MSA_(M)D-3W & MSB_(M)D-3W Series
3W, WIDE INPUT, ISOLATED & REGULATED
DUAL/SINGLE OUTPUT DIP DC-DC CONVERTER
multi-country patent protection
FEATURES
●
Wide (2:1) input range
●
Efficiency up to 82%
●
Operating temperature: -40°C ~ +85°C
●
1500VDC isolation
●
Short circuit protection(Automatic recovery)
●
Internal SMD construction
●
No heat sink required
●
No external component required
●
UL94-V0 package
●
Industry standard pinout
●
MTBF>1,000,000 hours
●
RoHS Compliance
PRODUCT PROGRAM
Input
Part
Number
MSA0505(M)D-3W
MSA0512(M)D-3W
MSA0515(M)D-3W
MSB0505(M)D-3W
MSB0509(M)D-3W
MSB0512(M)D-3W
MSB0515(M)D-3W
MSA1205(M)D-3W
MSA1212(M)D-3W
MSA1215(M)D-3W
MSB1205(M)D-3W
MSB1209(M)D-3W
12
9-18
22
5
4.5-9
11
Voltage (VDC)
Nominal Range
Voltage
Max* (VDC)
±5
±12
±15
5
9
12
15
±5
±12
±15
5
9
12
15
24
±5
±12
±15
3.3
24
18-36
40
5
9
12
15
24
±5
±12
±15
3.3
48
36-72
80
5
9
12
15
24
Output
Current (mA)
Max.
±300
±125
±100
600
333
250
200
±300
±125
±100
600
333
250
200
125
±300
±125
±100
909
600
333
250
200
125
±300
±125
±100
909
600
333
250
200
125
Min.
±30
±12
±10
60
33
25
20
±30
±12
±10
60
33
25
20
12
±30
±12
±10
90
60
33
25
20
12
±30
±12
±10
90
60
33
25
20
12
68
72
73
68
70
72
73
76
79
80
76
78
80
81
82
76
80
81
74
76
78
81
80
82
76
80
81
74
76
78
81
80
82
UL
UL
UL
UL
UL
Efficiency
Certificate
(%, Typ)
APPLICATIONS
The MSA_(M)D-3W &MSB_(M)D-3W Series
are specially designed for applications where a
wide range input voltage power supplies are
isolated from the input power supply in a
distributed power supply system on a circuit
board. These products apply to:
1) Where the voltage of the input power supply is
wide range (Voltage range≤ 2:1);
2) Where isolation is necessary between input
and output(Isolation voltage≤1500VDC);
3) Where the regulation of the output voltage and
the output ripple noise are dem anded.
MSB1212(M)D-3W
MSB1215(M)D-3W
MSB1224(M)D-3W
MSA2405(M)D-3W
MSA2412(M)D-3W
MSA2415(M)D-3W
MSB2403(M)D-3W
MSB2405(M)D-3W
MSB2409(M)D-3W
MSB2412(M)D-3W
MSB2415(M)D-3W
MSB2424(M)D-3W
MSA4805(M)D-3W
MSA4812(M)D-3W
MSA4815(M)D-3W
MODEL SELECTION
MSB4803(M)D-3W
MSB4805(M)D-3W
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
MSA2405MD-3W
MSB4809(M)D-3W
MSB4812(M)D-3W
MSB4815(M)D-3W
MSB4824(M)D-3W
* Input voltage over it may cause permanent damage to the device.
Note: Metal package style’s series is MSA_MD-3W & MSB_MD-3W.
MORNSUN Science & Technology co.,Ltd.
Address: 2th floor 6th building, Hangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
http://www.mornsun-power.com
ISOLATION SPECIFICATIONS
Item
Isolation voltage
Isolation resistance
Isolation capacitance
Test conditions
Tested for 1 minute and 1mA max
Test at 500VDC
Input/Output
Min.
1500
1000
80
Typ.
Max.
Units
VDC
MΩ
pF
The copyright and authority for the interpretation of the products are reserved by Mornsun
Specifications subject to change without notice.
MSA_((M)D-3W&MSB_(M)D-3W
A/2-2009
Page 1 of 3
OUTPUT SPECIFICATIONS
Item
Output power
Positive voltage accuracy
Load regulation
Line regulation
Temperature drift(Vout)
Ripple & Noise**
Switching frequency
Test conditions
See below products program
Refer to recommended circuit
From 10% to 100% load
Input voltage from low to high
Refer to recommended circuit
20MHz Bandwidth
100% load, nominal input voltage
50
300
Min.
0.3
±1
±3
±0.5
±0.2
Typ.
Max.
3
±3
±5
±1*
±0.5
±0.03
100
%/
°
C
mVp-p
KHz
%
Units
W
TYPICAL CHARACTERISTICS
Negative voltage accuracy Refer to recommended circuit
*Dual output models unbalanced load:
±5%.
**Test ripple and noise by
“parallel
cable” method. See detailed operation instructions at Testing of Power
Converter section, application notes.
