R3N
miniature industrial relays
10 A / 250 V AC
• Relays of general application • For plug-in sockets: 35 mm rail mount
acc. to PN-EN 60715; on panel mounting • Miniature dimensions •
Cadmium - free contacts • AC and DC coils
• WT (mechanical indicator + lockable front test button) - standard
features of relays. Relays may be provided with the test buttons (no
latching) and plugs - page 10
• Recognitions, certifications, directives: RoHS,
3 CO
AgNi,
AgNi/Au 0,2 µm
250 V / 440 V
10 V
10 A / 250 V AC
3 A / 120 V
1,5 A / 240 V (B300)
370 W (single-phase motor)
10 A / 24 V DC (see Fig. 3)
0,22 A / 120 V 0,1 A / 250 V (R300)
5 mA
20 A
10 A
2 500 VA
0,3 W
100 m
1 200 cycles/hour
18 000 cycles/hour
6 ... 240 V
5 ... 220 V
AC:
0,2 U
n
see Tables 1, 2
1,6 VA
0,9 W
250 V AC
4 000 V
1,2 / 50 µs
III
2
2 500 V AC
1 500 V AC
2 500 V AC
2,5 mm
4 mm
AC:
10
type of insulation: basic
type of clearance: micro-disconnection
type of insulation: basic
Contact data
Number and type of contacts
Contact material
Rated / max. switching voltage
Min. switching voltage
Rated load (capacity)
AC
AC1
AC15
AC3
DC1
DC13
Min. switching current
Max. inrush current
Rated current
Max. breaking capacity
Min. breaking capacity
Contact resistance
Max. operating frequency
• at rated load
• no load
AC1
AC1
Coil data
Rated voltage
Must release voltage
Operating range of supply voltage
Rated power consumption
50/60 Hz
AC
DC
DC:
0,1 U
n
Insulation
according to PN-EN 60664-1
Insulation rated voltage
Rated surge voltage
Overvoltage category
Insulation pollution degree
Dielectric strength
• between coil and contacts
• contact clearance
• pole - pole
Contact - coil distance
• clearance
• creepage
AC
DC
General data
The data in bold type pertain to the standard versions of the relays.
www.relpol.com.pl
Export Sales Department
phone +48 68 47 90 832, 951
•
e-mail: export@relpol.com.pl
14.07.2014
Operating / release time (typical values)
Electrical life
• resistive AC1
• cos
Mechanical life (cycles)
Dimensions (L x W x H)
Weight
Ambient temperature
• storage
• operating
Cover protection category
Environmental protection
Shock resistance
(NO/NC)
Vibration resistance
ms / 8 ms
DC:
13
ms / 3 ms
10 A, 250 V AC
> 10
5
see Fig. 2
> 2 x 10
7
27,5 x 21,2 x 35,6 mm
35 g
-40...+85
o
C
AC:
-40...+55
o
C
IP 40
PN-EN 60529
RTI
PN-EN 116000-3
10 g / 5 g
5 g
10...150 Hz
DC:
-40...+70
o
C
1
R3N
miniature industrial relays
Coil data
- DC voltage version
Coil code
1005
1006
1012
1024
1048
1060
1080
1110
1125
1220
Table 1
Coil resistance
at 20 °C
28
40
160
640
2 600
4 000
7 100
13 600
16 000
54 000
Rated voltage
V DC
5
6
12
24
48
60
80
110
125
220
Acceptable
resistance
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
Coil operating range
V DC
min. (at 20 °C)
4,0
4,8
9,6
19,2
38,4
48,0
64,0
88,0
100,0
176,0
max. (at 55 °C)
5,5
6,6
13,2
26,4
52,8
66,0
88,0
121,0
137,5
242,0
The data in bold type pertain to the standard versions of the relays.
Coil data
- AC 50/60 Hz voltage version
Coil code
5006
5012
5024
5042
5048
5060
5080
5110
5115
5120
5127
5220
5230
5240
Table 2
Coil resistance
at 20 °C
9,8
39,5
158
470
640
930
1 720
3 450
3 610
3 770
4 000
15 400
16 100
16 800
Rated voltage
V AC
6
12
24
42
48
60
80
110
115
120
127
220
230
240
Acceptable
resistance
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
Coil operating range
V AC
min. (at 20 °C)
4,8
9,6
19,2
33,6
38,4
48,0
64,0
88,0
92,0
96,0
101,6
176,0
184,0
192,0
max. (at 55 °C)
6,6
13,2
26,4
46,2
52,8
66,0
88,0
121,0
127,0
132,0
139,0
242,0
253,0
264,0
The data in bold type pertain to the standard versions of the relays.
NEW TECHNOLOGY
The new R2N, R3N, R4N relays are modernized versions
of the R2, R3, R4 relays. The modernization covered
the design of the relays and the manufacturing process.
www.relpol.com.pl
Export Sales Department
phone +48 68 47 90 832, 951
•
e-mail: export@relpol.com.pl
14.07.2014
2
R3N
miniature industrial relays
Dimensions
- plug-in version (WT),
with lockable front test button type T
Design
Dimensions
- plug-in version, with test button
(no latching) or with plug (no manual operation)
Improvement of the functionality of the mechanical
indicator (W):
it is mounted on an insulation base of
the unit of the movable contacts; the changes provide
the appropriate position in the window in the upper side
of the housing irrespectively of the number of operations
performed by the relay.
