SPECIFICATIONS
Current Rating:
Insulation Resistance:
Wire Strip Length:
Wire Range:
Withstanding:
Operating Temp:
A
6 Amp AC150V
2000MΩ min DC500V
10mm
20~26 AWG
AC 2000V min
40ºC to +105ºC
B
C
D
E
Item
1
2
3
4
5
Name
Insulating Body
Terminal
Lever
Cover
Spring
Material
Polyamide 66 UL94V-0
Brass
Polyamide 66 UL94V-0
Polyamide 66 UL94V-0
Stainless Strip Steel
Finish
Green
Tin Plating
Orange
Green
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
Series
CMTB
Terminal blocks
Type
MX422
Side Entry
Screwless
Pitch
254
254=2.54mm
Dimensions mm
A
Poles
8.08
15
10.62
16
13.16
17
15.70
18
18.24
19
20.78
20
23.32
21
25.86
22
28.40
23
30.94
24
33.48
25
36.02
38.56
Positions
XX
02-25
A
41.10
43.64
46.18
48.72
51.26
53.80
56.34
58.88
61.42
63.96
66.50
C
D
E
Color
GN
GN=Green
F
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Date
06/26/06
06/26/06
06/26/06 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CMTB-MX422-254-XX-GN
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Terminal Block, Side Entry Screwless