100
Operating Temp.(
C
)
COMMON SPECIFICATIONS
Item
Storage humidity
Operating temperature
Storage temperature
Temp. rise at full load
Lead temperature
No-load Power consumption
Cooling
Short circuit protection
Case material
MTBF
Weight
Free air convection
Continuous, Automatic Recovery
D: Plastic (UL94-V0);
MD: Steel, Nickel Coated
1000
15
K hours
1.5mm from case for 10 seconds
0.2
-40
-55
15
300
W
Test Conditions
Min.
Typ.
Max.
95
85
125
°C
Units
%
RECOMMENDED CIRCUIT
Vin
Cin
+Vout
DC
DC
0V
-Vout
GND
Single Output
Vin
Cin
+Vout
DC
DC
0V
GND
(Figure 1)
g
Input Current(A)
Ip
APPLICATION NOTE
Requirement On Output Load
In order to ensure the product operate efficiently and reliably, in addition to a max load
(namely full load), a minimum load is specified for this kind of DC/DC converter. Make sure the
specified range of input voltage is not exceeded, the minimum output load no less than 10%
load. If the actual load is less than the specified minimum load, the output ripple may increase
sharply while its efficiency and reliability will reduce greatly. If the actual output power is very
small, please add an appropriate resistor as extra loading, or contact our company for other
lower output power products.
Recommended Circuit
All the MSA_(M)D-3W & MSB_(M)D-3W Series have been tested according to the following
recommended testing circuit before leaving factory. This series should be tested under load.
Never be tested under no load (see Figure 1).
If you want to further decrease the input/output ripple, you can increase capacitance properly
or choose capacitors with low ESR. However, the capacitance of the output filter capacitor must
be proper. If the capacitance is too big, a startup problem might arise. For every channel of
output, provided the safe and reliable operation is ensured, the greatest capacitance of its filter
capacitor sees (Table 1). Generally: If you want to use the products in high EMI, please choose
our metal packaged products (MSA_MD-3W & MSB_MD- 3W). General:
Cin:
5V&12V
24V&48V
100μF
10μF-47μF
Input Voltage
Range
Input Voltage (V)
Output External Capacitor Table(Table 1)
Single Vout
Cout
Dual Vout
Cout
(VDC)
(uF)
(VDC)
(uF)
5
1000
±5
680
9
680
±9
470
12
470
±12
330
15
330
±15
220
24
220
±24
100
Cout: 10μF/100mA
Input Current
When it is used in unregulated power supply, be sure that the fluctuating range of the power
supply and the rippled voltage do not exceed the module standard. Input current of power
supply should afford the startup current of this kind of DC/DC module (See figure 2), General:
Ip
≤1.4*Iin-max
No parallel connection or plug and play
The copyright and authority for the interpretation of the products are reserved by Mornsun
Specifications subject to change without notice.
MSA_((M)D-3W&MSB_(M)D-3W
A/2-2009
Page 2 of 3
OUTLINE DIMENSIONS & PIN CONNECTIONS
MECHANICAL DIMENSIONS
MS_MD
31.50[1.240]
31.80[1.252]
15.24 [0.600]
2.54 [0.100]
MS_D
RECOMMENDED FOOTPRINT
DUAL OUTPUT
24 23 22
∅
1.00 [
∅
0.039]
15 14 13
20.00 [0.787]
20.30 [0.799]
15.24 [0.600]
1 2 3
(Bottom View )
10 11 12
1 2 3
10 11 12
24 23 22
MS_MD
MS_D
15 14 13
2.54 [0.100]
27.94 [1.100]
SINGLE OUTPUT
2.54 [0.100]
27.94 [1.100]
24
15 14 13
4.10 [0.161]
10.00[0.394]
9.50[0.374]
1
10 11 12
(Side View)
MS_MD
MS_D
TUBE OUTLINE DIMENSIONS
22.70 [0.894]
11.60[0.457]
0.50 [0.020]
FOOTPRINT DETAILS
Single
Dual
Pin
Vin
Vin
1,24
2,23
No Pin
-Vo
3,22
No Pin
0V
10,15
0V
0V
11,14
+Vo
+Vo
12,13
GND
GND
NC:No connection
0.60 [0.024]
18.20 [0.717]
Note:
Unit:mm[inch]
Pin diameter tolerances:
±
0.10mm[
±
0.004inch]
General tolerances:
±
0.25mm[
±
0.010inch]
11.30 [0.445]
Note:
Unit :mm[inch]
General tolerances:
±0.50mm[±0.020inch]
L=530mm[20.866inch] Tube Quantity: 15pcs
L=220mm[8.661inch] Tube Quantity: 6pcs
Note:
1. The load shouldn't be less than 10%, otherwise ripple will increase dramatically.
2. Operation under 10% load will not dam age the converter; However, they may not meet all specification listed.
3. All specifications measured at Ta=25°C, humidity<75%, nominal input voltage and rated output load unless otherwise specified.
4. In this datasheet, all the test methods of indications are based on corporate standards.
5. Only typical models listed, other models may be different, please contact our technical person for more details.
The copyright and authority for the interpretation of the products are reserved by Mornsun
Specifications subject to change without notice.
MSA_((M)D-3W&MSB_(M)D-3W
