ICTE5.0 to ICTE15C MPTE-5 to MPTE-45
1N6373 to 1N6381 and 1N6382 to 1N6389
GLASS PASSIVATED JUNCTION TRANSIENT VOLTAGE SUPPRESSOR
STANDOFF VOLTAGE- 5.0 to 45.0V
1500 Watt Peak Power
FEATURES
• Plastic package has Underwriters Laboratory
Flammability Classification 94 V-O
• Glass passivated chip junction in Molded Plastic package
• 1500W surge capability at 1ms
• Excellent clamping capability
• Low zener inpedance
• Fast response time: typically less than
1.0 ps from 0 volts to BV min.
• Typical IR less than 1µA above 10V
• High temperature soldering guaranteed:
250°C/10 seconds/ .375", (9.5mm) lead
length, 5lbs., (2.3kg) tension
• Includes 1N6373 thru 1N6385
MECHANICAL DATA
Case: JEDEC DO-201 Molded plastic
Terminals: Plated Axial leads, solderable per
MIL-STD-750, Method 2026
Polarity: Color band denoted positive end (cathode)
except Bipolar
Mounting Position: Any
Weight: 0.045 ounces, 1.2 grams
MAXIMUM RATINGS AND CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
RATING
Peak Pulse Power Dissipation at TA = 25 °C, TP = 1ms
(NOTE 1)
SYMBOL
P
PPM
I
PPM
VALUE
Minimum 1500
SEE TABLE 1
5.0
200
3.5
-55 +175
UNITS
Watts
Amps
Watts
Amps
Volt
°C
Peak Pulse Current of on 10/1000 µs waveform
(Note 1)
Steady State Power Dissipation at
T
L
= 75°C
Lead lengths .375", 9.5mm
(Note 2)
Peak Forward Surge Current, 8.3ms Single Half Sine-wave
Superimposed on Rated Load,
(JEDEC Method)(Note 3)
Maximum instantaneous forward voltage at 100A for
unidirectional only
Operatings and Storage Temperature Range
P
M
(AV)
I
FSM
V
F
T
J
, T
STG
NOTES:
1. Non-repetitive current pulse, per Fig.3 and derated above Ta=25 °C per Fig.2.
2. Mounted on Copper Pad area of 0.8x0.8" (20x20mm) per Fig.5.
3. 8.3ms single half sine-wave, or equivalent square wave, Duty cycle=4 pulses per minutes maximum.
Certified RoHS Compliant
UL File # E223026
11/13/2013
MDE Semiconductor, Inc.
78-150 Calle Tampico, Unit 210, La Quinta, CA., USA 92253 Tel : 760-564-8656 • Fax : 760-564-2414
1-800-831-4881 Email: sales@mdesemiconductor.com Web: www.mdesemiconductor.com
ICTE5.0 to ICTE15C MPTE-5 to MPTE-45
1N6373 to 1N6381 and 1N6382 to 1N6389
GLASS PASSIVATED JUNCTION TRANSIENT VOLTAGE SUPPRESSOR
STANDOFF VOLTAGE- 5.0 to 45.0V
1500 Watt Peak Power
REVERSE
MINIMUM
MAXIMUM
STANDOFF BREAKDOWN REVERSE
VOLTAGE
VOLTAGE
LEAKAGE
(VRWM)
VBR @ 1mA
IR @ Vr
(µA)
(V)
(Volts)
MINIMUM
CLAMPING
VOLTAGE
(Vc) @
Ipp=1A
(Volts)
MAXIMUM
CLAMPING
VOLTAGE
(Vc) @
Ipp=1A
(Volts)
MAXIMUM
PEAK
PULSE
CURRENT
Ipp (A)
Part Numbers
ICTE-5*
ICTE-8
ICTE-10
ICTE-12
ICTE-15
ICTE-18
ICTE-22
ICTE-36
ICTE-45
ICTE-8C
ICTE-10C
ICTE-12C
ICTE-15C
ICTE-18C
ICTE-22C
ICTE-36C
ICTE-45C
1N6373
1N6374
1N6375
1N6376
1N6377
1N6378
1N6379
1N6380
1N6381
1N6382
1N6383
1N6384
1N6385
1N6386
1N6387
1N6388
1N6389
MPTE-5*
MPTE-8
MPTE-10
MPTE-12
MPTE-15
MPTE-18
MPTE-22
MPTE-36
MPTE-45
MPTE-8C
MPTE-10C
MPTE-12C
MPTE-15C
MPTE-18C
MPTE-22C
MPTE-36C
MPTE-45C
5*
8.0
10.0
12.0
15.0
18.0
22.0
36.0
45.0
8.0
10.0
12.0
15.0
18.0
22.0
36.0
45.0
6.0
9.4
11.7
14.1
17.6
21.2
25.9
42.4
52.9
9.4
11.7
14.1
17.6
21.2
25.9
42.4
52.9
300.0
25.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
50
2.0
2.0
2.0
2.0
2.0
2.0
2.0
7.1
11.3
13.7
16.1
20.1
24.2
29.8
50.6
63.3
11.4
14.1
16.7
20.8
24.8
30.8
50.6
63.3
7.5
11.5
14.1
16.5
20.6
25.2
32.0
54.3
70.0
11.6
14.5
17.1
21.4
25.5
32.0
54.3
70.0
160.0
100.0
90.0
70.0
60.0
50.0
40.0
23.0
19.0
100.0
90.0
70.0
60.0
50.0
40.0
23.0
19.0
*ICTE-5 is not available in Bi-directional.
Certified RoHS Compliant
UL File # E223026
Suffix 'C' denotes Bi-directional device.
11/13/2013
