ALUMINUM ELECTROLYTIC CAPACITORS
LS
Snap-in Terminal Type, Smaller-Sized
series
Withstanding 3000 hours application of ripple current at 85°C.
One rank smaller case sized than LU series.
Higher production efficiency due to 4.0mm long terminal.
LU
Smaller
LS
Specifications
Item
Performance Characteristics
Category Temperaturer Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
– 40 ~ + 85°C (16~250V), – 25 ~ + 85°C (350 ~ 450V)
16 ~ 450V
56 ~ 56000µF
± 20% at 120Hz, 20°C
I
3 CV
(µA) (After 5 minutes' application of rated voltage) [C : Rated Capacitance (µF) V : Voltage(V)]
Rated voltage (V)
tan
δ
(MAX.)
16
0.50
25
0.40
35
0.35
50
0.30
16 ~ 100
4
20
63
0.25
80
0.20
100
0.20
Measurement frequency :120Hz, Temperature : 20°C
180
200
250
350
400
450
0.15
0.15
0.15
0.15
0.15
0.15
0.20
160
350 ~ 450
8
—
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
ZT/Z20(MAX.)
Z—25°C/ Z+20°C
Z—40°C/ Z+20°C
160 ~ 250
3
12
Endurance
After an application of DC voltage (in the range of rated
DC voltage even after over-lapping the specified ripple
current) for 3000 hours at 85°C, capacitors meet the
characteristic requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
After leaving capacitors under no load at 85°C
for 1000 hours, they meet the requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±15% of initial value
150% or less of initial specified value
Initial specified value or less
Marking
Printed with white color letter on black sleeve.
Drawing
Polarity bar
Bottom plate
φD
+1MAX.
Sleeve
Type numbering system ( Example
:
200V 390
µ
F)
1
2
3
4
5
6
7
8
9 10
11 12
L L S 2 D 3 9 1 MH L Z
Case dia.code
Configuration
Capacitance tolerane(±20%)
φ
D
20
22
25
30
35
Code
Y
Z
A
B
C
10
L±
2
Rated Capacitance(390µF)
Rated voltage(200V)
Pressure relief vent
4.0±0.5
Series name
0.8
+0.2
-0.1
4.0±0.5
10
±
0.1
0.8
.2
+0 1
-0.
Type
2-2φ±
0.1
2.5
1.5
+0.2
-0.1
(Terminal dimensions)
The other terminal is also available upon request.
Please refer to page 195 for schematic of dimensions.
(PC board hole dimensions)
Frequency coefficient of rated ripple current
Frequency (Hz)
16~ 100V
160~ 250V
350~ 450V
50
0.88
0.81
0.77
60
0.90
0.85
0.82
120
1.00
1.00
1.00
300
1.07
1.17
1.16
1k
1.15
1.32
1.30
10k
1.15
1.45
1.41
50k~
1.15
1.50
1.43
Coeff.
Minimum order quantity : 50pcs.
Dimension table in next page.
CAT.8100R
