SRA2202SF Overview

PNP Silicon Transistor

Semiconductor
SRA2202SF
PNP Silicon Transistor
Descriptions
Switching application
Interface circuit and driver circuit application
Features
With built-in bias resistors
Simplify circuit design
Reduce a quantity of parts and manufacturing process
High packing density
Ordering Information
Type NO.
SRA2202SF
Marking
RA2
Package Code
SOT-23F
Outline Dimensions
2.4±0.1
1.6±0.1
unit :
Equivalent Circuit
C(OUT)
mm
1
2.9±0.1
1.90 BSC
3
0.4±0.05
B(IN)
R
1
2
0.15±0.05
R
2
E(COMMON)
0.9±0.1
0~0.1
PIN Connections
1. Base
2. Emitter
3. Collector
R
1
10KΩ
R
2
10KΩ
KSR-2010-000
1
