
0.12
0.11
0.09
0.08
0.08
0.05
0.04
0.03
7.00
4.40
3.00
2.10
1.29
1.17
0.72
0.60
0.69
0.47
0.47
0.38
0.33
0.30
0.30
0.22
0.19
0.21
0.13
0.10
0.08
I
H
=Hold current-maximum current at which the device will not trip at 23ºC still air.
I
T
=Trip current-minimum current at which the device will always trip at 23ºC still air.
V
MAX
=Maximum voltage device can withstand without damage at its rated current (I
MAX
)
I
MAX
= Maximum fault current device can withstand without damage at rated voltage (V
MAX
).
Pd=Typical power dissipated-type amount of power dissipated by the device when in the tripped state in 23ºC still air
environment.
R
min
=Minimum device resistance at 23ºC prior to tripping.
R1
MAX
=Maximum device resistance at 23ºC measured 1 hour after tripping or reflow soldering of 260ºC for 20 seconds.
Termination pad characteristics
Termination pad materials: Pure Tin
Rev.7
Power technology
