IC SOCKETS
Competitively priced products
Low profile
Through hole or surface mount
20, 28, 32, 44, 52, 68 and 84way
Material - PBT and PPS
PLCC
SPECIFICATION
SuRFACE MOuNT
Current Rating:
Contact Material:
Contact Plating:
1A
Phosphor Bronze
Tin or Selective Plated
No. of
Contacts
20
28
32
44
52
68
84
A
±0.2
5.08
7.62
7.62
12.70
15.24
20.32
25.40
B
±0.2
15.64
18.82
18.82
23.28
25.84
30.94
36.04
C
±0.2
5.08
1.62
10.16
12.70
15.24
20.32
25.40
D
±0.1
15.64
18.28
20.82
23.28
25.84
30.94
36.40
E
±0.1
12.72
15.27
17.80
20.32
22.90
27.94
33.06
Insulator Material:
(1) 30% Glass Filled P.B.T. (UL94V-0) - Through hole
(2) 40% Glass Filled P.P.S. (UL94V-0) - Surface Mount
Dielectric Withstanding Voltage:
AC 600 V
1000 MΩ min.
Insulation Resistance:
Contact Resistance:
20 MΩ max.
Operating Temperature:
-45˚C to +105˚C.
THROuGH HOLE
No. of
Contacts
20
28
32
44
52
68
84
4.5
A
±0.2
15.50
18.00
18.00
23.58
25.90
31.80
36.70
B
±0.2
15.50
18.00
20.58
23.58
25.90
31.80
36.70
C
±0.2
16.70
20.38
22.34
27.60
31.40
38.34
45.60
D
±0.1
5.08
7.62
7.62
12.70
15.24
20.32
25.40
E
±0.1
5.08
7.62
10.16
12.70
15.24
20.32
25.40
OUTLINE DRAWING
4.5
SECTION 14
A
1.27
C D
A
B
A
B
1.52
0.55
A
A
0.55
4.5
C
C
C
D
D
0.55
1.27
C
1.27
E
E
E
E
C D
0.55
1.5
7
D
A
D
A
0.55
1.5
8.3
8.3
3.3
A
7.7
3.3
7.7
1.2
1.2
E
C
A
SuRFACE MOuNT
A
1.50
E
C
THROuGH HOLE
52
ORDERING INFORMATION
DBC
Dubilier
Connectors
1.50
PLCC
Series
PLCC
20=20way
0.55
28=28way
32=32way
44=44way
20
No. of Ways
0.55
SMT
Package Style
SMT=Surface
Mount
Blank=Through
Hole
TR
Options
TR=Tape+Reel
Blank=Loose
52=52way
68=68way
84=84way
316
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
