Features
SERIES
ALUMINUM ELECTROLYTIC CAPACITORS
105˚C, Bi-Polar Standard, Radial Leads
• Bi-polar, Radial
• Ideal for inconsistent polarity circuits
• High performance
• load life of 1000 hours at 105˚C
n
Specifications
Item
Operating temperature range
Rated working voltage range
Nominal capacitance range
D.C Leakage current(at 20˚C)
Performance Characteristics
-40˚C ~ +105˚C
10V ~ 50V
0.47µF ~ 1000µF ±20%(at 20˚C, 120Hz)
,
The following specifications shall be satisfied when the rated voltage is applied for
the required time.
I
≤
0.03CV or 3µA(5 min), whichever is greater
Where I=Leakage current(µA)
C=Nominal capacitance(µF)
V=Rated voltage(V)
10
16
25
50
W.V(V)
W.V(V)
Z-25˚C/Z20˚C
10
3
16
2
25
2
50
2
Tan (max., at 20˚C, 120Hz)
Characteristics
at low temperature(max.)
(impedance ratio at 120Hz)
Load life
Shelf life
After applying rated working voltage for 1000 hours at +105˚C with the polarity
inverted every
250 hours and then being stabilized at +20˚C, capacitors shall meet following
limits.
Capacitance change
Within ±20% of initial measured value
Tan
≤
200% of initial specified value
Leakage current
≤
Intial specified value
After storage for 500 hours at +105˚C with no voltage applied and then being
stabilized at +20˚C, capacitors shall meet following limits.
Capacitance change
Within ±20% of initial measured value
n
Case sizes and Dimensions
n
Dimensions & Maximum permissible ripple current [mA(rms) at 105˚C, 120Hz]
øD x L ( m m )
15.0
ød
4.0
•
Standard lead style
øD
p
ød
5.0
2.0
6.3
2.5
8.0
3.5
10.0
13.0
5.0
16.0
7.5
D’= [D +0.5]Max.
10.0
L’= [L+1.0]Max. at D
≤
8.0
L’ = [L+1.5]Max. at D
≥
W.V
10
Cap(µF)
SIZE
0.47
1.0
2.2
3.3
4.7
10
22
5x11
33
6.3x11
47
6.3x11
100
220
8x11.5
330
10x16
470
10x20
1000
13x20
I
R
16
SIZE
25
I
R
50
I
R
SIZE
44
58
75
118
190
245
330
570
6.3x11
6.3x11
8x11.5
10x12.5
10x20
13x20
13x25
55
70
89 8x11.5
135
252 10x12.5
320 10x16
410 13x20
670
5x11
5x11
6.3x11
21
35
62
80
105
171
310
SIZE
5x11
5x11
5x11
5x11
6.3x11
8x11.5
10x12.5
10x16
10x20
13x20
I
R
8
11
18
22
29
50
85
110
143
243
65
Talking
