893-011-1-4AA5-0D3-T2 Overview

Circular Connector

893-011-1-4AA5-0D3-T2 Parametric

Parameter Name	Attribute value
Maker	Glenair
Reach Compliance Code	compliant
Connector type	CIRCULAR CONNECTOR
Manufacturer's serial number	893-011

Preview

Download Datasheet

View All

Circular

Nanominiatures

893-011

Circular Threaded, Rear Panel Mount Receptacle

Connector with Right Angle PCB Termination

Glenair Rear Panel Mount Threaded Right Angle

PCB Connectors

feature gold alloy TwistPin contacts,

offering premium performance and reliability for demanding

applications. Available with or without backshell, overmolded

or shrink boot.

B

C

MATES

WITH 892-006

from 4 to 55 contacts. These connectors are intermateable with

nanominiature plug connectors 892-006 plug connectors.

excellent solderability.

How To Order Circular Nano Connectors

Choose Aluminum or Stainless Steel Shells

in 6 layouts

Pre-Tinned PC Tails

are coated with Sn63-Pb37 tin-lead for

Sample Part Number

Series

Shell Style

Shell Size/Contact

Arrangement

Polarization

Shell Material/Finish

Wire Gauge

Wire Type

90 Degree PC Tail

Length (inches)

893

- Nano Circular with PCB Termination

011

- Rear Panel Mount Threaded Coupling Receptacle

1-4

- Shell Size 1 with 4 contacts

1-7

- Shell Size 1 with 7 contacts

2-19

- Shell Size 2 wih 19 contacts

See Table 1

N

- Normal

A

- Alternate

A2

- Aluminum/Electroless Nickel

A5

- Aluminum/Gold Over Nickel

0

- 30 AWG

893

-011

-1-7

N

A2

-0

D3 -T1

3-37

- Shell Size 3 with 37 contacts

4-44

- Shell Size 4 with 44 contacts

4-55

- Shell Size 4 with 55 contacts

S1

- Stainless Steel/Zinc Cobalt (Black)

S2

- Stainless Steel/Passivated

D3

- Single Strand Copper Alloy Wire Uninsulated, Pre-tinned

T1

- .080” Lead Top

T2

- .110’ Lead Top

T3

- .140” Lead Top

T4

-.170” Lead Top

B1

- .080” Lead Bottom

B2

- .110” Lead Bottom

B3

- .140” Lead Bottom

B4

- .170” Lead Bottom

Size 1-4

4 Contacts

2

1

Size 1-7

7 Contacts

2

5

1

3

7

6

Table 1: Circular Receptacle Mating Face Views

Size 2-19

Size 3-37

19 Contacts

37 Contacts

3

7

12

16

19

17

1

4

Size 4-44

44 Contacts

11

18

26

33

39

44

40

5

1

6

12

19

27

34

Size 4-55

55 Contacts

16

24

31

93

46

52

41391016172425313239404647525355

9

15

22

28

33

4

1

5

10

16

23

9

3

1

4

10

8

13

4

3

37

34

29

55

53

17

25

32

40

47

Table 2: Rear Panel Mount Panel Cut-out

Size

1-4

1-7

2-19

3-37

4-44

4-55

C +.002 / -.001

.260 (6.7)

.318 (7.8)

.361 (9.2)

.401 (10.2)

Ø S + .002/ -.001

.280 (7.1)

.340 (8.7)

.378 (9.6)

.398 (10.7)

C

ØD

Material/Finish:

•

Shell/spanner nut - see part number breakdown

Insulator - LCP/na

Socket contacts - gold alloy

O-rings - flourosilicone/na

Internal latching spring - stainless steel/gold plated

PCB tray(s) - LCP/na

PC tails - copper alloy/pre-tinned Sn63-Pb37

Dimensions in inches (millimeters) and are subject to change without notice.

Series 89 Nano Catalog

U.S. CAGE Code 06324/0CA77

Printed in U.S.A.

GLENAIR, INC.

•

1211 AIR WAY

•

GLENDALE, CA 91201-2497

•

818-247-6000

•

FAX 818-500-9912

www.glenair.com

C-8