Test buttons R4P-0001
and
plugs R4W-0003
need
to ordered saparately. They substitute buttons type T.
To exchange by Customer themselves. Information
on test buttons (no latching) and plugs - page 10.
Application of electronics made in the SMD techno-
logy:
additional features L (LED diode) and D (diode)
are located on the printed circuit board; the change
of the position of the LED diode and optimization
of the quality and intensity of its light provide certainty
that the relay is in operation status when the LED is on.
Connection diagram
(pin side view)
3 CO
Strengthening of the insulation in the area of the
contact plate:
polyamide PA66 has been applied; it has
very good mechanical and electrical parameters and best
thermal properties.
www.relpol.com.pl
Export Sales Department
phone +48 68 47 90 832, 951
•
e-mail: export@relpol.com.pl
14.07.2014
Note:
the indicated polarity of the supply refers to the relays
with extra equipment
D
- surge suppression element (diode)
- for DC coils only.
Improvement of the efficiency of the electromagnet:
an innovational technology of connecting elements has
been introduced, which guarantees more reliable opera-
tion of the relay.
3
R3N
miniature industrial relays
Electrical life at AC resistive load.
Switching frequency: 1 200 cycles/hour
Fig. 1
Electrical life reduction factor
at AC inductive load
Fig. 2
Number of cycles
N
Reduction factor
Power factor
Breaking capacity [kVA]
N
- electrical life
at AC1
Max. DC breaking capacity
A - resistive load DC1
B - inductive load L/R = 40 ms
Fig. 3
Mounting
Relays
R3N
are offered in versions for plug-in sockets,
with WT features as standard
(W
- mechanical indi-
cator +
T
- lockable front test button). In these relays is
possibility self-exchange of button type T for test
button R4P-0001
(no latching)
or on plug R4W-0003
(no manual operation). The buttons
R4P-0001
and the
plugs
R4W-0003 need to ordered saparately.
Relays
R3N
are designed for: • screw terminals plug-
-in sockets
GZT3
❶
and
GZM3
❶
with clip
GZT4-0040
or
G4 1052,
35 mm rail mount acc. to PN-EN 60715
or on panel mounting with two M3 screws. Signalling /
protecting modules
type M...
are available with sockets
(see page 7).
❶
Plug-in sockets
GZT3, GZM3
may be linked with interconnection strip
type
ZGGZ4
(see page 8).
DC current [A]
DC voltage [V]
Contact material selection for different load types
•
AgNi
- for resistive or inductive loads,
•
AgNi/Au 0,2 µm
- Au protects the contact surface during storage.
www.relpol.com.pl
Export Sales Department
phone +48 68 47 90 832, 951
•
e-mail: export@relpol.com.pl
14.07.2014
4
R3N
Ordering codes
miniature industrial relays
Cover protection
category
Type
Contact
material
Number and type
of contacts
Connection
mode
Coil code
Additional
features
R 3 N —
Contact material
—
—
see Tables 1, 2 page 2
—
20
-
AgNi
21
- AgNi/Au 0,2 µm
Number and type of contacts
13
- 3 CO
Cover protection category
2
- in cover, IP 40 version
Connection mode
3
- for plug-in sockets
Additional features
without marks
- without additional features
WT
- mechanical indicator + lockable front test button
❷
WTL
- mechanical indicator + lockable front test button + light indicator (LED diode)
WTD
- mechanical indicator + lockable front test button + surge suppression element (diode)
❸
WTLD
- mechanical indicator + lockable front test button + light indicator (LED diode) + surge suppression element (diode)
❸
❷
WT
- standard features of relays
❸
WTD, WTLD
- available only in relays with DC coils
Test buttons (no latching) and plugs
need to ordered saparately. They substitute buttons type T. To exchange by Customer themselves.
Information on test buttons (no latching) and plugs - page 10.
• Button R4P-0001-A - orange colour (AC coils)
• Button R4P-0001-D - green colour (DC coils)
• Plug R4W-0003-A - orange colour (AC coils)
• Plug R4W-0003-D - green colour (DC coils)
Note:
For relays with additional features
D
- surge suppression element (diode) (versions WTD and WTLD) - fixed supply
polarity compulsory for the DC load of coils: +A1(13) / -A2(14). The polarity is indicated on the relay cover. For other
versions of the relays with DC coils any polarity is possible.
Example of ordering code:
R3N-2013-23-1024-WT
relay
R3N,
for plug-in sockets, three changeover contacts, contact material AgNi, coil
voltage 24 V DC, with mechanical indicator and lockable front test button, in cover IP 40
www.relpol.com.pl
Export Sales Department
phone +48 68 47 90 832, 951
•
e-mail: export@relpol.com.pl
14.07.2014
5
