IDT74LVC11APGG: Description3.3V CMOS TRIPLE 3-INPUT AND GATE WITH 5 VOLT TOLERANT I/O; File Size53KB，5 Pages; ManufacturerIDT (Integrated Device Technology, Inc.); Websitehttp://www.idt.com/

Download Datasheet Compare View All

IDT74LVC11APGG Overview

3.3V CMOS TRIPLE 3-INPUT AND GATE WITH 5 VOLT TOLERANT I/O

Preview

Download Datasheet

View All

IDT74LVC11A

3.3V CMOS TRIPLE 3-INPUT AND GATE WITH 5V TOLERANT I/O

INDUSTRIAL TEMPERATURE RANGE

3.3V CMOS

TRIPLE 3-INPUT AND GATE

WITH 5 VOLT TOLERANT I/O

FEATURES:

DESCRIPTION:

IDT74LVC11A

• 0.5 MICRON CMOS Technology

• ESD > 2000V per MIL-STD-883, Method 3015; > 200V using

machine model (C = 200pF, R = 0)

• V

= 3.3V ± 0.3V, Normal Range

• V

= 2.7V to 3.6V, Extended Range

• CMOS power levels (0.4µ W typ. static)

• Rail-to-Rail output swing for increased noise margin

• All inputs, outputs, and I/Os are 5V tolerant

• Supports hot insertion

• Available in SOIC, SSOP, and TSSOP packages

The LVC11A triple 3-input AND gate is built using advanced dual metal

CMOS technology. The LVC11A device provides the 3-input AND

function.

Inputs can be driven from either 3.3V or 5V devices. This feature allows

the use of this device as a translator in a mixed 3.3V/5V system environ-

ment.

The LVC11A has been designed with a ±24mA output driver. This driver

is capable of driving a moderate to heavy load while maintaining speed

performance.

DRIVE FEATURES:

• High Output Drivers: ±24mA

• Reduced system switching noise

APPLICATIONS:

• 3.3V high speed systems

• 3.3V and lower voltage computing systems

FUNCTIONAL BLOCK DIAGRAM

PIN CONFIGURATION

FUNCTION TABLE

Inputs

(1)

Outputs

GND

SOIC/ SSOP/ TSSOP

TOP VIEW

PIN DESCRIPTION

Pin Number

1, 3, 9

2, 4, 10

12, 6, 8

13, 5, 11

Symbol

1A - 3A

1B - 3B

GND

1Y - 3Y

1C - 3C

Data Inputs

Ground (0V)

Data Outputs

Data Inputs

Name and Function

NOTE:

1. H = HIGH Voltage Level

L = LOW Voltage Level

Positive Supply Voltage

The IDT logo is a registered trademark of Integrated Device Technology, Inc.

INDUSTRIAL TEMPERATURE RANGE

MARCH 1999

DSC-5155/2
